6JXL | pdb_00006jxl

Crystal Structures of Endo-beta-1,4-xylanase II Complexed with Xylotriose

• PDB DOI: https://doi.org/10.2210/pdb6JXL/pdb

• Classification: HYDROLASE
• Organism(s): Trichoderma reesei RUT C-30
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 2019-04-23 Released: 2020-04-29
• Deposition Author(s): Li, Z., Wan, Q.
• Funding Organization(s): National Natural Science Foundation of China

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.30 Å
• R-Value Free:
  0.168 (Depositor), 0.168 (DCC)
• R-Value Work:
  0.152 (Depositor), 0.152 (DCC)
• R-Value Observed:
  0.153 (Depositor)

Starting Model: experimental

Literature

Crystal Structures of Endo-beta-1,4-xylanase II Complexed with Xylotriose

Wan, Q.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 21.27 kDa
• Atom Count: 1,793
• Modeled Residue Count: 189
• Deposited Residue Count: 189
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Endo-1,4-beta-xylanase 2	A	189	Trichoderma reesei RUT C-30	Mutation(s): 1  Gene Names: xyn2 EC: 3.2.1.8
UniProt
Find proteins for P36217 (Hypocrea jecorina (strain ATCC 56765 / BCRC 32924 / NRRL 11460 / Rut C-30)) Explore P36217  Go to UniProtKB:  P36217

Oligosaccharides

Help

Entity ID: 2
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
beta-D-xylopyranose-(1-4)-beta-D-xylopyranose-(1-4)-beta-D-xylopyranose	B	3		N/A
Glycosylation Resources
GlyTouCan: G87429QT GlyCosmos: G87429QT

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
IOD	C [auth A]	IODIDE ION I XMBWDFGMSWQBCA-UHFFFAOYSA-M

Biologically Interesting Molecules (External Reference)

1 Unique

Entity ID: 2
ID	Chains	Name	Type/Class	2D Diagram	3D Interactions
PRD_900117	B	4beta-beta-xylotriose	Oligosaccharide / Metabolism

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.30 Å
• R-Value Free:  0.168 (Depositor), 0.168 (DCC)
• R-Value Work:  0.152 (Depositor), 0.152 (DCC)
• R-Value Observed: 0.153 (Depositor)

Diffraction Data: https://doi.org/10.1073/pnas.1504986112

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 47.54	α = 90
b = 58.969	β = 90
c = 69.502	γ = 90

Software Package:

Software Name	Purpose
XDS	data reduction
XDS	data scaling
PHENIX	refinement
PDB_EXTRACT	data extraction
PHASER	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2020-04-29
Deposition Author(s): Li, Z., Wan, Q.

---

Funding Organization	Location	Grant Number
National Natural Science Foundation of China	China	31670790

Revision History

• Version 1.0: 2020-04-29
  Type: Initial release

• Version 2.0: 2020-07-29
  Type: Remediation
  Reason: Carbohydrate remediation
  Changes: Atomic model, Data collection, Derived calculations, Structure summary
• Version 2.1: 2023-11-22
  Changes: Data collection, Database references, Derived calculations, Refinement description, Structure summary
• Version 2.2: 2025-03-12
  Changes: Database references, Structure summary
