Crystal structure of murine DHX37 in complex with RNA

Experimental Data Snapshot

  • Resolution: 2.88 Å
  • R-Value Free: 0.295
  • R-Value Work: 0.270
  • R-Value Observed: 0.272

wwPDB Validation   3D Report Full Report

This is version 1.2 of the entry. See complete history


Molecular mechanism of the RNA helicase DHX37 and its activation by UTP14A in ribosome biogenesis.

Boneberg, F.M.Brandmann, T.Kobel, L.van den Heuvel, J.Bargsten, K.Bammert, L.Kutay, U.Jinek, M.

(2019) RNA 25: 685-701

  • DOI: https://doi.org/10.1261/rna.069609.118
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    Eukaryotic ribosome biogenesis is a highly orchestrated process involving numerous assembly factors including ATP-dependent RNA helicases. The DEAH helicase DHX37 (Dhr1 in yeast) is activated by the ribosome biogenesis factor UTP14A to facilitate maturation of the small ribosomal subunit. We report the crystal structure of DHX37 in complex with single-stranded RNA, revealing a canonical DEAH ATPase/helicase architecture complemented by a structurally unique carboxy-terminal domain (CTD). Structural comparisons of the nucleotide-free DHX37-RNA complex with DEAH helicases bound to RNA and ATP analogs reveal conformational changes resulting in a register shift in the bound RNA, suggesting a mechanism for ATP-dependent 3'-5' RNA translocation. We further show that a conserved sequence motif in UTP14A interacts with and activates DHX37 by stimulating its ATPase activity and enhancing RNA binding. In turn, the CTD of DHX37 is required, but not sufficient, for interaction with UTP14A in vitro and is essential for ribosome biogenesis in vivo. Together, these results shed light on the mechanism of DHX37 and the function of UTP14A in controlling its recruitment and activity during ribosome biogenesis.

  • Organizational Affiliation

    Department of Biochemistry, University of Zurich, CH-8057 Zurich, Switzerland.


Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
DEAH (Asp-Glu-Ala-His) box polypeptide 37
A, B
975Mus musculusMutation(s): 0
Gene Names: Dhx37
UniProt & NIH Common Fund Data Resources
Find proteins for Q6NZL1 (Mus musculus)
Explore Q6NZL1
Go to UniProtKB:  Q6NZL1
IMPC:  MGI:3028576
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6NZL1
Sequence Annotations
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains LengthOrganismImage
C, D
10synthetic construct
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 2.88 Å
  • R-Value Free: 0.295
  • R-Value Work: 0.270
  • R-Value Observed: 0.272
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 83.829α = 90
b = 137.593β = 93.34
c = 94.225γ = 90
Software Package:
Software NamePurpose
XDSdata reduction
XDSdata scaling

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
Swiss National Science FoundationSwitzerlandNCCR RNA & Disease

Revision History  (Full details and data files)

  • Version 1.0: 2019-04-17
    Type: Initial release
  • Version 1.1: 2019-05-29
    Changes: Data collection, Database references
  • Version 1.2: 2024-03-13
    Changes: Data collection, Database references
