6NMG

Crystal Structure of Rat Ric-8A G alpha binding domain


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.275
  • R-Value Work: 0.227
  • R-Value Observed: 0.228

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Structure, Function, and Dynamics of the G alpha Binding Domain of Ric-8A.

Zeng, B.Mou, T.C.Doukov, T.I.Steiner, A.Yu, W.Papasergi-Scott, M.Tall, G.G.Hagn, F.Sprang, S.R.

(2019) Structure 27: 1137-1147.e5

  • DOI: 10.1016/j.str.2019.04.013
  • Primary Citation of Related Structures:
    6NMG, 6NMJ

  • PubMed Abstract:
  • Ric-8A is a 530-amino acid cytoplasmic molecular chaperone and guanine nucleotide exchange factor (GEF) for i, q, and 12/13 classes of heterortrimeric G protein alpha subunits (Gα). We report the 2.2-Å crystal structure of the Ric-8A Gα-binding domain with GEF activity, residues 1-452, and is phosphorylated at Ser435 and Thr440 ...

    Ric-8A is a 530-amino acid cytoplasmic molecular chaperone and guanine nucleotide exchange factor (GEF) for i, q, and 12/13 classes of heterortrimeric G protein alpha subunits (Gα). We report the 2.2-Å crystal structure of the Ric-8A Gα-binding domain with GEF activity, residues 1-452, and is phosphorylated at Ser435 and Thr440. Residues 1-429 adopt a superhelical fold comprised of Armadillo (ARM) and HEAT repeats, and the C terminus is disordered. One of the phosphorylated residues potentially binds to a basic cluster in an ARM motif. Amino acid sequence conservation and published hydrogen-deuterium exchange data indicate repeats 3 through 6 to be a putative Gα-binding surface. Normal mode modeling of small-angle X-ray scattering data indicates that phosphorylation induces relative rotation between repeats 1-4, 5-6, and 7-9. 2D 1 H- 15 N-TROSY spectra of [ 2 H, 15 N]-labeled Gαi1 in the presence of R452 reveals chemical shift perturbations of the C terminus and Gαi1 residues involved in nucleotide binding.


    Organizational Affiliation

    Graduate Program in Biochemistry and Biophysics, University of Montana, Missoula, MT 59812, USA; Center for Biomolecular Structure and Dynamics, University of Montana, Missoula, MT 59812, USA; Division of Biological Sciences, University of Montana, Missoula, MT 59812, USA. Electronic address: stephen.sprang@umontana.edu.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Resistance to inhibitors of cholinesterase 8 homolog A (C. elegans)AB453Rattus norvegicusMutation(s): 1
Gene Names: Ric8arCG_48458
Find proteins for B1H241 (Rattus norvegicus)
Explore B1H241
Go to UniProtKB:  B1H241
Protein Feature View
Expand
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download CCD File
A, B
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.275
  • R-Value Work: 0.227
  • R-Value Observed: 0.228
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 67.045α = 90
b = 103.645β = 90
c = 141.537γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
pointlessdata scaling
SHELXDphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United States5R01GM105993
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesP20GM103546

Revision History

  • Version 1.0: 2019-06-26
    Type: Initial release
  • Version 1.1: 2019-09-25
    Changes: Data collection, Database references
  • Version 1.2: 2020-01-01
    Changes: Author supporting evidence
