6Q58

Copper loading to a cytosolic copper storage protein from Streptomyces lividans (five coppers)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.50 Å
  • R-Value Free: 0.213
  • R-Value Work: 0.195
  • R-Value Observed: 0.196

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

A Histidine Residue and a Tetranuclear Cuprous-thiolate Cluster Dominate the Copper Loading Landscape of a Copper Storage Protein from Streptomyces lividans.

Straw, M.L.Hough, M.A.Wilson, M.T.Worrall, J.A.R.

(2019) Chemistry 25: 10678-10688

  • DOI: 10.1002/chem.201901411
  • Primary Citation of Related Structures:
    6Q58, 6Q6B, 6R01, 6QVH, 6QYB

  • PubMed Abstract:
  • The chemical basis for protecting organisms against the toxic effect imposed by excess cuprous ions is to constrain this through high-affinity binding sites that use cuprous-thiolate coordination chemistry. In bacteria, a family of cysteine rich four-helix bundle proteins utilise thiolate chemistry to bind up to 80 cuprous ions ...

    The chemical basis for protecting organisms against the toxic effect imposed by excess cuprous ions is to constrain this through high-affinity binding sites that use cuprous-thiolate coordination chemistry. In bacteria, a family of cysteine rich four-helix bundle proteins utilise thiolate chemistry to bind up to 80 cuprous ions. These proteins have been termed copper storage proteins (Csp). The present study investigates cuprous ion loading to the Csp from Streptomyces lividans (SlCsp) using a combination of X-ray crystallography, site-directed mutagenesis and stopped-flow reaction kinetics with either aquatic cuprous ions or a chelating donor. We illustrate that at low cuprous ion concentrations, copper is loaded exclusively into an outer core region of SlCsp via one end of the four-helix bundle, facilitated by a set of three histidine residues. X-ray crystallography reveals the existence of polynuclear cuprous-thiolate clusters culminating in the assembly of a tetranuclear [Cu 4 2 -S-Cys) 4 δ1 -His)] cluster in the outer core. As more cuprous ions are loaded, the cysteine lined inner core of SlCsp fills with cuprous ions but in a fluxional and dynamic manner with no evidence for the assembly of further intermediate polynuclear cuprous-thiolate clusters as observed in the outer core. Using site-directed mutagenesis a key role for His107 in the efficient loading of cuprous ions from a donor is established. A model of copper loading to SlCsp is proposed and discussed.


    Organizational Affiliation

    School of Biological Sciences, University of Essex, Wivenhoe Park, Colchester, CO4 3SQ, UK.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Cytosolic copper storage proteinD [auth A], A [auth B], B [auth C], C [auth D]120Streptomyces lividans 1326Mutation(s): 0
Gene Names: SCO3281
UniProt
Find proteins for Q9X8F4 (Streptomyces coelicolor (strain ATCC BAA-471 / A3(2) / M145))
Explore Q9X8F4
Go to UniProtKB:  Q9X8F4
Protein Feature View
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.50 Å
  • R-Value Free: 0.213
  • R-Value Work: 0.195
  • R-Value Observed: 0.196
  • Space Group: P 61 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 93.051α = 90
b = 93.051β = 90
c = 212.34γ = 120
Software Package:
Software NamePurpose
Aimlessdata scaling
REFMACrefinement
PDB_EXTRACTdata extraction
DIALSdata reduction
MOLREPphasing

Structure Validation

View Full Validation Report




Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2019-07-10
    Type: Initial release
  • Version 1.1: 2019-08-21
    Changes: Data collection, Database references
