Crystal structure of Glucose Isomerase from Non-merohedrally twinned crystals

Experimental Data Snapshot

  • Resolution: 1.60 Å
  • R-Value Free: 0.220
  • R-Value Work: 0.190
  • R-Value Observed: 0.190

wwPDB Validation   3D Report Full Report

This is version 1.0 of the entry. See complete history


Non-merohedral twinning: from minerals to proteins.

Sevvana, M.Ruf, M.Uson, I.Sheldrick, G.M.Herbst-Irmer, R.

(2019) Acta Crystallogr D Struct Biol 75: 1040-1050

  • DOI: https://doi.org/10.1107/S2059798319010179
  • Primary Citation of Related Structures:
    6OQZ, 6OR0

  • PubMed Abstract:

    In contrast to twinning by merohedry, the reciprocal lattices of the different domains of non-merohedral twins do not overlap exactly. This leads to three kinds of reflections: reflections with no overlap, reflections with an exact overlap and reflections with a partial overlap of a reflection from a second domain. This complicates the unit-cell determination, indexing, data integration and scaling of X-ray diffraction data. However, with hindsight it is possible to detwin the data because there are reflections that are not affected by the twinning. In this article, the successful solution and refinement of one mineral, one organometallic and two protein non-merohedral twins using a common strategy are described. The unit-cell constants and the orientation matrices were determined by the program CELL_NOW. The data were then integrated with SAINT. TWINABS was used for scaling, empirical absorption corrections and the generation of two different data files, one with detwinned data for structure solution and refinement and a second one for (usually more accurate) structure refinement against total integrated intensities. The structures were solved by experimental phasing using SHELXT for the first two structures and SHELXC/D/E for the two protein structures; all models were refined with SHELXL.

  • Organizational Affiliation

    Structural Biology, IBMB-CSIC, Baldiri Reixach 13-15, 08028 Barcelona, Spain.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Xylose isomerase386Streptomyces rubiginosusMutation(s): 0
Gene Names: xylA
Find proteins for P24300 (Streptomyces rubiginosus)
Explore P24300
Go to UniProtKB:  P24300
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP24300
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 1.60 Å
  • R-Value Free: 0.220
  • R-Value Work: 0.190
  • R-Value Observed: 0.190
  • Space Group: I 2 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 92.931α = 90
b = 97.935β = 90
c = 102.706γ = 90
Software Package:
Software NamePurpose
SAINTdata reduction
SADABSdata scaling

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
Spanish Ministry of Science, Innovation, and UniversitiesSpainBIO2015-64216-P
European Union (EU)European UnionMDM2014-0435

Revision History  (Full details and data files)

  • Version 1.0: 2019-12-11
    Type: Initial release
