6GYJ | pdb_00006gyj

Mouse thymidylate synthase crystal soaked in phenolphthalein

• PDB DOI: https://doi.org/10.2210/pdb6GYJ/pdb

• Classification: TRANSFERASE
• Organism(s): Mus musculus
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2018-06-30 Released: 2019-08-28
• Deposition Author(s): Maj, P., Jarmula, A., Wilk, P., Weiss, M.S., Rode, W.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.75 Å
• R-Value Free:
  0.250 (DCC)
• R-Value Work:
  0.210 (DCC)

Starting Model: experimental

Literature

Thymidylate synthase fragment screening

Maj, P., Jarmula, A., Wilk, P., Weiss, M.S., Rode, W.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 70.67 kDa
• Atom Count: 5,147
• Modeled Residue Count: 558
• Deposited Residue Count: 614
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Thymidylate synthase	A, B	307	Mus musculus	Mutation(s): 0  Gene Names: Tyms EC: 2.1.1.45
UniProt
Find proteins for P07607 (Mus musculus) Explore P07607  Go to UniProtKB:  P07607

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
FGT (Subject of Investigation/LOI)	D [auth A]	3,3-bis(4-hydroxyphenyl)-2-benzofuran-1-one C20 H14 O4 KJFMBFZCATUALV-UHFFFAOYSA-N
SO4	C [auth A], G [auth A]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L
DMS	E [auth A], F [auth A]	DIMETHYL SULFOXIDE C2 H6 O S IAZDPXIOMUYVGZ-UHFFFAOYSA-N

Binding Affinity Annotations
ID	Source	Binding Affinity
FGT	BindingDB:  6GYJ	Ki: 1200 (nM) from 1 assay(s)

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.75 Å
• R-Value Free:  0.250 (DCC)
• R-Value Work:  0.210 (DCC)

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 159.555	α = 90
b = 88.378	β = 97.01
c = 68.391	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
DENZO	data reduction
SCALEPACK	data scaling
PHASER	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2019-08-28
Deposition Author(s): Maj, P., Jarmula, A., Wilk, P., Weiss, M.S., Rode, W.

Revision History

• Version 1.0: 2019-08-28
  Type: Initial release

• Version 1.1: 2024-01-17
  Changes: Data collection, Database references, Refinement description
