6JMQ

LAT1-CD98hc complex bound to MEM-108 Fab


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.31 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report



Literature

Cryo-EM structure of the human L-type amino acid transporter 1 in complex with glycoprotein CD98hc.

Lee, Y.Wiriyasermkul, P.Jin, C.Quan, L.Ohgaki, R.Okuda, S.Kusakizako, T.Nishizawa, T.Oda, K.Ishitani, R.Yokoyama, T.Nakane, T.Shirouzu, M.Endou, H.Nagamori, S.Kanai, Y.Nureki, O.

(2019) Nat Struct Mol Biol 26: 510-517

  • DOI: 10.1038/s41594-019-0237-7
  • Primary Citation of Related Structures:
    6JMR, 6JMQ

  • PubMed Abstract:
  • The L-type amino acid transporter 1 (LAT1 or SLC7A5) transports large neutral amino acids across the membrane and is crucial for brain drug delivery and tumor growth. LAT1 forms a disulfide-linked heterodimer with CD98 heavy chain (CD98hc, 4F2hc or S ...

    The L-type amino acid transporter 1 (LAT1 or SLC7A5) transports large neutral amino acids across the membrane and is crucial for brain drug delivery and tumor growth. LAT1 forms a disulfide-linked heterodimer with CD98 heavy chain (CD98hc, 4F2hc or SLC3A2), but the mechanism of assembly and amino acid transport are poorly understood. Here we report the cryo-EM structure of the human LAT1-CD98hc heterodimer at 3.3-Å resolution. LAT1 features a canonical Leu T-fold and exhibits an unusual loop structure on transmembrane helix 6, creating an extended cavity that might accommodate bulky amino acids and drugs. CD98hc engages with LAT1 through the extracellular, transmembrane and putative cholesterol-mediated interactions. We also show that two anti-CD98 antibodies recognize distinct, multiple epitopes on CD98hc but not its glycans, explaining their robust reactivities. These results reveal the principles of glycoprotein-solute carrier assembly and provide templates for improving preclinical drugs and antibodies targeting LAT1 or CD98hc.


    Organizational Affiliation

    Department of Biological Sciences, Graduate School of Science, The University of Tokyo, Tokyo, Japan. nureki@bs.s.u-tokyo.ac.jp.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Large neutral amino acids transporter small subunit 1A515Homo sapiensMutation(s): 0
Gene Names: SLC7A5CD98LCLAT1MPE16
Membrane protein
Mpstruc
Group:
TRANSMEMBRANE PROTEINS: ALPHA-HELICAL
Sub Group:
Solute Carrier (SLC) Transporter Superfamily
Protein:
SLC7A5 L-type amino acid transporter LAT1-CD98hc in complex with MEM-108 Fab
Find proteins for Q01650 (Homo sapiens)
Explore Q01650
Go to UniProtKB:  Q01650
NIH Common Fund Data Resources
PHAROS  Q01650
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
4F2 cell-surface antigen heavy chainB631Homo sapiensMutation(s): 0
Gene Names: SLC3A2MDU1
Membrane protein
Mpstruc
Group:
TRANSMEMBRANE PROTEINS: ALPHA-HELICAL
Sub Group:
Solute Carrier (SLC) Transporter Superfamily
Protein:
SLC7A5 L-type amino acid transporter LAT1-CD98hc in complex with MEM-108 Fab
Find proteins for P08195 (Homo sapiens)
Explore P08195
Go to UniProtKB:  P08195
NIH Common Fund Data Resources
PHAROS  P08195
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetailsImage
AntibodyC219Mus musculusMutation(s): 0
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetailsImage
AntibodyD219Mus musculusMutation(s): 0
Protein Feature View
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 5
MoleculeChainsChain Length2D Diagram Glycosylation3D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
E
2 N-Glycosylation Oligosaccharides Interaction
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
CLR
Query on CLR

Download CCD File
A, B
CHOLESTEROL
C27 H46 O
HVYWMOMLDIMFJA-DPAQBDIFSA-N
 Ligand Interaction
NAG
Query on NAG

Download CCD File
B
2-acetamido-2-deoxy-beta-D-glucopyranose
C8 H15 N O6
OVRNDRQMDRJTHS-FMDGEEDCSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.31 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Japan Society for the Promotion of ScienceJapanJP16J07405
Japan Agency for Medical Research and Development (AMED)JapanJP18am0101115

Revision History

  • Version 1.0: 2019-06-19
    Type: Initial release
  • Version 1.1: 2019-11-06
    Changes: Data collection, Other
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Atomic model, Data collection, Derived calculations, Structure summary
