6MSY

Anti-HIV-1 Fab Fab 2G12 + Man4 re-refinement


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.999 Å
  • R-Value Free: 0.242
  • R-Value Work: 0.206

wwPDB Validation 3D Report Full Report


This is version 1.0 of the entry. See complete history

Literature

Dissection of the carbohydrate specificity of the broadly neutralizing anti-HIV-1 antibody 2G12.

Calarese, D.A.Lee, H.K.Huang, C.Y.Best, M.D.Astronomo, R.D.Stanfield, R.L.Katinger, H.Burton, D.R.Wong, C.H.Wilson, I.A.

(2005) Proc. Natl. Acad. Sci. U.S.A. 102: 13372-13377

  • DOI: 10.1073/pnas.0505763102
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Human antibody 2G12 neutralizes a broad range of HIV-1 isolates. Hence, molecular characterization of its epitope, which corresponds to a conserved cluster of oligomannoses on the viral envelope glycoprotein gp120, is a high priority in HIV vaccine d ...

    Human antibody 2G12 neutralizes a broad range of HIV-1 isolates. Hence, molecular characterization of its epitope, which corresponds to a conserved cluster of oligomannoses on the viral envelope glycoprotein gp120, is a high priority in HIV vaccine design. A prior crystal structure of 2G12 in complex with Man(9)GlcNAc(2) highlighted the central importance of the D1 arm in antibody binding. To characterize the specificity of 2G12 more precisely, we performed solution-phase ELISA, carbohydrate microarray analysis, and cocrystallized Fab 2G12 with four different oligomannose derivatives (Man(4), Man(5), Man(7), and Man(8)) that compete with gp120 for binding to 2G12. Our combined studies reveal that 2G12 is capable of binding both the D1 and D3 arms of the Man(9)GlcNAc(2) moiety, which would provide more flexibility to make the required multivalent interactions between the antibody and the gp120 oligomannose cluster than thought previously. These results have important consequences for the design of immunogens to elicit 2G12-like neutralizing antibodies as a component of an HIV vaccine.


    Organizational Affiliation

    Department of Molecular Biology, The Scripps Research Institute, 10550 North Torrey Pines Road, La Jolla, CA 92037, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Fab 2G12, light chain
L
213N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Fab 2g12, heavy chain
H
225N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ACT
Query on ACT

Download SDF File
Download CCD File
H
ACETATE ION
C2 H3 O2
QTBSBXVTEAMEQO-UHFFFAOYSA-M
 Ligand Interaction
MAN
Query on MAN

Download SDF File
Download CCD File
H
ALPHA-D-MANNOSE
C6 H12 O6
WQZGKKKJIJFFOK-PQMKYFCFSA-N
 Ligand Interaction
UNX
Query on UNX

Download SDF File
Download CCD File
H, L
UNKNOWN ATOM OR ION
X
*
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.999 Å
  • R-Value Free: 0.242
  • R-Value Work: 0.206
  • Space Group: C 2 2 2
Unit Cell:
Length (Å)Angle (°)
a = 144.646α = 90.00
b = 148.319β = 90.00
c = 54.604γ = 90.00
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data reduction
PHASERphasing
SCALEPACKdata scaling

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical SciencesUnited StatesGM46192

Revision History

  • Version 1.0: 2018-11-21
    Type: Initial release
