6J50

RNA polymerase II elongation complex bound with Spt4/5 and foreign DNA, stalled at SHL(-1) of the nucleosome (tilted conformation)


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 4.70 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Structural insight into nucleosome transcription by RNA polymerase II with elongation factors.

Ehara, H.Kujirai, T.Fujino, Y.Shirouzu, M.Kurumizaka, H.Sekine, S.I.

(2019) Science 363: 744-747

  • DOI: https://doi.org/10.1126/science.aav8912
  • Primary Citation of Related Structures:
    6IR9, 6J4W, 6J4X, 6J4Y, 6J4Z, 6J50, 6J51

  • PubMed Abstract:

    RNA polymerase II (RNAPII) transcribes chromosomal DNA that contains multiple nucleosomes. The nucleosome forms transcriptional barriers, and nucleosomal transcription requires several additional factors in vivo. We demonstrate that the transcription elongation factors Elf1 and Spt4/5 cooperatively lower the barriers and increase the RNAPII processivity in the nucleosome. The cryo-electron microscopy structures of the nucleosome-transcribing RNAPII elongation complexes (ECs) reveal that Elf1 and Spt4/5 reshape the EC downstream edge and intervene between RNAPII and the nucleosome. They facilitate RNAPII progression through superhelical location SHL(-1) by adjusting the nucleosome in favor of the forward progression. They suppress pausing at SHL(-5) by preventing the stable RNAPII-nucleosome interaction. Thus, the EC overcomes the nucleosomal barriers while providing a platform for various chromatin functions.


  • Organizational Affiliation

    RIKEN Center for Biosystems Dynamics Research, 1-7-22 Suehiro-cho, Tsurumi-ku, Yokohama 230-0045, Japan.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit1,743Komagataella phaffii GS115Mutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for C4R4Y0 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4R4Y0
Go to UniProtKB:  C4R4Y0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4R4Y0
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit beta1,227Komagataella phaffii GS115Mutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for C4QZQ7 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4QZQ7
Go to UniProtKB:  C4QZQ7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4QZQ7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
RNA polymerase II third largest subunit B44, part of central core304Komagataella phaffii GS115Mutation(s): 0
UniProt
Find proteins for C4R7L2 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4R7L2
Go to UniProtKB:  C4R7L2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4R7L2
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
RNA polymerase II subunit B32186Komagataella phaffii GS115Mutation(s): 0
UniProt
Find proteins for C4R2U9 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4R2U9
Go to UniProtKB:  C4R2U9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4R2U9
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
RNA polymerase subunit ABC27, common to RNA polymerases I, II, and III214Komagataella phaffii GS115Mutation(s): 0
UniProt
Find proteins for C4R3P8 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4R3P8
Go to UniProtKB:  C4R3P8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4R3P8
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
RNA polymerase subunit ABC23, common to RNA polymerases I, II, and III155Komagataella phaffii GS115Mutation(s): 0
UniProt
Find proteins for C4R1V1 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4R1V1
Go to UniProtKB:  C4R1V1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4R1V1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
RNA polymerase II subunit171Komagataella phaffii GS115Mutation(s): 0
UniProt
Find proteins for C4R9A1 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4R9A1
Go to UniProtKB:  C4R9A1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4R9A1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerases I, II, and III subunit RPABC3145Komagataella phaffii GS115Mutation(s): 0
UniProt
Find proteins for C4R273 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4R273
Go to UniProtKB:  C4R273
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4R273
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit115Komagataella phaffii CBS 7435Mutation(s): 0
UniProt
Find proteins for F2QPE6 (Komagataella phaffii (strain ATCC 76273 / CBS 7435 / CECT 11047 / NRRL Y-11430 / Wegner 21-1))
Explore F2QPE6
Go to UniProtKB:  F2QPE6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupF2QPE6
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChains Sequence LengthOrganismDetailsImage
RNA polymerase subunit ABC10-beta, common to RNA polymerases I, II, and III72Komagataella phaffii GS115Mutation(s): 0
UniProt
Find proteins for C4R009 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4R009
Go to UniProtKB:  C4R009
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4R009
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChains Sequence LengthOrganismDetailsImage
RNA polymerase II subunit B12.5118Komagataella phaffii GS115Mutation(s): 0
UniProt
Find proteins for C4R3Z5 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4R3Z5
Go to UniProtKB:  C4R3Z5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4R3Z5
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 12
MoleculeChains Sequence LengthOrganismDetailsImage
RNA polymerase subunit ABC10-alpha72Komagataella phaffii CBS 7435Mutation(s): 0
UniProt
Find proteins for F2QMI1 (Komagataella phaffii (strain ATCC 76273 / CBS 7435 / CECT 11047 / NRRL Y-11430 / Wegner 21-1))
Explore F2QMI1
Go to UniProtKB:  F2QMI1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupF2QMI1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 16
MoleculeChains Sequence LengthOrganismDetailsImage
Transcription elongation factor SPT4P [auth V]108Komagataella phaffii GS115Mutation(s): 0
Gene Names: PAS_chr2-1_0350
UniProt
Find proteins for C4R0E6 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4R0E6
Go to UniProtKB:  C4R0E6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4R0E6
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 17
MoleculeChains Sequence LengthOrganismDetailsImage
Protein that forms a complex with Spt4pQ [auth W]911Komagataella phaffii GS115Mutation(s): 0
Gene Names: PAS_chr3_1136
UniProt
Find proteins for C4R370 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4R370
Go to UniProtKB:  C4R370
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4R370
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 18
MoleculeChains Sequence LengthOrganismDetailsImage
Histone H3.3R [auth a],
V [auth e]
139Homo sapiensMutation(s): 0
Gene Names: H3F3AH3.3AH3F3PP781H3F3BH3.3B
UniProt & NIH Common Fund Data Resources
Find proteins for P84243 (Homo sapiens)
Explore P84243
Go to UniProtKB:  P84243
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP84243
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 19
MoleculeChains Sequence LengthOrganismDetailsImage
Histone H4S [auth b],
W [auth f]
106Homo sapiensMutation(s): 0
Gene Names:
UniProt & NIH Common Fund Data Resources
Find proteins for P62805 (Homo sapiens)
Explore P62805
Go to UniProtKB:  P62805
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP62805
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 20
MoleculeChains Sequence LengthOrganismDetailsImage
Histone H2A type 1-B/ET [auth c],
X [auth g]
133Homo sapiensMutation(s): 0
Gene Names: HIST1H2ABH2AFMHIST1H2AEH2AFA
UniProt & NIH Common Fund Data Resources
Find proteins for P04908 (Homo sapiens)
Explore P04908
Go to UniProtKB:  P04908
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP04908
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 21
MoleculeChains Sequence LengthOrganismDetailsImage
Histone H2B type 1-JU [auth d],
Y [auth h]
129Homo sapiensMutation(s): 0
Gene Names: HIST1H2BJH2BFR
UniProt & NIH Common Fund Data Resources
Find proteins for P06899 (Homo sapiens)
Explore P06899
Go to UniProtKB:  P06899
PHAROS:  P06899
GTEx:  ENSG00000124635
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP06899
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 13
MoleculeChains LengthOrganismImage
RNA (5'-R(P*GP*CP*CP*UP*GP*GP*UP*GP*UP*CP*UP*UP*GP*GP*GP*U)-3')M [auth P]16synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 14
MoleculeChains LengthOrganismImage
DNA (198-MER)N [auth T]198synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 15
MoleculeChains LengthOrganismImage
DNA (198-MER)O [auth N]198synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 22
MoleculeChains LengthOrganismImage
DNA (41-MER)Z [auth 0]41synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 23
MoleculeChains LengthOrganismImage
DNA (41-MER)AA [auth 1]41synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download Ideal Coordinates CCD File
BA [auth A]
CA [auth A]
EA [auth B]
FA [auth C]
GA [auth I]
BA [auth A],
CA [auth A],
EA [auth B],
FA [auth C],
GA [auth I],
HA [auth I],
IA [auth J],
JA [auth L],
KA [auth V]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
MG
Query on MG

Download Ideal Coordinates CCD File
DA [auth A]MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 4.70 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONRELION3.0-beta2

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Japan Society for the Promotion of ScienceJapanJP25116002
Japan Society for the Promotion of ScienceJapanJP15H04344
Japan Agency for Medical Research and Development (AMED)JapanJP18am0101076
Japan Agency for Medical Research and Development (AMED)JapanJP18am0101082
Japan Science and TechnologyJapanJPMJCR16G1
Other governmentJapanRIKEN Dynamic Structural Biology project

Revision History  (Full details and data files)

  • Version 1.0: 2019-02-20
    Type: Initial release
  • Version 1.1: 2019-02-27
    Changes: Data collection, Database references
  • Version 1.2: 2019-11-06
    Changes: Data collection, Other
