Crystal Structure of tyrosinase from Bacillus megaterium with JKB inhibitor in the active site.

Experimental Data Snapshot

  • Resolution: 2.32 Å
  • R-Value Free: 0.248
  • R-Value Work: 0.199
  • R-Value Observed: 0.201

wwPDB Validation   3D Report Full Report

This is version 1.1 of the entry. See complete history


Exploiting the 1-(4-fluorobenzyl)piperazine fragment for the development of novel tyrosinase inhibitors as anti-melanogenic agents: Design, synthesis, structural insights and biological profile.

Ielo, L.Deri, B.Germano, M.P.Vittorio, S.Mirabile, S.Gitto, R.Rapisarda, A.Ronsisvalle, S.Floris, S.Pazy, Y.Fais, A.Fishman, A.De Luca, L.

(2019) Eur J Med Chem 178: 380-389

  • DOI: https://doi.org/10.1016/j.ejmech.2019.06.019
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    The development of Tyrosinase inhibitors (TYRIs) could represent an efficacious strategy for pharmacological intervention on skin pathologies related to aberrant production of melanin. Based on in silico studies we designed and tested a library of twenty-four compounds bearing the 4-(4-fluorobenzyl)piperazin-1-yl]-fragment. As result, we identified several compounds with excellent inhibit effects at low micromolar concentration against TYR from Agaricus bisporus (TyM). Among them, compound 25 (IC 50  = 0.96 μM) proved to be ∼20-fold more potent than the reference compound kojic acid (IC 50  = 17.76 μM) having wide applications in the cosmetics and pharmaceutical industries. The mode of interaction of active inhibitor 25 was deciphered by means of crystallography as well as molecular docking and these results were consistent with kinetic experiments. Moreover, the identified compound 25 exhibited no considerable cytotoxicity and showed anti-melanogenic effects on B16F10 melanoma cells. Therefore, a combination of computational and biochemical approaches could represent a rational guidelines for further structural modification of this class of compounds as future anti-melanogenic agents.

  • Organizational Affiliation

    Department of Biotechnology and Food Engineering, Technion-Israel Institute of Technology, Haifa, 3200003, Israel.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
A, B
287Priestia megateriumMutation(s): 0
Find proteins for B2ZB02 (Priestia megaterium)
Explore B2ZB02
Go to UniProtKB:  B2ZB02
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB2ZB02
Sequence Annotations
  • Reference Sequence
Small Molecules
Experimental Data & Validation

Experimental Data

  • Resolution: 2.32 Å
  • R-Value Free: 0.248
  • R-Value Work: 0.199
  • R-Value Observed: 0.201
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 48.129α = 90
b = 78.263β = 105.82
c = 84.873γ = 90
Software Package:
Software NamePurpose
MOSFLMdata reduction
SCALAdata scaling

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
Israel Science FoundationIsrael419/15

Revision History  (Full details and data files)

  • Version 1.0: 2019-06-19
    Type: Initial release
  • Version 1.1: 2019-06-26
    Changes: Data collection, Database references
