6GXJ | pdb_00006gxj

X-ray structure of DiRu-1-encapsulated Apoferritin


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.43 Å
  • R-Value Free:
    0.191 (Depositor), 0.185 (DCC)
  • R-Value Work:
    0.174 (Depositor), 0.168 (DCC)
  • R-Value Observed:
    0.174 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6GXJ

This is version 1.2 of the entry. See complete history

Literature

Encapsulation of the Dinuclear Trithiolato-Bridged Arene Ruthenium Complex Diruthenium-1 in an Apoferritin Nanocage: Structure and Cytotoxicity.

Petruk, G.Monti, D.M.Ferraro, G.Pica, A.D'Elia, L.Pane, F.Amoresano, A.Furrer, J.Kowalski, K.Merlino, A.

(2019) ChemMedChem 14: 594-602

  • DOI: https://doi.org/10.1002/cmdc.201800805
  • Primary Citation Related Structures:
    6GXJ

  • PubMed Abstract:

    The effects of encapsulating the cytotoxic dinuclear trithiolato-bridged arene ruthenium complex [(η 6 -p-MeC 6 H 4 iPr) 2 Ru 2 2 -S-p-C 6 H 4 tBu) 3 ]Cl (DiRu-1) within the apoferritin (AFt) nanocage were investigated. The DiRu-1-AFt nanocarrier was characterized by UV/Vis spectroscopy, ICP-MS, CD and X-ray crystallography. In contrast to previously reported Au- and Pt-based drug-loaded AFt carriers, we found no evidence of direct interactions between DiRu-1 and AFt. DiRu-1-AFt is cytotoxic toward immortalized murine BALB/c-3T3 fibroblasts transformed with SV40 virus (SVT2) and human epidermoid carcinoma A431 malignant cells, and exhibits moderate selectivity for these cancer cells over normal BALB/c-3T3 cells. DiRu-1-AFt triggers the production of reactive oxygen species, depolarization of mitochondrial membrane potential, and induces cell death via p53-mediated apoptosis. Comparison between our data and previous results suggests that the presence of specific interactions between a metal-based drug and AFt within the protein cage is not essential for drug encapsulation.


  • Organizational Affiliation
    • Department of Chemical Sciences, University of Naples Federico II, Complesso Universitario di Monte Sant'Angelo, via Cinthia 21, 80126, Naples, Italy.

Macromolecule Content

  • Total Structure Weight: 21.35 kDa
  • Atom Count: 1,771
  • Modeled Residue Count: 173
  • Deposited Residue Count: 174
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Ferritin light chain174Equus caballusMutation(s): 0
UniProt
Find proteins for P02791 (Equus caballus)
Explore P02791
Go to UniProtKB:  P02791
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP02791
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
CD

Query on CD



Download:Ideal Coordinates CCD File
B [auth A]
C [auth A]
D [auth A]
E [auth A]
F [auth A]
B [auth A],
C [auth A],
D [auth A],
E [auth A],
F [auth A],
G [auth A],
H [auth A],
I [auth A],
J [auth A],
M [auth A]
CADMIUM ION
Cd
WLZRMCYVCSSEQC-UHFFFAOYSA-N
SO4

Query on SO4



Download:Ideal Coordinates CCD File
N [auth A]SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
GOL

Query on GOL



Download:Ideal Coordinates CCD File
O [auth A],
P [auth A]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
CL

Query on CL



Download:Ideal Coordinates CCD File
K [auth A],
L [auth A]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.43 Å
  • R-Value Free:  0.191 (Depositor), 0.185 (DCC)
  • R-Value Work:  0.174 (Depositor), 0.168 (DCC)
  • R-Value Observed: 0.174 (Depositor)
Space Group: F 4 3 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 180.404α = 90
b = 180.404β = 90
c = 180.404γ = 90
Software Package:
Software NamePurpose
BUSTERrefinement
XDSdata reduction
XSCALEdata scaling
BUSTERphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2019-02-06
    Type: Initial release
  • Version 1.1: 2019-03-13
    Changes: Data collection, Database references
  • Version 1.2: 2024-01-17
    Changes: Data collection, Database references, Derived calculations, Refinement description
