6PI5 | pdb_00006pi5

The evolving story of AtzT, a periplasmic binding protein


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.67 Å
  • R-Value Free:
    0.184 (Depositor)
  • R-Value Work:
    0.156 (Depositor)
  • R-Value Observed:
    0.158 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6PI5

Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history

Literature

The evolving story of AtzT, a periplasmic binding protein.

Dennis, M.L.Esquirol, L.Nebl, T.Newman, J.Scott, C.Peat, T.S.

(2019) Acta Crystallogr D Struct Biol 75: 995-1002

  • DOI: https://doi.org/10.1107/S2059798319013883
  • Primary Citation Related Structures:
    6PI5, 6PI6, 6PII

  • PubMed Abstract:

    Atrazine is an s-triazine-based herbicide that is used in many countries around the world in many millions of tons per year. A small number of organisms, such as Pseudomonas sp. strain ADP, have evolved to use this modified s-triazine as a food source, and the various genes required to metabolize atrazine can be found on a single plasmid. The atomic structures of seven of the eight proteins involved in the breakdown of atrazine by Pseudomonas sp. strain ADP have been determined by X-ray crystallography, but the structures of the proteins required by the cell to import atrazine for use as an energy source are still lacking. The structure of AtzT, a periplasmic binding protein that may be involved in the transport of a derivative of atrazine, 2-hydroxyatrazine, into the cell for mineralization, has now been determined. The structure was determined by SAD phasing using an ethylmercury phosphate derivative that diffracted X-rays to beyond 1.9 Å resolution. `Native' (guanine-bound) and 2-hydroxyatrazine-bound structures were also determined to high resolution (1.67 and 1.65 Å, respectively), showing that 2-hydroxyatrazine binds in a similar way to the purportedly native ligand. Structural similarities led to the belief that it may be possible to evolve AtzT from a purine-binding protein to a protein that can bind and detect atrazine in the environment.


  • Organizational Affiliation
    • Biomedical Manufacturing Program, CSIRO, 343 Royal Parade, Parkville, VIC 3052, Australia.

Macromolecule Content

  • Total Structure Weight: 153.85 kDa
  • Atom Count: 11,222
  • Modeled Residue Count: 1,333
  • Deposited Residue Count: 1,420
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Atrazine periplasmic binding protein
A, B, C, D
355Pseudomonas sp. ADPMutation(s): 0
Gene Names: orf97AOX63_31690
UniProt
Find proteins for A0ACD6B843 (Pseudomonas sp. (strain ADP))
Explore A0ACD6B843
Go to UniProtKB:  A0ACD6B843
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0ACD6B843
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.67 Å
  • R-Value Free:  0.184 (Depositor)
  • R-Value Work:  0.156 (Depositor)
  • R-Value Observed: 0.158 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 99.006α = 90
b = 63.142β = 93.55
c = 120.373γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2019-11-13
    Type: Initial release
  • Version 1.1: 2019-12-25
    Changes: Database references
  • Version 1.2: 2023-10-11
    Changes: Data collection, Database references, Refinement description
