6NST | pdb_00006nst

Crystal structure of branched chain amino acid aminotransferase from Pseudomonas aeruginosa

PDB DOI: https://doi.org/10.2210/pdb6NST/pdb

Classification: TRANSFERASE
Organism(s): Pseudomonas aeruginosa PAO1
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2019-01-25 Released: 2019-02-06
Deposition Author(s): Chang, C., Skarina, T., Savshenko, A., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.14 Å
R-Value Free:
0.253 (Depositor), 0.253 (DCC)
R-Value Work:
0.195 (Depositor), 0.195 (DCC)
R-Value Observed:
0.197 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6NST

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of branched chain amino acid aminotransferase from Pseudomonas aeruginosa

Chang, C., Skarina, T., Savshenko, A., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

To be published.

Macromolecule Content

Total Structure Weight: 205.49 kDa
Atom Count: 14,476
Modeled Residue Count: 1,796
Deposited Residue Count: 1,842
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Branched-chain-amino-acid aminotransferase	A, B, C, D, E A, B, C, D, E, F	307	Pseudomonas aeruginosa PAO1	Mutation(s): 1 Gene Names: ilvE, PA5013 EC: 2.6.1.42
UniProt
Find proteins for O86428 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1)) Explore O86428 Go to UniProtKB: O86428
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	O86428
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain L [auth F] SDF format, chain K [auth E] SDF format, chain J [auth D] SDF format, chain I [auth C] SDF format, chain H [auth B] SDF format, chain G [auth A] MOL2 format, chain L [auth F] MOL2 format, chain K [auth E] MOL2 format, chain J [auth D] MOL2 format, chain I [auth C] MOL2 format, chain H [auth B] MOL2 format, chain G [auth A] mmCIF format, chain L [auth F] mmCIF format, chain K [auth E] mmCIF format, chain J [auth D] mmCIF format, chain I [auth C] mmCIF format, chain H [auth B] mmCIF format, chain G [auth A]	G [auth A] H [auth B] I [auth C] J [auth D] K [auth E] G [auth A], H [auth B], I [auth C], J [auth D], K [auth E], L [auth F]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain G [auth A] Focus chain H [auth B] Focus chain I [auth C] Focus chain J [auth D] Focus chain K [auth E] Focus chain L [auth F] Interactions & Density Focus chain G [auth A] Focus chain H [auth B] Focus chain I [auth C] Focus chain J [auth D] Focus chain K [auth E] Focus chain L [auth F]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.14 Å
R-Value Free: 0.253 (Depositor), 0.253 (DCC)
R-Value Work: 0.195 (Depositor), 0.195 (DCC)
R-Value Observed: 0.197 (Depositor)

Diffraction Data:

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 85.837	α = 90
b = 129.636	β = 114.25
c = 85.787	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
SCALEPACK	data scaling
PDB_EXTRACT	data extraction
HKL-3000	data reduction
HKL-3000	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2019-02-06

Deposition Author(s):

Center for Structural Genomics of Infectious Diseases (CSGID)

Revision History (Full details and data files)

Version 1.0: 2019-02-06
Type: Initial release
Version 1.1: 2023-10-11
Changes: Data collection, Database references, Refinement description
