6H9L

Kcr_0859 delta TM from Korarchaeum cryptofilum


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.19 Å
  • R-Value Free: 0.273
  • R-Value Work: 0.243
  • R-Value Observed: 0.244

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Characterization of MCU-Binding Proteins MCUR1 and CCDC90B - Representatives of a Protein Family Conserved in Prokaryotes and Eukaryotic Organelles.

Adlakha, J.Karamichali, I.Sangwallek, J.Deiss, S.Bar, K.Coles, M.Hartmann, M.D.Lupas, A.N.Hernandez Alvarez, B.

(2019) Structure 27: 464-475.e6

  • DOI: https://doi.org/10.1016/j.str.2018.11.004
  • Primary Citation of Related Structures:
    6H9L, 6H9M

  • PubMed Abstract:

    Membrane-bound coiled-coil proteins are important mediators of signaling, fusion, and scaffolding. Here, we delineate a heterogeneous group of trimeric membrane-anchored proteins in prokaryotes and eukaryotic organelles with a characteristic head-neck-stalk-anchor architecture, in which a membrane-anchored coiled-coil stalk projects an N-terminal head domain via a β-layer neck. Based on sequence analysis, we identify different types of head domains and determine crystal structures of two representatives, the archaeal protein Kcr-0859 and the human CCDC90B, which possesses the most widespread head type. Using mitochondrial calcium uniporter regulator 1 (MCUR1), the functionally characterized paralog of CCDC90B, we study the role of individual domains, and find that the head interacts directly with the mitochondrial calcium uniporter (MCU) and is destabilized upon Ca 2+ binding. Our data provide structural details of a class of membrane-bound coiled-coil proteins and identify the conserved head domain of the most widespread type as a mediator of their function.


  • Organizational Affiliation

    Department of Protein Evolution, Max Planck Institute for Developmental Biology, Max-Planck-Ring 5, 72076 Tübingen, Germany.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Uncharacterized protein
A, B, C
139Candidatus Korarchaeum cryptofilum OPF8Mutation(s): 0
Gene Names: Kcr_0859
UniProt
Find proteins for B1L576 (Korarchaeum cryptofilum (strain OPF8))
Explore B1L576
Go to UniProtKB:  B1L576
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB1L576
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
A, B, C
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.19 Å
  • R-Value Free: 0.273
  • R-Value Work: 0.243
  • R-Value Observed: 0.244
  • Space Group: P 21 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 197.52α = 90
b = 48.88β = 90
c = 51.06γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
XDSdata scaling
SHELXDEphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2019-02-13
    Type: Initial release
  • Version 1.1: 2019-03-13
    Changes: Data collection, Database references
