6N36 | pdb_00006n36

Beta-lactamase from Chitinophaga pinensis

• PDB DOI: https://doi.org/10.2210/pdb6N36/pdb

• Classification: LIGASE
• Organism(s): Chitinophaga pinensis DSM 2588
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2018-11-14 Released: 2018-11-28
• Deposition Author(s): Osipiuk, J., Tesar, C., Endres, M., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)
• Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.45 Å
• R-Value Free:
  0.185 (Depositor), 0.191 (DCC)
• R-Value Work:
  0.156 (Depositor), 0.166 (DCC)
• R-Value Observed:
  0.158 (Depositor)

Starting Model: experimental

Literature

Beta-lactamase from Chitinophaga pinensis

Osipiuk, J., Tesar, C., Endres, M., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 30.5 kDa
• Atom Count: 2,391
• Modeled Residue Count: 265
• Deposited Residue Count: 271
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Beta-lactamase	A	271	Chitinophaga pinensis DSM 2588	Mutation(s): 0  Gene Names: Cpin_4572 EC: 3.5.2.6

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
ZN	B [auth A], C [auth A]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N
EDO	D [auth A]	1,2-ETHANEDIOL C2 H6 O2 LYCAIKOWRPUZTN-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.45 Å
• R-Value Free:  0.185 (Depositor), 0.191 (DCC)
• R-Value Work:  0.156 (Depositor), 0.166 (DCC)
• R-Value Observed: 0.158 (Depositor)

Diffraction Data: https://doi.org/10.18430/m36n36

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 40.137	α = 90
b = 79.849	β = 90
c = 85.488	γ = 90

Software Package:

Software Name	Purpose
HKL-3000	data scaling
REFMAC	refinement
PDB_EXTRACT	data extraction
HKL-3000	data reduction
HKL-3000	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2018-11-28
Deposition Author(s): Osipiuk, J., Tesar, C., Endres, M., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	HHSN272201200026C
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	HHSN272201700060C

Revision History

• Version 1.0: 2018-11-28
  Type: Initial release

• Version 1.1: 2019-12-18
  Changes: Author supporting evidence
• Version 1.2: 2023-10-11
  Changes: Data collection, Database references, Derived calculations, Refinement description
