6IN2 | pdb_00006in2

Crystal structure of BRD1 in complex with 18-Crown-6

• PDB DOI: https://doi.org/10.2210/pdb6IN2/pdb

• Classification: TRANSCRIPTION
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2018-10-24 Released: 2019-10-30
• Deposition Author(s): Yokoyama, T., Kosaka, Y., Matsumoto, K., Kitakami, R., Nabeshima, Y., Mizuguchi, M.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.75 Å
• R-Value Free:
  0.248 (Depositor), 0.250 (DCC)
• R-Value Work:
  0.208 (Depositor), 0.210 (DCC)
• R-Value Observed:
  0.210 (Depositor)

Literature

Crown Ethers as Transthyretin Amyloidogenesis Inhibitor

Yokoyama, T., Kosaka, Y., Matsumoto, K., Kitakami, R., Nabeshima, Y., Mizuguchi, M.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 15.24 kDa
• Atom Count: 1,127
• Modeled Residue Count: 124
• Deposited Residue Count: 127
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Bromodomain-containing protein 1	A	127	Homo sapiens	Mutation(s): 0  Gene Names: BRD1, BRL, BRPF2
UniProt & NIH Common Fund Data Resources
Find proteins for O95696 (Homo sapiens) Explore O95696  Go to UniProtKB:  O95696
PHAROS:  O95696 GTEx:  ENSG00000100425

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
O4B	C [auth A]	1,4,7,10,13,16-HEXAOXACYCLOOCTADECANE C12 H24 O6 XEZNGIUYQVAUSS-UHFFFAOYSA-N
ACT	B [auth A]	ACETATE ION C2 H3 O2 QTBSBXVTEAMEQO-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.75 Å
• R-Value Free:  0.248 (Depositor), 0.250 (DCC)
• R-Value Work:  0.208 (Depositor), 0.210 (DCC)
• R-Value Observed: 0.210 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 27.926	α = 90
b = 59.641	β = 106.6
c = 35.831	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
XSCALE	data scaling
MOLREP	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2019-10-30
Deposition Author(s): Yokoyama, T., Kosaka, Y., Matsumoto, K., Kitakami, R., Nabeshima, Y., Mizuguchi, M.

Revision History

• Version 1.0: 2019-10-30
  Type: Initial release

• Version 1.1: 2024-03-27
  Changes: Data collection, Database references
