6RCH | pdb_00006rch

Crystal structure of Casein kinase I isoform delta (CK1 delta) complexed with SR4133 inhibitor

PDB DOI: https://doi.org/10.2210/pdb6RCH/pdb

Classification: TRANSFERASE
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2019-04-11 Released: 2020-03-25
Deposition Author(s): Chaikuad, A., Arrowsmith, C.H., Edwards, A.M., Bountra, C., Roush, W.R., Knapp, S., Structural Genomics Consortium (SGC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.45 Å
R-Value Free:
0.178 (Depositor), 0.187 (DCC)
R-Value Work:
0.155 (Depositor), 0.165 (DCC)
R-Value Observed:
0.157 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of Casein kinase I isoform delta (CK1 delta) complexed with SR4133 inhibitor

Chaikuad, A., Arrowsmith, C.H., Edwards, A.M., Bountra, C., Roush, W.R., Knapp, S., Structural Genomics Consortium (SGC)

To be published.

Macromolecule Content

Total Structure Weight: 70.45 kDa
Atom Count: 5,794
Modeled Residue Count: 586
Deposited Residue Count: 592
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Casein kinase I isoform delta	A, B	296	Homo sapiens	Mutation(s): 0 Gene Names: CSNK1D, HCKID EC: 2.7.11.1 (PDB Primary Data), 2.7.11.26 (PDB Primary Data)
UniProt & NIH Common Fund Data Resources
Find proteins for P48730 (Homo sapiens) Explore P48730 Go to UniProtKB: P48730
PHAROS: P48730 GTEx: ENSG00000141551
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P48730
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
K0B Query on K0B Download Ideal Coordinates CCD File SDF format, chain L [auth A] MOL2 format, chain L [auth A] mmCIF format, chain L [auth A]	L [auth A]	~{N}-[[4,5-bis(fluoranyl)-1~{H}-benzimidazol-2-yl]methyl]-2-morpholin-4-yl-9-naphthalen-2-yl-purin-6-amine C₂₇ H₂₂ F₂ N₈ O DOPHVIBXJOSQHB-UHFFFAOYSA-N		Interactions Focus chain L [auth A] Interactions & Density Focus chain L [auth A]
SO4 Query on SO4 Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain M [auth B] SDF format, chain N [auth B] SDF format, chain O [auth B] SDF format, chain P [auth B] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain M [auth B] MOL2 format, chain N [auth B] MOL2 format, chain O [auth B] MOL2 format, chain P [auth B] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain M [auth B] mmCIF format, chain N [auth B] mmCIF format, chain O [auth B] mmCIF format, chain P [auth B]	C [auth A] D [auth A] E [auth A] M [auth B] N [auth B] C [auth A], D [auth A], E [auth A], M [auth B], N [auth B], O [auth B], P [auth B]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain M [auth B] Focus chain N [auth B] Focus chain O [auth B] Focus chain P [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain M [auth B] Focus chain N [auth B] Focus chain O [auth B] Focus chain P [auth B]
EDO Query on EDO Download Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain Q [auth B] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain Q [auth B] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain Q [auth B]	F [auth A] G [auth A] H [auth A] I [auth A] J [auth A] F [auth A], G [auth A], H [auth A], I [auth A], J [auth A], Q [auth B]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain Q [auth B] Interactions & Density Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain Q [auth B]
NA Query on NA Download Ideal Coordinates CCD File SDF format, chain K [auth A] SDF format, chain R [auth B] MOL2 format, chain K [auth A] MOL2 format, chain R [auth B] mmCIF format, chain K [auth A] mmCIF format, chain R [auth B]	K [auth A], R [auth B]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N		Interactions Focus chain K [auth A] Focus chain R [auth B] Interactions & Density Focus chain K [auth A] Focus chain R [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.45 Å
R-Value Free: 0.178 (Depositor), 0.187 (DCC)
R-Value Work: 0.155 (Depositor), 0.165 (DCC)
R-Value Observed: 0.157 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 49.106	α = 90
b = 74.072	β = 103.18
c = 88.967	γ = 90

Software Package:

Software Name	Purpose
SCALA	data scaling
REFMAC	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Released Date: 2020-03-25

Deposition Author(s):

Structural Genomics Consortium (SGC)

Revision History (Full details and data files)

Version 1.0: 2020-03-25
Type: Initial release
Version 1.1: 2024-01-24
Changes: Data collection, Database references, Derived calculations, Refinement description
