6S2K | pdb_00006s2k

Human Menin in complex with AJ21

PDB DOI: https://doi.org/10.2210/pdb6S2K/pdb

Classification: ONCOPROTEIN
Organism(s): Homo sapiens
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2019-06-21 Released: 2021-01-13
Deposition Author(s): Groves, M.R., Gao, K.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 3.10 Å
R-Value Free:
0.300 (Depositor), 0.300 (DCC)
R-Value Work:
0.215 (Depositor), 0.220 (DCC)
R-Value Observed:
0.219 (Depositor)

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Human Menin in complex with AJ21

Groves, M.R., Gao, K.

To be published.

Macromolecule Content

Total Structure Weight: 116.68 kDa
Atom Count: 7,284
Modeled Residue Count: 931
Deposited Residue Count: 1,052
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Multiple endocrine neoplasia I, isoform CRA_b	A, B	526	Homo sapiens	Mutation(s): 0 Gene Names: MEN1, hCG_2017452
UniProt & NIH Common Fund Data Resources
Find proteins for O00255 (Homo sapiens) Explore O00255 Go to UniProtKB: O00255
PHAROS: O00255 GTEx: ENSG00000133895
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	O00255
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
KTQ Query on KTQ Download Ideal Coordinates CCD File SDF format, chain C [auth B] MOL2 format, chain C [auth B] mmCIF format, chain C [auth B]	C [auth B]	~{N}-[2-(4-methoxyphenyl)ethyl]-2-(4-nitrophenyl)imidazo[1,2-a]pyridin-3-amine C₂₂ H₂₀ N₄ O₃ YJYNKUFASFWVSL-UHFFFAOYSA-N		Interactions Focus chain C [auth B] Interactions & Density Focus chain C [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 3.10 Å
R-Value Free: 0.300 (Depositor), 0.300 (DCC)
R-Value Work: 0.215 (Depositor), 0.220 (DCC)
R-Value Observed: 0.219 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 84.399	α = 90
b = 101.31	β = 90
c = 126.842	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data reduction
XDS	data scaling
DIMPLE	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Released Date: 2021-01-13

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2021-01-13
Type: Initial release
Version 1.1: 2024-05-15
Changes: Data collection, Database references
