6O73

Crystal structure of apo Csm1-Csm4 cassette


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.00 Å
  • R-Value Free: 0.293
  • R-Value Work: 0.245
  • R-Value Observed: 0.250

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report

Currently 6O73 does not have a validation slider image.


This is version 1.2 of the entry. See complete history


Literature

Second Messenger cA4Formation within the Composite Csm1 Palm Pocket of Type III-A CRISPR-Cas Csm Complex and Its Release Path.

Jia, N.Jones, R.Sukenick, G.Patel, D.J.

(2019) Mol Cell 75: 933-943.e6

  • DOI: https://doi.org/10.1016/j.molcel.2019.06.013
  • Primary Citation of Related Structures:
    6O73, 6O74, 6O75, 6O78, 6O79, 6O7B, 6O7D, 6O7E, 6O7H, 6O7I

  • PubMed Abstract:

    Target RNA binding to crRNA-bound type III-A CRISPR-Cas multi-subunit Csm surveillance complexes activates cyclic-oligoadenylate (cA n ) formation from ATP subunits positioned within the composite pair of Palm domain pockets of the Csm1 subunit. The generated cA n second messenger in turn targets the CARF domain of trans-acting RNase Csm6, triggering its HEPN domain-based RNase activity. We have undertaken cryo-EM studies on multi-subunit Thermococcus onnurineus Csm effector ternary complexes, as well as X-ray studies on Csm1-Csm4 cassette, both bound to substrate (AMPPNP), intermediates (pppA n ), and products (cA n ), to decipher mechanistic aspects of cA n formation and release. A network of intermolecular hydrogen bond alignments accounts for the observed adenosine specificity, with ligand positioning dictating formation of linear pppA n intermediates and subsequent cA n formation by cyclization. We combine our structural results with published functional studies to highlight mechanistic insights into the role of the Csm effector complex in mediating the cA n signaling pathway.


  • Organizational Affiliation

    Structural Biology Program Memorial Sloan Kettering Cancer Center, New York, NY 10065, USA. Electronic address: jian@mskcc.org.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Csm1791Thermococcus onnurineusMutation(s): 0
Gene Names: TON_0893
EC: 3.1 (PDB Primary Data), 2.7.7 (PDB Primary Data)
UniProt
Find proteins for B6YWB8 (Thermococcus onnurineus (strain NA1))
Explore B6YWB8
Go to UniProtKB:  B6YWB8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB6YWB8
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Csm4289Thermococcus onnurineusMutation(s): 0
Gene Names: TON_0896
UniProt
Find proteins for B6YWC1 (Thermococcus onnurineus (strain NA1))
Explore B6YWC1
Go to UniProtKB:  B6YWC1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB6YWC1
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
NI
Query on NI

Download Ideal Coordinates CCD File
C [auth A]NICKEL (II) ION
Ni
VEQPNABPJHWNSG-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.00 Å
  • R-Value Free: 0.293
  • R-Value Work: 0.245
  • R-Value Observed: 0.250
  • Space Group: P 65 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 154.284α = 90
b = 154.284β = 90
c = 182.418γ = 120
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data reduction
HKL-2000data scaling
PHENIXphasing

Structure Validation

View Full Validation Report

Currently 6O73 does not have a validation slider image.



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2019-07-31
    Type: Initial release
  • Version 1.1: 2019-09-18
    Changes: Data collection, Database references
  • Version 1.2: 2023-10-11
    Changes: Data collection, Database references, Refinement description
