6OE6 | pdb_00006oe6

Structure of a Uncharacterized protein from Leptospira interrogans serogroup Icterohaemorrhagiae serovar Copenhageni (strain Fiocruz L1-130)

PDB DOI: https://doi.org/10.2210/pdb6OE6/pdb

Classification: UNKNOWN FUNCTION
Organism(s): Leptospira interrogans serovar Copenhageni str. Fiocruz L1-130
Expression System: Escherichia coli 'BL21-Gold(DE3)pLysS AG
Mutation(s): No

Deposited: 2019-03-27 Released: 2019-04-17
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free:
0.208 (Depositor), 0.211 (DCC)
R-Value Work:
0.176 (Depositor), 0.180 (DCC)
R-Value Observed:
0.177 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 6OE6

This is version 1.1 of the entry. See complete history.

Literature

Structure of an Uncharacterized protein from Leptospira interrogans serogroup Icterohaemorrhagiae serovar Copenhageni (strain Fiocruz L1-130)

Abendroth, J., Mayclin, S.J., Lorimer, D.D., Horanyi, P.S., Edwards, T.E.

To be published.

Macromolecule Content

Total Structure Weight: 35.11 kDa
Atom Count: 2,064
Modeled Residue Count: 237
Deposited Residue Count: 302
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Uncharacterized protein	A, B	151	Leptospira interrogans serovar Copenhageni str. Fiocruz L1-130	Mutation(s): 0 Gene Names: LIC_12238
UniProt
Find proteins for Q72Q74 (Leptospira interrogans serogroup Icterohaemorrhagiae serovar copenhageni (strain Fiocruz L1-130)) Explore Q72Q74 Go to UniProtKB: Q72Q74
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q72Q74
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
FMT Query on FMT Download:Ideal Coordinates CCD File SDF format, chain F [auth B] SDF format, chain D [auth A] MOL2 format, chain F [auth B] MOL2 format, chain D [auth A] mmCIF format, chain F [auth B] mmCIF format, chain D [auth A]	D [auth A], F [auth B]	FORMIC ACID C H₂ O₂ BDAGIHXWWSANSR-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain F [auth B] Interactions & Density Focus chain D [auth A] Focus chain F [auth B]
NA Query on NA Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain C [auth A] MOL2 format, chain E [auth A] MOL2 format, chain C [auth A] mmCIF format, chain E [auth A] mmCIF format, chain C [auth A]	C [auth A], E [auth A]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain E [auth A] Interactions & Density Focus chain C [auth A] Focus chain E [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free: 0.208 (Depositor), 0.211 (DCC)
R-Value Work: 0.176 (Depositor), 0.180 (DCC)
R-Value Observed: 0.177 (Depositor)

Diffraction Data:

Space Group: P 3₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 50.63	α = 90
b = 50.63	β = 90
c = 99.48	γ = 120

Software Package:

Software Name	Purpose
XDS	data reduction
XSCALE	data scaling
PHENIX	refinement
PDB_EXTRACT	data extraction
PHASER	phasing
PARROT	phasing
Coot	model building

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2019-04-17

Deposition Author(s):

Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Revision History (Full details and data files)

Version 1.0: 2019-04-17
Type: Initial release
Version 1.1: 2024-03-13
Changes: Data collection, Database references, Derived calculations
