6N81

Crystal structure of GII.4 2002 norovirus P domain in complex with cross-reactive human antibody A1227


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.579 Å
  • R-Value Free: 0.211
  • R-Value Work: 0.173

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Sera Antibody Repertoire Analyses Reveal Mechanisms of Broad and Pandemic Strain Neutralizing Responses after Human Norovirus Vaccination.

Lindesmith, L.C.McDaniel, J.R.Changela, A.Verardi, R.Kerr, S.A.Costantini, V.Brewer-Jensen, P.D.Mallory, M.L.Voss, W.N.Boutz, D.R.Blazeck, J.J.Ippolito, G.C.Vinje, J.Kwong, P.D.Georgiou, G.Baric, R.S.

(2019) Immunity 50: 1530-1541.e8

  • DOI: 10.1016/j.immuni.2019.05.007
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Rapidly evolving RNA viruses, such as the GII.4 strain of human norovirus (HuNoV), and their vaccines elicit complex serological responses associated with previous exposure. Specific correlates of protection, moreover, remain poorly understood. Here, ...

    Rapidly evolving RNA viruses, such as the GII.4 strain of human norovirus (HuNoV), and their vaccines elicit complex serological responses associated with previous exposure. Specific correlates of protection, moreover, remain poorly understood. Here, we report the GII.4-serological antibody repertoire-pre- and post-vaccination-and select several antibody clonotypes for epitope and structural analysis. The humoral response was dominated by GII.4-specific antibodies that blocked ancestral strains or by antibodies that bound to divergent genotypes and did not block viral-entry-ligand interactions. However, one antibody, A1431, showed broad blockade toward tested GII.4 strains and neutralized the pandemic GII.P16-GII.4 Sydney strain. Structural mapping revealed conserved epitopes, which were occluded on the virion or partially exposed, allowing for broad blockade with neutralizing activity. Overall, our results provide high-resolution molecular information on humoral immune responses after HuNoV vaccination and demonstrate that infection-derived and vaccine-elicited antibodies can exhibit broad blockade and neutralization against this prevalent human pathogen.


    Organizational Affiliation

    Department of Epidemiology, University of North Carolina, Chapel Hill, NC 27599, USA.,Institute for Cellular and Molecular Biology, University of Texas at Austin, Austin, TX 78712, USA.,Department of Molecular Biosciences, University of Texas at Austin, Austin, TX 78712, USA.,Department of Chemical Engineering, University of Texas at Austin, Austin, TX 78712, USA.,Vaccine Research Center, National Institute of Allergy and Infectious Diseases, National Institutes of Health, Bethesda, MD 20892, USA.,Department of Chemical Engineering, University of Texas at Austin, Austin, TX 78712, USA; Institute for Cellular and Molecular Biology, University of Texas at Austin, Austin, TX 78712, USA; Department of Molecular Biosciences, University of Texas at Austin, Austin, TX 78712, USA. Electronic address: gg@che.utexas.edu.,Department of Epidemiology, University of North Carolina, Chapel Hill, NC 27599, USA. Electronic address: rbaric@email.unc.edu.,Division of Viral Diseases, Centers for Disease Control and Prevention, Atlanta, GA 30333, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Major capsid protein
A, B
309Norovirus Hu/GII.4/Farmington Hills/2004/USAMutation(s): 0
Find proteins for R4I4P2 (Norovirus Hu/GII.4/Farmington Hills/2004/USA)
Go to UniProtKB:  R4I4P2
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
A1227 Fab light chain
D, L
214N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetails
A1227 Fab heavy chain
C, H
236N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.579 Å
  • R-Value Free: 0.211
  • R-Value Work: 0.173
  • Space Group: P 1 21 1
Unit Cell:
Length (Å)Angle (°)
a = 82.602α = 90.00
b = 150.100β = 95.06
c = 117.250γ = 90.00
Software Package:
Software NamePurpose
HKL-2000data reduction
HKL-2000data scaling
PHENIXrefinement
PHENIXphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2019-06-19
    Type: Initial release
  • Version 1.1: 2019-07-03
    Type: Data collection, Database references
