6PLK

Crystal structure of ZIKV-116 Fab in complex with ZIKV envelope DIII


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.3 Å
  • R-Value Free: 0.211
  • R-Value Work: 0.167

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Mechanism of differential Zika and dengue virus neutralization by a public antibody lineage targeting the DIII lateral ridge.

Zhao, H.Xu, L.Bombardi, R.Nargi, R.Deng, Z.Errico, J.M.Nelson, C.A.Dowd, K.A.Pierson, T.C.Crowe, J.E.Diamond, M.S.Fremont, D.H.

(2020) J.Exp.Med. 217: --

  • DOI: 10.1084/jem.20191792

  • PubMed Abstract:
  • We previously generated a panel of human monoclonal antibodies (mAbs) against Zika virus (ZIKV) and identified one, ZIKV-116, that shares germline usage with mAbs identified in multiple donors. Here we show that ZIKV-116 interferes with ZIKV infectio ...

    We previously generated a panel of human monoclonal antibodies (mAbs) against Zika virus (ZIKV) and identified one, ZIKV-116, that shares germline usage with mAbs identified in multiple donors. Here we show that ZIKV-116 interferes with ZIKV infection at a post-cellular attachment step by blocking viral fusion with host membranes. ZIKV-116 recognizes the lateral ridge of envelope protein domain III, with one critical residue varying between the Asian and African strains responsible for differential binding affinity and neutralization potency (E 393 D). ZIKV-116 also binds to and cross-neutralizes some dengue virus serotype 1 (DENV1) strains, with genotype-dependent inhibition explained by variation in a domain II residue (R 204 K) that potentially modulates exposure of the distally located, partially cryptic epitope. The V-J reverted germline configuration of ZIKV-116 preferentially binds to and neutralizes an Asian ZIKV strain, suggesting that this epitope may optimally induce related B cell clonotypes. Overall, these studies provide a structural and molecular mechanism for a cross-reactive mAb that uniquely neutralizes ZIKV and DENV1.


    Organizational Affiliation

    Department of Molecular Microbiology, Washington University School of Medicine, Saint Louis, MO.,Viral Pathogenesis Section, National Institute of Allergy and Infectious Diseases, National Institutes of Health, Bethesda, MD.,Department of Pathology, Microbiology and Immunology, Vanderbilt University Medical Center, Nashville, TN.,Department of Pathology & Immunology, Washington University School of Medicine, Saint Louis, MO fremont@wustl.edu.,Department of Cell Biology & Physiology, Washington University School of Medicine, Saint Louis, MO.,Department of Pediatrics, Vanderbilt University Medical Center, Nashville, TN.,The Vanderbilt Vaccine Center, Vanderbilt University Medical Center, Nashville, TN.,Department of Pathology & Immunology, Washington University School of Medicine, Saint Louis, MO.,Department of Medicine, Washington University School of Medicine, Saint Louis, MO.,Department of Biochemistry & Molecular Biophysics, Washington University School of Medicine, Saint Louis, MO.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
ZIKV-116 heavy chain
H, I
225N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
ZIKV-116 light chain
L, M
214N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetails
Env
E, F
110Zika virus (isolate ZIKV/Human/French Polynesia/10087PF/2013)Mutation(s): 0
Find proteins for A0A024B7W1 (Zika virus (isolate ZIKV/Human/French Polynesia/10087PF/2013))
Go to UniProtKB:  A0A024B7W1
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.3 Å
  • R-Value Free: 0.211
  • R-Value Work: 0.167
  • Space Group: P 1 21 1
Unit Cell:
Length (Å)Angle (°)
a = 72.809α = 90.00
b = 89.805β = 103.96
c = 92.487γ = 90.00
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data reduction
PHENIXrefinement
HKL-2000data scaling
PHASERphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United States--

Revision History

  • Version 1.0: 2019-11-20
    Type: Initial release
  • Version 1.1: 2019-12-04
    Type: Database references
  • Version 1.2: 2019-12-18
    Type: Author supporting evidence, Database references
