6NNG

Tubulin-RB3_SLD-TTL in complex with compound DJ95


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.397 Å
  • R-Value Free: 0.227
  • R-Value Work: 0.192

wwPDB Validation 3D Report Full Report


This is version 1.0 of the entry. See complete history

Literature

Colchicine Binding Site Agent DJ95 Overcomes Drug Resistance and Exhibits Antitumor Efficacy.

Arnst, K.E.Wang, Y.Lei, Z.N.Hwang, D.J.Kumar, G.Ma, D.Parke, D.N.Chen, Q.Yang, J.White, S.W.Seagroves, T.N.Chen, Z.S.Miller, D.D.Li, W.

(2019) Mol.Pharmacol. 96: 73-89

  • DOI: 10.1124/mol.118.114801

  • PubMed Abstract:
  • Interfering with microtubule dynamics is a well-established strategy in cancer treatment; however, many microtubule-targeting agents are associated with drug resistance and adverse effects. Substantial evidence points to ATP-binding cassette (ABC) tr ...

    Interfering with microtubule dynamics is a well-established strategy in cancer treatment; however, many microtubule-targeting agents are associated with drug resistance and adverse effects. Substantial evidence points to ATP-binding cassette (ABC) transporters as critical players in the development of resistance. Herein, we demonstrate the efficacy of DJ95 (2-(1 H -indol-6-yl)-4-(3,4,5-trimethoxyphenyl)-1 H -imidazo[4,5- c ]pyridine), a novel tubulin inhibitor, in a variety of cancer cell lines, including malignant melanomas, drug-selected resistant cell lines, specific ABC transporter-overexpressing cell lines, and the National Cancer Institute 60 cell line panel. DJ95 treatment inhibited cancer cell migration, caused morphologic changes to the microtubule network foundation, and severely disrupted mitotic spindle formation of mitotic cells. The high-resolution crystal structure of DJ95 in complex with tubulin protein and the detailed molecular interactions confirmed its direct binding to the colchicine site. In vitro pharmacological screening of DJ95 using SafetyScreen44 (Eurofins Cerep-Panlabs) revealed no significant off-target interactions, and pharmacokinetic analysis showed that DJ95 was maintained at therapeutically relevant plasma concentrations for up to 24 hours in mice. In an A375 xenograft model in nude mice, DJ95 inhibited tumor growth and disrupted tumor vasculature in xenograft tumors. These results demonstrate that DJ95 is potent against a variety of cell lines, demonstrated greater potency to ABC transporter-overexpressing cell lines than existing tubulin inhibitors, directly targets the colchicine binding domain, exhibits significant antitumor efficacy, and demonstrates vascular-disrupting properties. Collectively, these data suggest that DJ95 has great potential as a cancer therapeutic, particularly for multidrug resistance phenotypes, and warrants further development. SIGNIFICANCE STATEMENT: Paclitaxel is a widely used tubulin inhibitor for cancer therapy, but its clinical efficacy is often limited by the development of multidrug resistance. In this study, we reported the preclinical characterization of a new tubulin inhibitor DJ95, and demonstrated its abilities to overcome paclitaxel resistance, disrupt tumor vasculature, and exhibit significant antitumor efficacy.


    Organizational Affiliation

    Department of Pharmaceutical Sciences, College of Pharmacy (K.E.A., D.-J.H., D.M., D.D.M., W.L.), and Department of Pathology (D.N.P., T.N.S.), the University of Tennessee Health Science Center, Memphis, Tennessee; State Key Laboratory of Biotherapy and Cancer Center, Collaborative Innovation Center of Biotherapy (Y.W., Q.C., J.Y.), and Department of Respiratory Medicine (Y.W.), West China Hospital, Sichuan University, Chengdu, China; Department of Pharmaceutical Sciences, College of Pharmacy and Health Sciences, St. John's University, Queens, New York (Z.-N.L., Z.-S.C.); and Department of Structural Biology, St. Jude Children's Research Hospital, Memphis, Tennessee (G.K., S.W.W.).,Department of Pharmaceutical Sciences, College of Pharmacy (K.E.A., D.-J.H., D.M., D.D.M., W.L.), and Department of Pathology (D.N.P., T.N.S.), the University of Tennessee Health Science Center, Memphis, Tennessee; State Key Laboratory of Biotherapy and Cancer Center, Collaborative Innovation Center of Biotherapy (Y.W., Q.C., J.Y.), and Department of Respiratory Medicine (Y.W.), West China Hospital, Sichuan University, Chengdu, China; Department of Pharmaceutical Sciences, College of Pharmacy and Health Sciences, St. John's University, Queens, New York (Z.-N.L., Z.-S.C.); and Department of Structural Biology, St. Jude Children's Research Hospital, Memphis, Tennessee (G.K., S.W.W.) wli@uthsc.edu.,Department of Pharmaceutical Sciences, College of Pharmacy (K.E.A., D.-J.H., D.M., D.D.M., W.L.), and Department of Pathology (D.N.P., T.N.S.), the University of Tennessee Health Science Center, Memphis, Tennessee; State Key Laboratory of Biotherapy and Cancer Center, Collaborative Innovation Center of Biotherapy (Y.W., Q.C., J.Y.), and Department of Respiratory Medicine (Y.W.), West China Hospital, Sichuan University, Chengdu, China; Department of Pharmaceutical Sciences, College of Pharmacy and Health Sciences, St. John's University, Queens, New York (Z.-N.L., Z.-S.C.); and Department of Structural Biology, St. Jude Children's Research Hospital, Memphis, Tennessee (G.K., S.W.W.) dmiller@uthsc.edu.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Tubulin alpha-1B chain
A, C
450Sus scrofaMutation(s): 0
Gene Names: TUBA1B
Find proteins for Q2XVP4 (Sus scrofa)
Go to Gene View: TUBA1B
Go to UniProtKB:  Q2XVP4
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Tubulin beta-2B chain
B, D
445Sus scrofaMutation(s): 0
Gene Names: TUBB2B
Find proteins for A0A287AGU7 (Sus scrofa)
Go to Gene View: TUBB2B
Go to UniProtKB:  A0A287AGU7
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetails
Stathmin-4
E
143Homo sapiensMutation(s): 0
Gene Names: STMN4
Find proteins for Q9H169 (Homo sapiens)
Go to Gene View: STMN4
Go to UniProtKB:  Q9H169
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetails
Tubulin Tyrosine Ligase
F
384Gallus gallusMutation(s): 0
Gene Names: TTL
Find proteins for E1BQ43 (Gallus gallus)
Go to Gene View: TTL
Go to UniProtKB:  E1BQ43
Small Molecules
Ligands 7 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
GDP
Query on GDP

Download SDF File
Download CCD File
B
GUANOSINE-5'-DIPHOSPHATE
C10 H15 N5 O11 P2
QGWNDRXFNXRZMB-UUOKFMHZSA-N
 Ligand Interaction
GTP
Query on GTP

Download SDF File
Download CCD File
A, C, D
GUANOSINE-5'-TRIPHOSPHATE
C10 H16 N5 O14 P3
XKMLYUALXHKNFT-UUOKFMHZSA-N
 Ligand Interaction
CA
Query on CA

Download SDF File
Download CCD File
A, C
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
 Ligand Interaction
MG
Query on MG

Download SDF File
Download CCD File
A, B, C, F
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
 Ligand Interaction
DJ9
Query on DJ9

Download SDF File
Download CCD File
B
2-(1H-indol-6-yl)-4-(3,4,5-trimethoxyphenyl)-1H-imidazo[4,5-c]pyridine
C23 H20 N4 O3
SQSZRGOISCZCTQ-UHFFFAOYSA-N
 Ligand Interaction
MES
Query on MES

Download SDF File
Download CCD File
B
2-(N-MORPHOLINO)-ETHANESULFONIC ACID
C6 H13 N O4 S
SXGZJKUKBWWHRA-UHFFFAOYSA-N
 Ligand Interaction
ACP
Query on ACP

Download SDF File
Download CCD File
F
PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER
ADENOSINE-5'-[BETA, GAMMA-METHYLENE]TRIPHOSPHATE
C11 H18 N5 O12 P3
UFZTZBNSLXELAL-IOSLPCCCSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.397 Å
  • R-Value Free: 0.227
  • R-Value Work: 0.192
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 105.418α = 90.00
b = 157.979β = 90.00
c = 182.840γ = 90.00
Software Package:
Software NamePurpose
PDB_EXTRACTdata extraction
PHENIXrefinement
HKL-2000data scaling

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Cancer InstituteUnited StatesR01CA148706

Revision History

  • Version 1.0: 2019-07-10
    Type: Initial release
