6T3Z

Crystal structure of the truncated EBV BFRF1-BFLF2 nuclear egress complex


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.56 Å
  • R-Value Free: 0.242
  • R-Value Work: 0.212
  • R-Value Observed: 0.214

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

High-resolution crystal structures of two prototypical beta- and gamma-herpesviral nuclear egress complexes unravel the determinants of subfamily specificity.

Muller, Y.A.Hage, S.Alkhashrom, S.Hollriegl, T.Weigert, S.Dolles, S.Hof, K.Walzer, S.A.Egerer-Sieber, C.Conrad, M.Holst, S.Losing, J.Sonntag, E.Sticht, H.Eichler, J.Marschall, M.

(2020) J Biol Chem 295: 3189-3201

  • DOI: https://doi.org/10.1074/jbc.RA119.011546
  • Primary Citation of Related Structures:
    6T3X, 6T3Z

  • PubMed Abstract:

    Herpesviruses uniquely express two essential nuclear egress-regulating proteins forming a heterodimeric basic structure of the nuclear egress complex (core NEC). These core NECs serve as a hexameric lattice-structured platform for capsid docking and recruit viral and cellular NEC-associated factors that jointly exert nuclear lamina- and membrane-rearranging functions (multicomponent NEC). Here, we report the X-ray structures of β- and γ-herpesvirus core NECs obtained through an innovative recombinant expression strategy based on NEC-hook::NEC-groove protein fusion constructs. This approach yielded the first structure of γ-herpesviral core NEC, namely the 1.56 Å structure of Epstein-Barr virus (EBV) BFRF1-BFLF2, as well as an increased resolution 1.48 Å structure of human cytomegalovirus (HCMV) pUL50-pUL53. Detailed analysis of these structures revealed that the prominent hook segment is absolutely required for core NEC formation and contributes approximately 80% of the interaction surface of the globular domains of NEC proteins. Moreover, using HCMV::EBV hook domain swap constructs, computational prediction of the roles of individual hook residues for binding, and quantitative binding assays with synthetic peptides presenting the HCMV- and EBV-specific NEC hook sequences, we characterized the unique hook-into-groove NEC interaction at various levels. Although the overall physicochemical characteristics of the protein interfaces differ considerably in these β- and γ-herpesvirus NECs, the binding free energy contributions of residues displayed from identical positions are similar. In summary, the results of our study reveal critical details of the molecular mechanism of herpesviral NEC interactions and highlight their potential as an antiviral drug target.


  • Organizational Affiliation

    Department of Biology, Division of Biotechnology, Friedrich-Alexander University of Erlangen-Nürnberg (FAU), Erlangen, Germany. Electronic address: yves.muller@fau.de.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Nuclear egress protein 2,Nuclear egress protein 1233human gammaherpesvirus 4Mutation(s): 0
Gene Names: BFRF1NEC2HHV4-K4123Mi_BFRF1NEC1
UniProt
Find proteins for V5KTU9 (Epstein-Barr virus (strain GD1))
Explore V5KTU9
Go to UniProtKB:  V5KTU9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupV5KTU9
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
MLI
Query on MLI

Download Ideal Coordinates CCD File
B [auth A]MALONATE ION
C3 H2 O4
OFOBLEOULBTSOW-UHFFFAOYSA-L
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.56 Å
  • R-Value Free: 0.242
  • R-Value Work: 0.212
  • R-Value Observed: 0.214
  • Space Group: P 61 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 59.313α = 90
b = 59.313β = 90
c = 265.37γ = 120
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XDSdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data

  • Released Date: 2020-02-12
  • Deposition Author(s): Muller, Y.A.

Funding OrganizationLocationGrant Number
German Research FoundationGermanyMU 1477/10-1

Revision History  (Full details and data files)

  • Version 1.0: 2020-02-12
    Type: Initial release
  • Version 1.1: 2020-03-18
    Changes: Database references
  • Version 1.2: 2024-01-24
    Changes: Data collection, Database references, Refinement description
