6KWY

human PA200-20S complex

Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.72 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 2.0 of the entry. See complete history.


Literature

Cryo-EM structures of the human PA200 and PA200-20S complex reveal regulation of proteasome gate opening and two PA200 apertures.

Guan, H., Wang, Y., Yu, T., Huang, Y., Li, M., Saeed, A.F.U.H., Perculija, V., Li, D., Xiao, J., Wang, D., Zhu, P., Ouyang, S.

(2020) PLoS Biol 18: e3000654-e3000654

  • DOI: 10.1371/journal.pbio.3000654
  • Primary Citation of Related Structures:
    6KWX, 6KWY

  • PubMed Abstract:

    • Proteasomes are highly abundant and conserved protease complexes that eliminate unwanted proteins in the cells. As a single-chain ATP-independent nuclear proteasome activator, proteasome activator 200 (PA200) associates with 20S core particle to form proteasome complex that catalyzes polyubiquitin-independent degradation of acetylated histones, thus playing a pivotal role in DNA repair and spermatogenesis ...

    Proteasomes are highly abundant and conserved protease complexes that eliminate unwanted proteins in the cells. As a single-chain ATP-independent nuclear proteasome activator, proteasome activator 200 (PA200) associates with 20S core particle to form proteasome complex that catalyzes polyubiquitin-independent degradation of acetylated histones, thus playing a pivotal role in DNA repair and spermatogenesis. Here, we present cryo-electron microscopy (cryo-EM) structures of the human PA200-20S complex and PA200 at 2.72 Å and 3.75 Å, respectively. PA200 exhibits a dome-like architecture that caps 20S and uses its C-terminal YYA (Tyr-Tyr-Ala) to induce the α-ring rearrangements and partial opening of the 20S gate. Our structural data also indicate that PA200 has two openings formed by numerous positively charged residues that respectively bind (5,6)-bisdiphosphoinositol tetrakisphosphate (5,6[PP]2-InsP4) and inositol hexakisphosphate (InsP6) and are likely to be the gates that lead unfolded proteins through PA200 and into the 20S. Besides, our structural analysis of PA200 found that the bromodomain (BRD)-like (BRDL) domain of PA200 shows considerable sequence variation in comparison to other human BRDs, as it contains only 82 residues because of a short ZA loop, and cannot be classified into any of the eight typical human BRD families. Taken together, the results obtained from this study provide important insights into human PA200-induced 20S gate opening for substrate degradation and the opportunities to explore the mechanism for its recognition of H4 histone in acetylation-mediated proteasomal degradation.

    Organizational Affiliation:

    Laboratory for Marine Biology and Biotechnology, Pilot National Laboratory for Marine Science and Technology (Qingdao), Qingdao, China.



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Proteasome subunit alpha type-2A, O234Homo sapiensMutation(s): 0
Gene Names: PSMA2, HC3, PSC3
EC: 3.4.25.1
UniProt & NIH Common Fund Data Resources
Find proteins for P25787 (Homo sapiens)
Explore P25787
Go to UniProtKB:  P25787
PHAROS:  P25787
GTEx:  ENSG00000106588
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP25787
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
Proteasome subunit alpha type-4B, P261Homo sapiensMutation(s): 0
Gene Names: PSMA4, HC9, PSC9
EC: 3.4.25.1
UniProt & NIH Common Fund Data Resources
Find proteins for P25789 (Homo sapiens)
Explore P25789
Go to UniProtKB:  P25789
PHAROS:  P25789
GTEx:  ENSG00000041357
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP25789
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetailsImage
Proteasome subunit alpha type-7C, Q248Homo sapiensMutation(s): 0
Gene Names: PSMA7, HSPC
EC: 3.4.25.1
UniProt & NIH Common Fund Data Resources
Find proteins for O14818 (Homo sapiens)
Explore O14818
Go to UniProtKB:  O14818
PHAROS:  O14818
GTEx:  ENSG00000101182
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO14818
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetailsImage
Proteasome subunit alpha type-5D, R241Homo sapiensMutation(s): 0
Gene Names: PSMA5
EC: 3.4.25.1
UniProt & NIH Common Fund Data Resources
Find proteins for P28066 (Homo sapiens)
Explore P28066
Go to UniProtKB:  P28066
PHAROS:  P28066
GTEx:  ENSG00000143106
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP28066
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChainsSequence LengthOrganismDetailsImage
Proteasome subunit alpha type-1E, S263Homo sapiensMutation(s): 0
Gene Names: PSMA1, HC2, NU, PROS30, PSC2
EC: 3.4.25.1
UniProt & NIH Common Fund Data Resources
Find proteins for P25786 (Homo sapiens)
Explore P25786
Go to UniProtKB:  P25786
PHAROS:  P25786
GTEx:  ENSG00000129084
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP25786
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChainsSequence LengthOrganismDetailsImage
Proteasome subunit alpha type-3F, T255Homo sapiensMutation(s): 0
Gene Names: PSMA3, HC8, PSC8
EC: 3.4.25.1
UniProt & NIH Common Fund Data Resources
Find proteins for P25788 (Homo sapiens)
Explore P25788
Go to UniProtKB:  P25788
PHAROS:  P25788
GTEx:  ENSG00000100567
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP25788
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChainsSequence LengthOrganismDetailsImage
Proteasome subunit alpha type-6G, U246Homo sapiensMutation(s): 0
Gene Names: PSMA6, PROS27
EC: 3.4.25.1
UniProt & NIH Common Fund Data Resources
Find proteins for P60900 (Homo sapiens)
Explore P60900
Go to UniProtKB:  P60900
PHAROS:  P60900
GTEx:  ENSG00000100902
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP60900
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChainsSequence LengthOrganismDetailsImage
Proteasome subunit beta type-7H, V277Homo sapiensMutation(s): 0
Gene Names: PSMB7, Z
EC: 3.4.25.1
UniProt & NIH Common Fund Data Resources
Find proteins for Q99436 (Homo sapiens)
Explore Q99436
Go to UniProtKB:  Q99436
PHAROS:  Q99436
GTEx:  ENSG00000136930
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ99436
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChainsSequence LengthOrganismDetailsImage
Proteasome subunit beta type-3I, W205Homo sapiensMutation(s): 0
Gene Names: PSMB3
EC: 3.4.25.1
UniProt & NIH Common Fund Data Resources
Find proteins for P49720 (Homo sapiens)
Explore P49720
Go to UniProtKB:  P49720
PHAROS:  P49720
GTEx:  ENSG00000277791
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP49720
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChainsSequence LengthOrganismDetailsImage
Proteasome subunit beta type-2J, X201Homo sapiensMutation(s): 0
Gene Names: PSMB2
EC: 3.4.25.1
UniProt & NIH Common Fund Data Resources
Find proteins for P49721 (Homo sapiens)
Explore P49721
Go to UniProtKB:  P49721
PHAROS:  P49721
GTEx:  ENSG00000126067
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP49721
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChainsSequence LengthOrganismDetailsImage
Proteasome subunit beta type-5K, Y263Homo sapiensMutation(s): 0
Gene Names: PSMB5, LMPX, MB1, X
EC: 3.4.25.1
UniProt & NIH Common Fund Data Resources
Find proteins for P28074 (Homo sapiens)
Explore P28074
Go to UniProtKB:  P28074
PHAROS:  P28074
GTEx:  ENSG00000100804
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP28074
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 12
MoleculeChainsSequence LengthOrganismDetailsImage
Proteasome subunit beta type-1L, Z241Homo sapiensMutation(s): 0
Gene Names: PSMB1, PSC5
EC: 3.4.25.1
UniProt & NIH Common Fund Data Resources
Find proteins for P20618 (Homo sapiens)
Explore P20618
Go to UniProtKB:  P20618
PHAROS:  P20618
GTEx:  ENSG00000008018
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP20618
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 13
MoleculeChainsSequence LengthOrganismDetailsImage
Proteasome subunit beta type-4M,
AA [auth a]		264Homo sapiensMutation(s): 0
Gene Names: PSMB4, PROS26
EC: 3.4.25.1
UniProt & NIH Common Fund Data Resources
Find proteins for P28070 (Homo sapiens)
Explore P28070
Go to UniProtKB:  P28070
PHAROS:  P28070
GTEx:  ENSG00000159377
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP28070
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 14
MoleculeChainsSequence LengthOrganismDetailsImage
Proteasome subunit beta type-6N,
BA [auth b]		239Homo sapiensMutation(s): 0
Gene Names: PSMB6, LMPY, Y
EC: 3.4.25.1
UniProt & NIH Common Fund Data Resources
Find proteins for P28072 (Homo sapiens)
Explore P28072
Go to UniProtKB:  P28072
PHAROS:  P28072
GTEx:  ENSG00000142507
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP28072
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 15
MoleculeChainsSequence LengthOrganismDetailsImage
Proteasome activator complex subunit 4CA [auth c]1878Homo sapiensMutation(s): 0
Gene Names: PSME4, KIAA0077
UniProt & NIH Common Fund Data Resources
Find proteins for Q14997 (Homo sapiens)
Explore Q14997
Go to UniProtKB:  Q14997
PHAROS:  Q14997
GTEx:  ENSG00000068878
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ14997
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
K0W (Subject of Investigation/LOI)
Query on K0W
Download Ideal Coordinates CCD File
DA [auth c][(1~{S},2~{R},3~{R},4~{S},5~{S},6~{R})-2-[oxidanyl(phosphonooxy)phosphoryl]oxy-3,4,5,6-tetraphosphonooxy-cyclohexyl] phosphono hydrogen phosphate
C6 H20 O30 P8
GXPFHIDIIMSLOF-FTYOSCRSSA-N		 Ligand Interaction
IHP (Subject of Investigation/LOI)
Query on IHP
Download Ideal Coordinates CCD File
EA [auth c]INOSITOL HEXAKISPHOSPHATE
C6 H18 O24 P6
IMQLKJBTEOYOSI-GPIVLXJGSA-N		 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.72 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



View more in-depth experimental data

Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
National Science Foundation (NSF, China)China31770948

Revision History  (Full details and data files)

  • Version 1.0: 2020-04-01
    Type: Initial release
  • Version 2.0: 2020-10-14
    Changes: Advisory, Atomic model, Author supporting evidence, Data collection, Derived calculations, Non-polymer description, Structure summary
