6R33

Aspergillus niger ferulic acid decarboxylase (Fdc)in complex with the covalent adduct formed between prFMN cofactor and phenylpropiolic acid, following decarboxylation (Int3')

  • Classification: LYASE
  • Organism(s): Aspergillus niger
  • Expression System: Escherichia coli
  • Mutation(s): No

  • Deposited: 2019-03-19 Released: 2019-08-28
  • Deposition Author(s): Bailey, S.S., Leys, D.
  • Funding Organization(s): European Research Council, Biotechnology and Biological Sciences Research Council

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.01 Å
  • R-Value Free: 0.136
  • R-Value Work: 0.117
  • R-Value Observed: 0.118

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history


Literature

Atomic description of an enzyme reaction dependent on reversible 1,3-dipolar cycloaddition

Bailey, S.S.Payne, K.A.P.Saaret, A.Marshall, S.A.Gostimskaya, I.Kosov, I.Fisher, K.Hay, S.Leys, D.

To be published.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Ferulic acid decarboxylase 1A508Aspergillus nigerMutation(s): 0
Gene Names: fdc1An03g06590
EC: 4.1.1.102
UniProt
Find proteins for A2QHE5 (Aspergillus niger (strain CBS 513.88 / FGSC A1513))
Explore A2QHE5
Go to UniProtKB:  A2QHE5
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
JQH (Subject of Investigation/LOI)
Query on JQH

Download Ideal Coordinates CCD File
E [auth A]prFMN cofactor and phenylpropiolic acid adduct
C30 H35 N4 O9 P
PESIXFCXBGLILZ-QNFINUSWSA-N
 Ligand Interaction
MN
Query on MN

Download Ideal Coordinates CCD File
B [auth A]MANGANESE (II) ION
Mn
WAEMQWOKJMHJLA-UHFFFAOYSA-N
 Ligand Interaction
K
Query on K

Download Ideal Coordinates CCD File
C [auth A], D [auth A]POTASSIUM ION
K
NPYPAHLBTDXSSS-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.01 Å
  • R-Value Free: 0.136
  • R-Value Work: 0.117
  • R-Value Observed: 0.118
  • Space Group: P 21 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 95.89α = 90
b = 64.21β = 90
c = 87.57γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
xia2data reduction
xia2data scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment



Entry History & Funding Information

Deposition Data

  • Deposited Date: 2019-03-19
  • Released Date: 2019-08-28
  • Deposition Author(s): Bailey, S.S., Leys, D.

Funding OrganizationLocationGrant Number
European Research CouncilUnited KingdompreFAB 695013
Biotechnology and Biological Sciences Research CouncilUnited KingdomBB/K017802

Revision History  (Full details and data files)

  • Version 1.0: 2019-08-28
    Type: Initial release
