6OML

Human BMP chimera BV261


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free: 0.265
  • R-Value Work: 0.199
  • R-Value Observed: 0.202

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 2.0 of the entry. See complete history


Literature

A BMP/activin A chimera is superior to native BMPs and induces bone repair in nonhuman primates when delivered in a composite matrix.

Seeherman, H.J.Berasi, S.P.Brown, C.T.Martinez, R.X.Juo, Z.S.Jelinsky, S.Cain, M.J.Grode, J.Tumelty, K.E.Bohner, M.Grinberg, O.Orr, N.Shoseyov, O.Eyckmans, J.Chen, C.Morales, P.R.Wilson, C.G.Vanderploeg, E.J.Wozney, J.M.

(2019) Sci Transl Med 11

  • DOI: 10.1126/scitranslmed.aar4953
  • Primary Citation of Related Structures:
    6OML, 6OMN, 6OMO

  • PubMed Abstract:
  • Bone morphogenetic protein (BMP)/carriers approved for orthopedic procedures achieve efficacy superior or equivalent to autograft bone. However, required supraphysiological BMP concentrations have been associated with potential local and systemic adverse events ...

    Bone morphogenetic protein (BMP)/carriers approved for orthopedic procedures achieve efficacy superior or equivalent to autograft bone. However, required supraphysiological BMP concentrations have been associated with potential local and systemic adverse events. Suboptimal BMP/receptor binding and rapid BMP release from approved carriers may contribute to these outcomes. To address these issues and improve efficacy, we engineered chimeras with increased receptor binding by substituting BMP-6 and activin A receptor binding domains into BMP-2 and optimized a carrier for chimera retention and tissue ingrowth. BV-265, a BMP-2/BMP-6/activin A chimera, demonstrated increased binding affinity to BMP receptors, including activin-like kinase-2 (ALK2) critical for bone formation in people. BV-265 increased BMP intracellular signaling, osteogenic activity, and expression of bone-related genes in murine and human cells to a greater extent than BMP-2 and was not inhibited by BMP antagonist noggin or gremlin. BV-265 induced larger ectopic bone nodules in rats compared to BMP-2 and was superior to BMP-2, BMP-2/6, and other chimeras in nonhuman primate bone repair models. A composite matrix (CM) containing calcium-deficient hydroxyapatite granules suspended in a macroporous, fenestrated, polymer mesh-reinforced recombinant human type I collagen matrix demonstrated improved BV-265 retention, minimal inflammation, and enhanced handling. BV-265/CM was efficacious in nonhuman primate bone repair models at concentrations ranging from 1 / 10 to 1 / 30 of the BMP-2/absorbable collagen sponge (ACS) concentration approved for clinical use. Initial toxicology studies were negative. These results support evaluations of BV-265/CM as an alternative to BMP-2/ACS in clinical trials for orthopedic conditions requiring augmented healing.


    Organizational Affiliation

    Bioventus Surgical, Bioventus LLC, Boston, MA 02215, USA.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Bone morphogenetic protein 2 and Bone morphogenetic protein 6A [auth X],
B [auth Y]
105Homo sapiensMutation(s): 0
Gene Names: BMP2BMP2A
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Protein Feature View
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 2
MoleculeChainsChain Length2D DiagramGlycosylation3D Interactions
alpha-D-mannopyranose-(1-2)-alpha-D-mannopyranose-(1-3)-[alpha-D-mannopyranose-(1-6)]beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranoseC [auth A]6N-Glycosylation Oligosaccharides Interaction
Glycosylation Resources
GlyTouCan:  G56014GC
GlyCosmos:  G56014GC
GlyGen:  G56014GC
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
NAG
Query on NAG

Download Ideal Coordinates CCD File
D [auth X]2-acetamido-2-deoxy-beta-D-glucopyranose
C8 H15 N O6
OVRNDRQMDRJTHS-FMDGEEDCSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free: 0.265
  • R-Value Work: 0.199
  • R-Value Observed: 0.202
  • Space Group: P 43 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 67.779α = 90
b = 67.779β = 90
c = 148.011γ = 90
Software Package:
Software NamePurpose
BUSTERrefinement
MOSFLMdata reduction
SCALAdata scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2019-05-15
    Type: Initial release
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Atomic model, Data collection, Derived calculations, Structure summary
