6PKO

MicroED structure of proteinase K from a platinum coated, unpolished, single lamella at 2.07A resolution (#12)

Experimental Data Snapshot

  • Method: ELECTRON CRYSTALLOGRAPHY
  • Resolution: 2.07 Å
  • R-Value Free: 0.269
  • R-Value Work: 0.216
  • R-Value Observed: 0.220

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history.


Literature

Qualitative Analyses of Polishing and Precoating FIB Milled Crystals for MicroED.

Martynowycz, M.W., Zhao, W., Hattne, J., Jensen, G.J., Gonen, T.

(2019) Structure 27: 1594

  • DOI: 10.1016/j.str.2019.07.004
  • Primary Citation of Related Structures:
    6PKJ, 6PKK, 6PKL, 6PKM, 6PKN, 6PKO, 6PKP, 6PKQ, 6PKR, 6PKS, 6PKT

  • PubMed Abstract:

    • Microcrystal electron diffraction (MicroED) leverages the strong interaction between matter and electrons to determine protein structures from vanishingly small crystals. This strong interaction limits the thickness of crystals that can be investigated by MicroED, mainly due to absorption ...

    Microcrystal electron diffraction (MicroED) leverages the strong interaction between matter and electrons to determine protein structures from vanishingly small crystals. This strong interaction limits the thickness of crystals that can be investigated by MicroED, mainly due to absorption. Recent studies have demonstrated that focused ion-beam (FIB) milling can thin crystals into ideal-sized lamellae; however, it is not clear how to best apply FIB milling for MicroED. Here, the effects of polishing the lamellae, whereby the last few nanometers are milled away using a low-current gallium beam, are explored in both the platinum-precoated and uncoated samples. Our results suggest that precoating samples with a thin layer of platinum followed by polishing the crystal surfaces prior to data collection consistently led to superior results as indicated by higher signal-to-noise ratio, higher resolution, and better refinement statistics. This study lays the foundation for routine and reproducible methodology for sample preparation in MicroED.

    Organizational Affiliation:

    Howard Hughes Medical Institute, University of California Los Angeles, Los Angeles, CA, USA; Departments of Biological Chemistry and Physiology, University of California Los Angeles, Los Angeles, CA, USA. Electronic address: tgonen@ucla.edu.



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Proteinase KA279Parengyodontium albumMutation(s): 0
Gene Names: PROK
EC: 3.4.21.64
UniProt
Find proteins for P06873 (Parengyodontium album)
Explore P06873
Go to UniProtKB:  P06873
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP06873
Protein Feature View
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON CRYSTALLOGRAPHY
  • Resolution: 2.07 Å
  • R-Value Free: 0.269
  • R-Value Work: 0.216
  • R-Value Observed: 0.220
  • Space Group: P 43 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 67.32α = 90
b = 67.32β = 90
c = 105.09γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement

Structure Validation

View Full Validation Report



View more in-depth experimental data

Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
National Institutes of Health/National Human Genome Research Institute (NIH/NHGRI)United StatesR35 GM122588
National Institutes of Health/National Human Genome Research Institute (NIH/NHGRI)United States2P50GM082545

Revision History  (Full details and data files)

  • Version 1.0: 2019-09-04
    Type: Initial release
  • Version 1.1: 2019-10-16
    Changes: Data collection, Database references
  • Version 1.2: 2019-12-18
    Changes: Author supporting evidence
