6H1A

Crystal structure of VX surrogate NEMP inhibited recombinant human bile salt activated lipase


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.75 Å
  • R-Value Free: 0.224
  • R-Value Work: 0.194

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

X-ray structures of human bile-salt activated lipase conjugated to nerve agents surrogates.

Touvrey, C.Courageux, C.Guillon, V.Terreux, R.Nachon, F.Brazzolotto, X.

(2019) Toxicology 411: 15-23

  • DOI: 10.1016/j.tox.2018.10.015
  • Primary Citation of Related Structures:
    6H0T, 6H0V, 6H18, 6H19, 6H1A

  • PubMed Abstract:
  • The efficiency of human butyrylcholinesterase (BChE) as a stoichiometric bioscavenger of nerve agents is well established. However, wide use is currently limited by production and purification costs. Aiming at identifying an alternative human protein bioscavenger, we looked for an original scaffold candidate by virtual screening of the Protein Data Bank for functional similarity using the "Surfing the Molecules" software (sumo-pbil ...

    The efficiency of human butyrylcholinesterase (BChE) as a stoichiometric bioscavenger of nerve agents is well established. However, wide use is currently limited by production and purification costs. Aiming at identifying an alternative human protein bioscavenger, we looked for an original scaffold candidate by virtual screening of the Protein Data Bank for functional similarity using the "Surfing the Molecules" software (sumo-pbil.ibcp.fr) and a search model based on the BChE active site topology. Besides the expected acetylcholinesterase and butyrylcholinesterase, we identified a set of bile salt activated lipases structures, among which the human pancreatic lipase (hBAL) that shares 34% identity with BChE. We produced the recombinant enzyme in mammalian cells, purified it, and measured the inhibition constants for paraoxon and surrogates of VX, sarin and tabun. We solved the X-ray structure of apo hBAL and conjugates with paraoxon and the surrogates at resolutions in the 2-Å range. These structures allow the assessment of hBAL for scavenging nerve agents. They revealed that hBAL has inverted stereoselectivity for the surrogates of nerve agent compared to human cholinesterases. We observed a remarkable flip of the catalytic histidine driven by the chelation of Zn 2+ . Dealkylation of the conjugate, aka aging, was solely observed for paraoxon.


    Organizational Affiliation

    Institut de Recherche Biomédicale des Armées, Département de Toxicologie et Risques Chimiques, Brétigny sur Orge, 91220, France.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Bile salt-activated lipaseA547Homo sapiensMutation(s): 2
Gene Names: CELBAL
EC: 3.1.1.13 (PDB Primary Data), 3.1.1.3 (PDB Primary Data), 3.1.1.6 (UniProt)
Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for P19835 (Homo sapiens)
Explore P19835
Go to UniProtKB:  P19835
PHAROS:  P19835
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP19835
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download Ideal Coordinates CCD File
B [auth A],
C [auth A],
D [auth A],
E [auth A],
F [auth A],
B [auth A],
C [auth A],
D [auth A],
E [auth A],
F [auth A],
G [auth A],
H [auth A],
I [auth A],
J [auth A],
K [auth A],
L [auth A]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
 Ligand Interaction
ACT
Query on ACT

Download Ideal Coordinates CCD File
M [auth A],
N [auth A],
O [auth A],
P [auth A],
Q [auth A],
M [auth A],
N [auth A],
O [auth A],
P [auth A],
Q [auth A],
R [auth A],
S [auth A]
ACETATE ION
C2 H3 O2
QTBSBXVTEAMEQO-UHFFFAOYSA-M
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
SVX
Query on SVX
A L-PEPTIDE LINKINGC6 H14 N O5 PSER
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.75 Å
  • R-Value Free: 0.224
  • R-Value Work: 0.194
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 56.371α = 90
b = 97.744β = 90
c = 110.835γ = 90
Software Package:
Software NamePurpose
XDSdata reduction
XSCALEdata scaling
PHASERphasing
Cootmodel building
PHENIXrefinement

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
French Ministry of Armed ForcesFrancePDH-2-NRBC-3-C-3201
French National Research AgencyFranceASTRID CAT-SCAV

Revision History  (Full details and data files)

  • Version 1.0: 2019-03-27
    Type: Initial release
