 6TGA | pdb_00006tga

Cryo-EM Structure of as isolated form of NAD+-dependent Formate Dehydrogenase from Rhodobacter capsulatus

Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.26 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 6TGA

This is version 1.3 of the entry. See complete history.

Literature

Cryo-EM structures reveal intricate Fe-S cluster arrangement and charging in Rhodobacter capsulatus formate dehydrogenase.

Radon, C., Mittelstadt, G., Duffus, B.R., Burger, J., Hartmann, T., Mielke, T., Teutloff, C., Leimkuhler, S., Wendler, P.

(2020) Nat Commun 11: 1912-1912

  • DOI: https://doi.org/10.1038/s41467-020-15614-0
  • Primary Citation Related Structures:
    6TG9, 6TGA

  • PubMed Abstract:

    Metal-containing formate dehydrogenases (FDH) catalyse the reversible oxidation of formate to carbon dioxide at their molybdenum or tungsten active site. They display a diverse subunit and cofactor composition, but structural information on these enzymes is limited. Here we report the cryo-electron microscopic structures of the soluble Rhodobacter capsulatus FDH (RcFDH) as isolated and in the presence of reduced nicotinamide adenine dinucleotide (NADH). RcFDH assembles into a 360 kDa dimer of heterotetramers revealing a putative interconnection of electron pathway chains. In the presence of NADH, the RcFDH structure shows charging of cofactors, indicative of an increased electron load.

    • Organizational Affiliation:
    • Institute of Biochemistry and Biology, Department of Biochemistry, University of Potsdam, Karl-Liebknecht Strasse 24-25, 14476, Potsdam-Golm, Germany.

Macromolecule Content

  • Total Structure Weight: 369.03 kDa
  • Atom Count: 25,324
  • Modeled Residue Count: 3,318
  • Deposited Residue Count: 3,358
  • Unique protein chains: 4

Macromolecules

Find similar proteins by:
|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Formate dehydrogenase subunit alpha
A, E
958Rhodobacter capsulatusMutation(s): 0
Gene Names: U715_16550
EC: 1.2.1.2
UniProt
Find proteins for D5AQH0 (Rhodobacter capsulatus (strain ATCC BAA-309 / NBRC 16581 / SB1003))
Explore D5AQH0
Go to UniProtKB:  D5AQH0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD5AQH0
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:
|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Formate dehydrogenase subunit beta
B, F
500Rhodobacter capsulatusMutation(s): 0
Gene Names: U715_16555
EC: 1.2.1.2
UniProt
Find proteins for D5AQH1 (Rhodobacter capsulatus (strain ATCC BAA-309 / NBRC 16581 / SB1003))
Explore D5AQH1
Go to UniProtKB:  D5AQH1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD5AQH1
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:
|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
Formate dehydrogenase subunit gammaC [auth G],
G [auth C]		150Rhodobacter capsulatusMutation(s): 0
Gene Names: U715_16560
EC: 1.2.1.2
UniProt
Find proteins for D5AQH2 (Rhodobacter capsulatus (strain ATCC BAA-309 / NBRC 16581 / SB1003))
Explore D5AQH2
Go to UniProtKB:  D5AQH2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD5AQH2
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:
|  3D Structure
Entity ID: 4
MoleculeChains  Sequence LengthOrganismDetailsImage
NAD-dependent formate dehydrogenase subunit delta
D, H
71Rhodobacter capsulatusMutation(s): 0
Gene Names: U715_16540
EC: 1.2.1.2
UniProt
Find proteins for D5AQG8 (Rhodobacter capsulatus (strain ATCC BAA-309 / NBRC 16581 / SB1003))
Explore D5AQG8
Go to UniProtKB:  D5AQG8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD5AQG8
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 6 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
MGD
(Subject of Investigation/LOI)

Query on MGD


Download:Ideal Coordinates CCD File
I [auth A],
J [auth A],
U [auth E],
V [auth E]		2-AMINO-5,6-DIMERCAPTO-7-METHYL-3,7,8A,9-TETRAHYDRO-8-OXA-1,3,9,10-TETRAAZA-ANTHRACEN-4-ONE GUANOSINE DINUCLEOTIDE
C20 H26 N10 O13 P2 S2
VQAGYJCYOLHZDH-ILXWUORBSA-N
FMN
(Subject of Investigation/LOI)

Query on FMN


Download:Ideal Coordinates CCD File
DA [auth F],
R [auth B]		FLAVIN MONONUCLEOTIDE
C17 H21 N4 O9 P
FVTCRASFADXXNN-SCRDCRAPSA-N
SF4
(Subject of Investigation/LOI)

Query on SF4


Download:Ideal Coordinates CCD File
AA [auth E]
BA [auth E]
EA [auth F]
M [auth A]
N [auth A]
AA [auth E],
BA [auth E],
EA [auth F],
M [auth A],
N [auth A],
O [auth A],
P [auth A],
S [auth B],
Y [auth E],
Z [auth E]
IRON/SULFUR CLUSTER
Fe4 S4
LJBDFODJNLIPKO-UHFFFAOYSA-N
FES
(Subject of Investigation/LOI)

Query on FES


Download:Ideal Coordinates CCD File
FA [auth C],
L [auth A],
T [auth G],
X [auth E]		FE2/S2 (INORGANIC) CLUSTER
Fe2 S2
NIXDOXVAJZFRNF-UHFFFAOYSA-N
6MO
(Subject of Investigation/LOI)

Query on 6MO


Download:Ideal Coordinates CCD File
K [auth A],
W [auth E]		MOLYBDENUM(VI) ION
Mo
HCNGUXXTNNIKCQ-UHFFFAOYSA-N
H2S
(Subject of Investigation/LOI)

Query on H2S


Download:Ideal Coordinates CCD File
CA [auth E],
Q [auth A]		HYDROSULFURIC ACID
H2 S
RWSOTUBLDIXVET-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.26 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONRELION3.0
MODEL REFINEMENTPHENIX1.14

Structure Validation

View Full Validation Report



View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
German Research FoundationGermanyEXC 314/2
German Research FoundationGermanyEXC 2008/1
European UnionGermanyiNext-4008

Revision History  (Full details and data files)

  • Version 1.0: 2020-04-22
    Type: Initial release
  • Version 1.1: 2020-04-29
    Changes: Database references
  • Version 1.2: 2024-05-22
    Changes: Data collection, Database references, Derived calculations
  • Version 1.3: 2026-09-02
    Type: Remediation
    Reason: Metalloprotein remediation
    Changes: Data collection, Derived calculations, Structure summary
