6OLN | pdb_00006oln

Controlling the Self-Assembly of Synthetic Metal-Coordinating Coiled-Coil Peptides: Orthorhombic Lattice from a Trimeric Coiled Coil

PDB DOI: https://doi.org/10.2210/pdb6OLN/pdb

Classification: DE NOVO PROTEIN
Organism(s): synthetic construct
Mutation(s): No

Deposited: 2019-04-16 Released: 2020-02-19
Deposition Author(s): Scheib, K.A., Horne, W.S.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.50 Å
R-Value Free:
0.295 (Depositor), 0.305 (DCC)
R-Value Work:
0.268 (Depositor), 0.274 (DCC)
R-Value Observed:
0.271 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.3 of the entry. See complete history.

Literature

Understanding and controlling the metal-directed assembly of terpyridine-functionalized coiled-coil peptides.

Scheib, K.A., Tavenor, N.A., Lawless, M.J., Saxena, S., Horne, W.S.

(2019) Chem Commun (Camb) 55: 7752-7755

PubMed: 31204733 Search on PubMed
DOI: https://doi.org/10.1039/c9cc03496j
Primary Citation Related Structures:
6OLN, 6OLO

PubMed Abstract:
Metal-binding peptides are versatile building blocks in supramolecular chemistry. We recently reported a class of crystalline materials formed through a combination of coiled-coil peptide self-association and metal coordination. Here, we probe the serendipitously discovered metal binding motif that drives the assembly and apply these insights to exert rational control over structure and morphology in the materials.

Organizational Affiliation

Department of Chemistry, University of Pittsburgh, Pittsburgh, PA 15260, USA. horne@pitt.edu.

Macromolecule Content

Total Structure Weight: 19.65 kDa
Atom Count: 1,476
Modeled Residue Count: 180
Deposited Residue Count: 180
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Designed trimeric coiled coil peptide	A, B, C, D, E A, B, C, D, E, F	30	synthetic construct	Mutation(s): 0

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CU Query on CU Download:Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain J [auth B] SDF format, chain M [auth C] SDF format, chain P [auth D] SDF format, chain Q [auth E] SDF format, chain R [auth F] MOL2 format, chain G [auth A] MOL2 format, chain J [auth B] MOL2 format, chain M [auth C] MOL2 format, chain P [auth D] MOL2 format, chain Q [auth E] MOL2 format, chain R [auth F] mmCIF format, chain G [auth A] mmCIF format, chain J [auth B] mmCIF format, chain M [auth C] mmCIF format, chain P [auth D] mmCIF format, chain Q [auth E] mmCIF format, chain R [auth F]	G [auth A] J [auth B] M [auth C] P [auth D] Q [auth E] G [auth A], J [auth B], M [auth C], P [auth D], Q [auth E], R [auth F]	COPPER (II) ION Cu JPVYNHNXODAKFH-UHFFFAOYSA-N		Interactions Focus chain G [auth A] Focus chain J [auth B] Focus chain M [auth C] Focus chain P [auth D] Focus chain Q [auth E] Focus chain R [auth F] Interactions & Density Focus chain G [auth A] Focus chain J [auth B] Focus chain M [auth C] Focus chain P [auth D] Focus chain Q [auth E] Focus chain R [auth F]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain K [auth B] SDF format, chain L [auth B] SDF format, chain N [auth C] SDF format, chain O [auth C] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain K [auth B] MOL2 format, chain L [auth B] MOL2 format, chain N [auth C] MOL2 format, chain O [auth C] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain K [auth B] mmCIF format, chain L [auth B] mmCIF format, chain N [auth C] mmCIF format, chain O [auth C]	H [auth A] I [auth A] K [auth B] L [auth B] N [auth C] H [auth A], I [auth A], K [auth B], L [auth B], N [auth C], O [auth C]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain H [auth A] Focus chain I [auth A] Focus chain K [auth B] Focus chain L [auth B] Focus chain N [auth C] Focus chain O [auth C] Interactions & Density Focus chain H [auth A] Focus chain I [auth A] Focus chain K [auth B] Focus chain L [auth B] Focus chain N [auth C] Focus chain O [auth C]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.50 Å
R-Value Free: 0.295 (Depositor), 0.305 (DCC)
R-Value Work: 0.268 (Depositor), 0.274 (DCC)
R-Value Observed: 0.271 (Depositor)

Space Group: P 2 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 48.783	α = 90
b = 50.962	β = 90
c = 79.264	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
d*TREK	data reduction
d*TREK	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2020-02-19

Deposition Author(s):

Scheib, K.A.

Horne, W.S.

Revision History (Full details and data files)

Version 1.0: 2020-02-19
Type: Initial release
Version 1.1: 2023-10-11
Changes: Data collection, Database references, Derived calculations, Refinement description
Version 1.2: 2023-11-15
Changes: Data collection, Derived calculations
Version 1.3: 2024-11-13
Changes: Structure summary
