6JHH

Crystal structure of mutant D350A of Pullulanase from Paenibacillus barengoltzii complexed with maltotriose

• PDB DOI:  https://doi.org/10.2210/pdb6JHH/pdb
• Entry: 6JHH supersedes: 5WVS

• Classification: HYDROLASE
• Organism(s): Paenibacillus barengoltzii
• Expression System: Escherichia coli 'BL21-Gold(DE3)pLysS AG
• Mutation(s): No


• Deposited: 2019-02-18 Released: 2019-03-06
• Deposition Author(s): Wu, S.W., Yang, S.Q., Qin, Z., You, X., Huang, P., Jiang, Z.Q.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.02 Å
• R-Value Free: 0.233
• R-Value Work: 0.167
• R-Value Observed: 0.170

Literature

Crystal structure of mutant D350A of Pullulanase from Paenibacillus barengoltzii complexed with maltotriose

Wu, S.W., Yang, S.Q., Qin, Z., You, X., Huang, P., Jiang, Z.Q.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 76.77 kDa
• Atom Count: 5,808
• Modelled Residue Count: 642
• Deposited Residue Count: 675
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Pulullanase	A	675	Paenibacillus barengoltzii	Mutation(s): 0  EC: 3.2.1.41
UniProt
Find proteins for A0A0C5GWS2 (Paenibacillus barengoltzii) Explore A0A0C5GWS2  Go to UniProtKB:  A0A0C5GWS2

Oligosaccharides

Help

Entity ID: 2
Molecule	Chains	Chain Length	2D Diagram	Glycosylation
alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose	B, C, D	3		N/A
Glycosylation Resources
GlyTouCan:  G96370VA GlyCosmos:  G96370VA GlyGen:  G96370VA

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
CA (Subject of Investigation/LOI)	E [auth A], F [auth A], G [auth A]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N

Biologically Interesting Molecules (External Reference) 1 Unique

Entity ID: 2
ID	Chains	Name	Type/Class	2D Diagram	3D Interactions
PRD_900009	B, C, D	alpha-maltotriose	Oligosaccharide / Nutrient		Ligand Interaction

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.02 Å
• R-Value Free: 0.233
• R-Value Work: 0.167
• R-Value Observed: 0.170
• Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 72.822	α = 90
b = 78.803	β = 90
c = 116.348	γ = 90

Software Package:

Software Name	Purpose
HKL-2000	data reduction
HKL-2000	data scaling
PHENIX	phasing
PHENIX	refinement

Structure Validation

Entry History

Deposition Data

• Released Date: 2019-03-06
Deposition Author(s): Wu, S.W., Yang, S.Q., Qin, Z., You, X., Huang, P., Jiang, Z.Q.
• This entry supersedes: 5WVS

Revision History

• Version 1.0: 2019-03-06
  Type: Initial release

• Version 2.0: 2020-07-29
  Type: Remediation
  Reason: Carbohydrate remediation
  Changes: Atomic model, Data collection, Derived calculations, Structure summary
