6JR1

Crystal structure of the human nucleosome phased with 16 selenium atoms


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.40 Å
  • R-Value Free: 0.243
  • R-Value Work: 0.209
  • R-Value Observed: 0.210

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Structure determination of the nucleosome core particle by selenium SAD phasing.

Saotome, M.Horikoshi, N.Urano, K.Kujirai, T.Yuzurihara, H.Kurumizaka, H.Kagawa, W.

(2019) Acta Crystallogr D Struct Biol 75: 930-936

  • DOI: https://doi.org/10.1107/S2059798319012713
  • Primary Citation of Related Structures:
    6JR0, 6JR1

  • PubMed Abstract:

    The eukaryotic genome is compacted inside the nucleus of the cell in the form called chromatin. The fundamental unit of chromatin is the nucleosome, which contains four types of histones (H3, H4, H2A and H2B) and approximately 150 base pairs of DNA wrapped around the histone complex. The structure of the nucleosome is highly conserved across several eukaryotic species, and molecular replacement has been the primary phasing method used to solve nucleosome structures by X-ray crystallography. However, there is currently no simple, widely applicable experimental phasing method for the nucleosome. In the present study, it is demonstrated that selenomethionine-incorporated histones H3, H2A and H2B can be reconstituted into nucleosomes and crystallized for structural determination. Unexpectedly, it was found that the nucleosome can be phased with a relatively small number of Se atoms. The structures of nucleosome core particles containing 12 and 16 Se atoms were solved by SAD phasing at 2.5 and 2.4 Å resolution, respectively. The present study demonstrates a simple method for determining nucleosome structures by experimental phasing, which may be particularly useful for noncanonical structures that cannot be solved by molecular replacement.


  • Organizational Affiliation

    Department of Chemistry, Graduate School of Science and Engineering, Meisei University, 2-1-1 Hodokubo, Hino-shi, Tokyo 191-8506, Japan.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Histone H3.1
A, E
139Homo sapiensMutation(s): 0
Gene Names:
UniProt & NIH Common Fund Data Resources
Find proteins for P68431 (Homo sapiens)
Explore P68431
Go to UniProtKB:  P68431
PHAROS:  P68431
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP68431
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Histone H4
B, F
106Homo sapiensMutation(s): 0
Gene Names:
UniProt & NIH Common Fund Data Resources
Find proteins for P62805 (Homo sapiens)
Explore P62805
Go to UniProtKB:  P62805
PHAROS:  P62805
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP62805
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Histone H2A type 1-B/E
C, G
133Homo sapiensMutation(s): 2
Gene Names: HIST1H2ABH2AFMHIST1H2AEH2AFA
UniProt & NIH Common Fund Data Resources
Find proteins for P04908 (Homo sapiens)
Explore P04908
Go to UniProtKB:  P04908
PHAROS:  P04908
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP04908
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Histone H2B type 1-J
D, H
129Homo sapiensMutation(s): 2
Gene Names: HIST1H2BJH2BFR
UniProt & NIH Common Fund Data Resources
Find proteins for P06899 (Homo sapiens)
Explore P06899
Go to UniProtKB:  P06899
PHAROS:  P06899
GTEx:  ENSG00000124635
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP06899
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains LengthOrganismImage
DNA (146-MER)
I, J
146Homo sapiens
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
MN
Query on MN

Download Ideal Coordinates CCD File
M [auth E]
P [auth I]
Q [auth I]
R [auth I]
S [auth J]
M [auth E],
P [auth I],
Q [auth I],
R [auth I],
S [auth J],
T [auth J],
U [auth J],
V [auth J]
MANGANESE (II) ION
Mn
WAEMQWOKJMHJLA-UHFFFAOYSA-N
CL
Query on CL

Download Ideal Coordinates CCD File
K [auth A],
L [auth C],
N [auth E],
O [auth G]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
A, E
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.40 Å
  • R-Value Free: 0.243
  • R-Value Work: 0.209
  • R-Value Observed: 0.210
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 99.461α = 90
b = 108.539β = 90
c = 170.462γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
Aimlessdata scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Japan Society for the Promotion of ScienceJapanJP24570138
Japan Society for the Promotion of ScienceJapanJP26116521
Japan Society for the Promotion of ScienceJapanJP16H01316
Japan Society for the Promotion of ScienceJapanJP18H05534
Japan Society for the Promotion of ScienceJapanJP17H01408
Japan Agency for Medical Research and Development (AMED)JapanJP18am0101076

Revision History  (Full details and data files)

  • Version 1.0: 2019-10-02
    Type: Initial release
  • Version 1.1: 2019-10-23
    Changes: Data collection, Database references
  • Version 1.2: 2024-10-09
    Changes: Data collection, Database references, Derived calculations, Structure summary
