6S2O

Granulovirus occlusion bodies by serial electron diffraction


Experimental Data Snapshot

  • Method: ELECTRON CRYSTALLOGRAPHY
  • Resolution: 1.55 Å
  • R-Value Free: 0.197
  • R-Value Work: 0.171
  • R-Value Observed: 0.172

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Serial protein crystallography in an electron microscope.

Bucker, R.Hogan-Lamarre, P.Mehrabi, P.Schulz, E.C.Bultema, L.A.Gevorkov, Y.Brehm, W.Yefanov, O.Oberthur, D.Kassier, G.H.Dwayne Miller, R.J.

(2020) Nat Commun 11: 996-996

  • DOI: 10.1038/s41467-020-14793-0
  • Primary Citation of Related Structures:
    6S2N, 6S2O

  • PubMed Abstract:
  • Serial X-ray crystallography at free-electron lasers allows to solve biomolecular structures from sub-micron-sized crystals. However, beam time at these facilities is scarce, and involved sample delivery techniques are required. On the other hand, rotation electron diffraction (MicroED) has shown great potential as an alternative means for protein nano-crystallography ...

    Serial X-ray crystallography at free-electron lasers allows to solve biomolecular structures from sub-micron-sized crystals. However, beam time at these facilities is scarce, and involved sample delivery techniques are required. On the other hand, rotation electron diffraction (MicroED) has shown great potential as an alternative means for protein nano-crystallography. Here, we present a method for serial electron diffraction of protein nanocrystals combining the benefits of both approaches. In a scanning transmission electron microscope, crystals randomly dispersed on a sample grid are automatically mapped, and a diffraction pattern at fixed orientation is recorded from each at a high acquisition rate. Dose fractionation ensures minimal radiation damage effects. We demonstrate the method by solving the structure of granulovirus occlusion bodies and lysozyme to resolutions of 1.55 Å and 1.80 Å, respectively. Our method promises to provide rapid structure determination for many classes of materials with minimal sample consumption, using readily available instrumentation.


    Organizational Affiliation

    Departments of Chemistry and Physics, University of Toronto, 80 St. George Street, Toronto, ON, M5S 3H6, Canada. dwayne.miller@mpsd.mpg.de.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
GranulinA248Cydia pomonella granulosis virus (isolate Mexican)Mutation(s): 0
UniProt
Find proteins for P87577 (Cydia pomonella granulosis virus (isolate Mexico/1963))
Explore P87577
Go to UniProtKB:  P87577
Protein Feature View
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON CRYSTALLOGRAPHY
  • Resolution: 1.55 Å
  • R-Value Free: 0.197
  • R-Value Work: 0.171
  • R-Value Observed: 0.172
  • Space Group: I 2 3
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 103.2α = 90
b = 103.2β = 90
c = 103.2γ = 90
Software Package:
Software NamePurpose
phenix.refinerefinement
PHENIXrefinement

Structure Validation

View Full Validation Report




Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2020-04-29
    Type: Initial release
  • Version 1.1: 2020-11-11
    Changes: Database references
  • Version 1.2: 2020-11-18
    Changes: Database references
