6M1K

USP7 in complex with a novel inhibitor


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.25 Å
  • R-Value Free: 0.269
  • R-Value Work: 0.233
  • R-Value Observed: 0.235

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

N-benzylpiperidinol derivatives as novel USP7 inhibitors: Structure-activity relationships and X-ray crystallographic studies.

Li, M.Liu, S.Chen, H.Zhou, X.Zhou, J.Zhou, S.Yuan, H.Xu, Q.L.Liu, J.Cheng, K.Sun, H.Wang, Y.Chen, C.Wen, X.

(2020) Eur J Med Chem 199: 112279-112279

  • DOI: https://doi.org/10.1016/j.ejmech.2020.112279
  • Primary Citation of Related Structures:
    6M1K

  • PubMed Abstract:

    USP7 as a deubiquitinase plays important roles in regulating the stability of some oncoproteins including MDM2 and DNMT1, and thus represents a potential anticancer target. Through comparative analysis of USP7 co-crystal structures in complex with the reported piperidinol inhibitors, we noticed that the USP7 Phe409 sub-site might have good adaptability to the ligands. Based on this observation, 55 N-aromatic and N-benzyl piperidinol derivatives were designed, synthesized and biologically evaluated, among which compound L55 was identified as a highly selective and potent USP7 inhibitor (IC 50  = 40.8 nM, K D  = 78.3 nM). X-ray crystallographic studies revealed that L55 bound to USP7 with a new pose that was very different from the previously reported inhibitors. The results of cellular assays showed that L55 had strong antitumor activity against LNCaP (IC 50  = 29.6 nM) and RS4; 11 (IC 50  = 41.6 nM) cells, probably through inducing cell death and restricting G0/G1 and S phases. Moreover, L55 dose-dependently reduced the protein levels of MDM2 and DNMT1 and increased the protein levels of p53 and p21. These findings could have valuable implications for designing novel structural classes of USP7 inhibitors.


  • Organizational Affiliation

    Jiangsu Key Laboratory of Drug Discovery for Metabolic Disease, State Key Laboratory of Natural Medicines, China Pharmaceutical University, Nanjing, 210009, China.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Ubiquitin carboxyl-terminal hydrolase 7
A, B
347Homo sapiensMutation(s): 0
Gene Names: USP7HAUSP
EC: 3.4.19.12
UniProt & NIH Common Fund Data Resources
Find proteins for Q93009 (Homo sapiens)
Explore Q93009
Go to UniProtKB:  Q93009
PHAROS:  Q93009
GTEx:  ENSG00000187555
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ93009
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
EZF (Subject of Investigation/LOI)
Query on EZF

Download Ideal Coordinates CCD File
C [auth A],
D [auth B]
methyl 4-[[4-[[3-[4-(aminomethyl)phenyl]-2-methyl-7-oxidanylidene-pyrazolo[4,3-d]pyrimidin-6-yl]methyl]-4-oxidanyl-piperidin-1-yl]methyl]-3-chloranyl-benzoate
C28 H31 Cl N6 O4
AQZDRXXVFOYWHG-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.25 Å
  • R-Value Free: 0.269
  • R-Value Work: 0.233
  • R-Value Observed: 0.235
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 76.065α = 90
b = 69.2β = 95.56
c = 76.45γ = 90
Software Package:
Software NamePurpose
HKL-2000data scaling
PHENIXrefinement
PDB_EXTRACTdata extraction
HKL-2000data reduction
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China81773584

Revision History  (Full details and data files)

  • Version 1.0: 2021-03-10
    Type: Initial release
  • Version 1.1: 2023-11-29
    Changes: Data collection, Database references, Refinement description
