6IE1

Crystal Structure of ELMO2(Engulfment and cell motility protein 2)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.48 Å
  • R-Value Free: 0.240
  • R-Value Work: 0.206
  • R-Value Observed: 0.207

wwPDB Validation 3D Report Full Report



Literature

Structure of BAI1/ELMO2 complex reveals an action mechanism of adhesion GPCRs via ELMO family scaffolds

Weng, Z.Situ, C.Lin, L.Wu, Z.Zhu, J.Zhang, R.

(2019) Nat Commun 10: 51-51

  • DOI: 10.1038/s41467-018-07938-9
  • Primary Citation of Related Structures:
    6IE1, 6IDX

  • PubMed Abstract:
  • The brain-specific angiogenesis inhibitor (BAI) subfamily of adhesion G protein-coupled receptors (aGPCRs) plays crucial roles in diverse cellular processes including phagocytosis, myoblast fusion, and synaptic development through the ELMO/DOCK/Rac s ...

    The brain-specific angiogenesis inhibitor (BAI) subfamily of adhesion G protein-coupled receptors (aGPCRs) plays crucial roles in diverse cellular processes including phagocytosis, myoblast fusion, and synaptic development through the ELMO/DOCK/Rac signaling pathway, although the underlying molecular mechanism is not well understood. Here, we demonstrate that an evolutionarily conserved fragment located in the C-terminal cytoplasmic tail of BAI-aGPCRs is specifically recognized by the RBD-ARR-ELMO (RAE) supramodule of the ELMO family scaffolds. The crystal structures of ELMO2-RAE and its complex with BAI1 uncover the molecular basis of BAI/ELMO interactions. Based on the complex structure we identify aGPCR-GPR128 as another upstream receptor for the ELMO family scaffolds, most likely with a recognition mode similar to that of BAI/ELMO interactions. Finally, we map disease-causing mutations of BAI and ELMO and analyze their effects on complex formation.


    Organizational Affiliation

    School of Life Science and Technology, ShanghaiTech University, 100 Haike Road, 201210, Shanghai, China. rgzhang@sibcb.ac.cn.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Engulfment and cell motility protein 2A524Homo sapiensMutation(s): 0
Gene Names: ELMO2CED12AKIAA1834
Find proteins for Q96JJ3 (Homo sapiens)
Explore Q96JJ3
Go to UniProtKB:  Q96JJ3
NIH Common Fund Data Resources
PHAROS  Q96JJ3
Protein Feature View
Expand
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
GOL
Query on GOL

Download CCD File
A
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.48 Å
  • R-Value Free: 0.240
  • R-Value Work: 0.206
  • R-Value Observed: 0.207
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 75.182α = 90
b = 119.134β = 90
c = 169.326γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-3000data scaling
PDB_EXTRACTdata extraction
d*TREKdata reduction
SHELXDEphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 2019-01-23
    Type: Initial release
