ADP bound to K46bE mutant ATP-grasp fold of Blastocystis hominis succinyl-CoA synthetase

Experimental Data Snapshot

  • Resolution: 2.44 Å
  • R-Value Free: 0.289
  • R-Value Work: 0.265
  • R-Value Observed: 0.266

wwPDB Validation   3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history


ATP-specificity of succinyl-CoA synthetase from Blastocystis hominis.

Huang, J.Nguyen, V.H.Hamblin, K.A.Maytum, R.van der Giezen, M.Fraser, M.E.

(2019) Acta Crystallogr D Struct Biol 75: 647-659

  • DOI: https://doi.org/10.1107/S2059798319007976
  • Primary Citation of Related Structures:
    6NO0, 6NO1, 6NO2, 6NO3, 6NO4, 6NO5, 6NO6

  • PubMed Abstract:

    Succinyl-CoA synthetase (SCS) catalyzes the only step of the tricarboxylic acid cycle that leads to substrate-level phosphorylation. Some forms of SCS are specific for ADP/ATP or for GDP/GTP, while others can bind all of these nucleotides, generally with different affinities. The theory of `gatekeeper' residues has been proposed to explain the nucleotide-specificity. Gatekeeper residues lie outside the binding site and create specific electrostatic interactions with incoming nucleotides to determine whether the nucleotides can enter the binding site. To test this theory, the crystal structure of the nucleotide-binding domain in complex with Mg 2+ -ADP was determined, as well as the structures of four proteins with single mutations, K46βE, K114βD, V113βL and L227βF, and one with two mutations, K46βE/K114βD. The crystal structures show that the enzyme is specific for ADP/ATP because of interactions between the nucleotide and the binding site. Nucleotide-specificity is provided by hydrogen-bonding interactions between the adenine base and Gln20β, Gly111β and Val113β. The O atom of the side chain of Gln20β interacts with N6 of ADP, while the side-chain N atom interacts with the carbonyl O atom of Gly111β. It is the different conformations of the backbone at Gln20β, of the side chain of Gln20β and of the linker that make the enzyme ATP-specific. This linker connects the two subdomains of the ATP-grasp fold and interacts differently with adenine and guanine bases. The mutant proteins have similar conformations, although the L227βF mutant shows structural changes that disrupt the binding site for the magnesium ion. Although the K46βE/K114βD double mutant of Blastocystis hominis SCS binds GTP better than ATP according to kinetic assays, only the complex with Mg 2+ -ADP was obtained.

  • Organizational Affiliation

    Department of Biological Sciences, University of Calgary, 2500 University Drive NW, Calgary, Alberta T2N 1N4, Canada.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Succinate--CoA ligase [ADP-forming] subunit beta
A, B
250Blastocystis sp. ATCC 50177/Nand IIMutation(s): 1
Gene Names: SCSb
Find proteins for B3FHP0 (Blastocystis sp. subtype 1 (strain ATCC 50177 / NandII))
Explore B3FHP0
Go to UniProtKB:  B3FHP0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB3FHP0
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 2.44 Å
  • R-Value Free: 0.289
  • R-Value Work: 0.265
  • R-Value Observed: 0.266
  • Space Group: P 21 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 80.129α = 90
b = 96.681β = 90
c = 69.235γ = 90
Software Package:
Software NamePurpose
xia2data scaling
PDB_EXTRACTdata extraction
xia2data reduction

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
Natural Sciences and Engineering Research Council (NSERC, Canada)Canada222915-2013

Revision History  (Full details and data files)

  • Version 1.0: 2019-07-17
    Type: Initial release
  • Version 1.1: 2019-11-13
    Changes: Database references
  • Version 1.2: 2020-01-08
    Changes: Author supporting evidence
