Structure-based Design, Synthesis, and Biological Evaluation of Imidazo[4,5-b]pyridine-2-one based p38 MAP Kinase Inhibitors by scaffold hopping - compound 10

Experimental Data Snapshot

  • Resolution: 2.45 Å
  • R-Value Free: 0.270
  • R-Value Work: 0.213
  • R-Value Observed: 0.216

wwPDB Validation   3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history


Structure-Based Design, Synthesis, and Biological Evaluation of Imidazo[4,5-b]pyridin-2-one-Based p38 MAP Kinase Inhibitors: Part 1.

Kaieda, A.Takahashi, M.Fukuda, H.Okamoto, R.Morimoto, S.Gotoh, M.Miyazaki, T.Hori, Y.Unno, S.Kawamoto, T.Tanaka, T.Itono, S.Takagi, T.Sugimoto, H.Okada, K.Snell, G.Bertsch, R.Nguyen, J.Sang, B.C.Miwatashi, S.

(2019) ChemMedChem 14: 1022-1030

  • DOI: https://doi.org/10.1002/cmdc.201900129
  • Primary Citation of Related Structures:
    6M95, 6M9L

  • PubMed Abstract:

    We identified a lead series of p38 mitogen-activated protein kinase inhibitors using a structure-based design strategy from high-throughput screening of hit compound 1. X-ray crystallography of 1 with the kinase showed an infrequent flip of the peptide bond between Met109 and Gly110, which was considered to lead to high kinase selectivity. Our structure-based design strategy was to conduct scaffold transformation of 1 with maintenance of hydrogen bond interactions with the flipped hinge backbone of the enzyme. In accordance with this strategy, we focused on scaffold transformation to identify imidazo[4,5-b]pyridin-2-one derivatives as potent inhibitors of the p38 MAP kinase. Of the compounds evaluated, 21 was found to be a potent inhibitor of the p38 MAP kinase, lipopolysaccharide-induced tumor necrosis factor-α (TNF-α) production in human monocytic leukemia cells, and TNF-α-induced production of interleukin-8 in human whole blood cells. Herein we describe the discovery of potent and orally bioavailable imidazo[4,5-b]pyridin-2-one-based p38 MAP kinase inhibitors that suppressed cytokine production in a human whole blood cell-based assay.

  • Organizational Affiliation

    Pharmaceutical Research Division, Takeda Pharmaceutical Company Limited, 26-1, Muraoka-higashi 2-chome, Fujisawa, Kanagawa, 251-8555, Japan.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Mitogen-activated protein kinase 14388Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for Q16539 (Homo sapiens)
Explore Q16539
Go to UniProtKB:  Q16539
GTEx:  ENSG00000112062
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ16539
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
J9G (Subject of Investigation/LOI)
Query on J9G

Download Ideal Coordinates CCD File
B [auth A]3-benzyl-6-[(2,4-difluorophenyl)amino]-1,3-dihydro-2H-imidazo[4,5-b]pyridin-2-one
C19 H14 F2 N4 O
Experimental Data & Validation

Experimental Data

  • Resolution: 2.45 Å
  • R-Value Free: 0.270
  • R-Value Work: 0.213
  • R-Value Observed: 0.216
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 68.674α = 90
b = 71.046β = 90
c = 74.562γ = 90
Software Package:
Software NamePurpose
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2019-04-17
    Type: Initial release
  • Version 1.1: 2019-05-29
    Changes: Data collection, Database references
  • Version 1.2: 2024-03-13
    Changes: Data collection, Database references
