6RTQ | pdb_00006rtq

Hoefavidin P61C mutant generates a stabilized octamer

PDB DOI: https://doi.org/10.2210/pdb6RTQ/pdb

Classification: BIOTIN BINDING PROTEIN
Organism(s): Hoeflea phototrophica DFL-43
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2019-05-26 Released: 2019-08-14
Deposition Author(s): Livnah, O., Avraham, O.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free:
0.283 (Depositor), 0.294 (DCC)
R-Value Work:
0.227 (Depositor), 0.239 (DCC)
R-Value Observed:
0.230 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6RTQ

This is version 1.2 of the entry. See complete history.

Literature

Generating a High Valency Biotin Binder by Selecting Uniform Protein Assemblies via Crystallization

Avraham, O., Levi-Kalisman, Y., Livnah, O.

(2019) Crystals (Basel)

DOI: https://doi.org/10.3390/cryst9070353

Macromolecule Content

Total Structure Weight: 31.16 kDa
Atom Count: 2,073
Modeled Residue Count: 266
Deposited Residue Count: 292
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Hoefavidin	A, B	146	Hoeflea phototrophica DFL-43	Mutation(s): 1 Gene Names: HPDFL43_17171
UniProt
Find proteins for A9D857 (Hoeflea phototrophica (strain DSM 17068 / NCIMB 14078 / DFL-43)) Explore A9D857 Go to UniProtKB: A9D857
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A9D857
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free: 0.283 (Depositor), 0.294 (DCC)
R-Value Work: 0.227 (Depositor), 0.239 (DCC)
R-Value Observed: 0.230 (Depositor)

Space Group: P 6₂ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 81.885	α = 90
b = 81.885	β = 90
c = 130.429	γ = 120

Software Package:

Software Name	Purpose
REFMAC	refinement
MOSFLM	data reduction
Aimless	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2019-08-14

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2019-08-14
Type: Initial release
Version 1.1: 2024-01-24
Changes: Data collection, Database references, Derived calculations, Refinement description
Version 1.2: 2024-11-13
Changes: Structure summary
