6NM9

CryoEM structure of the LbCas12a-crRNA-AcrVA4 dimer


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.38 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report


This is version 1.0 of the entry. See complete history

Literature

Structural Basis for the Inhibition of CRISPR-Cas12a by Anti-CRISPR Proteins.

Zhang, H.Li, Z.Daczkowski, C.M.Gabel, C.Mesecar, A.D.Chang, L.

(2019) Cell Host Microbe --: --

  • DOI: 10.1016/j.chom.2019.05.004
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • CRISPR-Cas12a (Cpf1), a type V CRISPR-associated nuclease, provides bacterial immunity against bacteriophages and plasmids but also serves as a tool for genome editing. Foreign nucleic acids are integrated into the CRISPR locus, prompting transcripti ...

    CRISPR-Cas12a (Cpf1), a type V CRISPR-associated nuclease, provides bacterial immunity against bacteriophages and plasmids but also serves as a tool for genome editing. Foreign nucleic acids are integrated into the CRISPR locus, prompting transcription of CRISPR RNAs (crRNAs) that guide Cas12a cleavage of foreign complementary DNA. However, mobile genetic elements counteract Cas12a with inhibitors, notably type V-A anti-CRISPRs (AcrVAs). We present cryoelectron microscopy structures of Cas12a-crRNA bound to AcrVA1 and AcrVA4 at 3.5 and 3.3 Å resolutions, respectively. AcrVA1 is sandwiched between the recognition (REC) and nuclease (NUC) lobes of Cas12a and inserts into the binding pocket for the protospacer-adjacent motif (PAM), a short DNA sequence guiding Cas12a targeting. AcrVA1 cleaves crRNA in a Cas12a-dependent manner, inactivating Cas12a-crRNA complexes. The AcrVA4 dimer is anchored around the crRNA pseudoknot of Cas12a-crRNA, preventing required conformational changes for crRNA-DNA heteroduplex formation. These results uncover molecular mechanisms for CRISPR-Cas12a inhibition, providing insights into bacteria-phage dynamics.


    Organizational Affiliation

    Department of Biological Sciences, Purdue University, West Lafayette, IN 47907, USA; Department of Biochemistry, Purdue University, West Lafayette, IN 47907, USA; Purdue University Center for Cancer Research, Purdue University, West Lafayette, IN 47907, USA.,Department of Biological Sciences, Purdue University, West Lafayette, IN 47907, USA; Purdue University Center for Cancer Research, Purdue University, West Lafayette, IN 47907, USA. Electronic address: lchang18@purdue.edu.,Department of Biochemistry, Purdue University, West Lafayette, IN 47907, USA.,Department of Biological Sciences, Purdue University, West Lafayette, IN 47907, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure


Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
AcrVA4
A, C
234Moraxella bovoculiMutation(s): 0
Find proteins for A0A0U2APF4 (Moraxella bovoculi)
Go to UniProtKB:  A0A0U2APF4
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Cpf1
B, D
1227Lachnospiraceae bacterium ND2006Mutation(s): 0
Find proteins for A0A182DWE3 (Lachnospiraceae bacterium ND2006)
Go to UniProtKB:  A0A182DWE3
Entity ID: 3
MoleculeChainsLengthOrganism
RNA (25-MER)G,E40Lachnospiraceae bacterium ND2006
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
MG
Query on MG

Download SDF File
Download CCD File
A, B, C, D
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.38 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
Software Package:
Software NamePurpose
PHENIXrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2019-06-12
    Type: Initial release
