6GBZ

50S ribosomal subunit assembly intermediate state 5


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.8 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report


This is version 1.0 of the entry. See complete history

Literature

Structural Visualization of the Formation and Activation of the 50S Ribosomal Subunit during In Vitro Reconstitution.

Nikolay, R.Hilal, T.Qin, B.Mielke, T.Burger, J.Loerke, J.Textoris-Taube, K.Nierhaus, K.H.Spahn, C.M.T.

(2018) Mol. Cell 70: 881-893.e3

  • DOI: 10.1016/j.molcel.2018.05.003
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • The assembly of ribosomal subunits is an essential prerequisite for protein biosynthesis in all domains of life. Although biochemical and biophysical approaches have advanced our understanding of ribosome assembly, our mechanistic comprehension of th ...

    The assembly of ribosomal subunits is an essential prerequisite for protein biosynthesis in all domains of life. Although biochemical and biophysical approaches have advanced our understanding of ribosome assembly, our mechanistic comprehension of this process is still limited. Here, we perform an in vitro reconstitution of the Escherichia coli 50S ribosomal subunit. Late reconstitution products were subjected to high-resolution cryo-electron microscopy and multiparticle refinement analysis to reconstruct five distinct precursors of the 50S subunit with 4.3-3.8 Å resolution. These assembly intermediates define a progressive maturation pathway culminating in a late assembly particle, whose structure is more than 96% identical to a mature 50S subunit. Our structures monitor the formation and stabilization of structural elements in a nascent particle in unprecedented detail and identify the maturation of the rRNA-based peptidyl transferase center as the final critical step along the 50S assembly pathway.


    Organizational Affiliation

    Institut für Medizinische Physik und Biophysik, Charité - Universitätsmedizin Berlin, corporate member of Freie Universität Berlin, Humboldt-Universität zu Berlin, and Berlin Institute of Health, Berlin, Germany.




Macromolecules

Find similar proteins by: Sequence  |  Structure


Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L2
C
271Escherichia coli (strain K12)Mutation(s): 0
Gene Names: rplB
Find proteins for P60422 (Escherichia coli (strain K12))
Go to UniProtKB:  P60422
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L3
D
209Escherichia coli (strain K12)Mutation(s): 0
Gene Names: rplC
Find proteins for P60438 (Escherichia coli (strain K12))
Go to UniProtKB:  P60438
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L4
E
201Escherichia coli (strain K12)Mutation(s): 0
Gene Names: rplD (eryA)
Find proteins for P60723 (Escherichia coli (strain K12))
Go to UniProtKB:  P60723
Entity ID: 5
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L5
F
177Escherichia coli (strain K12)Mutation(s): 0
Gene Names: rplE
Find proteins for P62399 (Escherichia coli (strain K12))
Go to UniProtKB:  P62399
Entity ID: 6
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L6
G
176Escherichia coli (strain K12)Mutation(s): 0
Gene Names: rplF
Find proteins for P0AG55 (Escherichia coli (strain K12))
Go to UniProtKB:  P0AG55
Entity ID: 7
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L9
H
50Escherichia coli (strain K12)Mutation(s): 0
Gene Names: rplI
Find proteins for P0A7R1 (Escherichia coli (strain K12))
Go to UniProtKB:  P0A7R1
Entity ID: 8
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L13
J
142Escherichia coli (strain K12)Mutation(s): 0
Gene Names: rplM
Find proteins for P0AA10 (Escherichia coli (strain K12))
Go to UniProtKB:  P0AA10
Entity ID: 9
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L14
K
122Escherichia coli (strain K12)Mutation(s): 0
Gene Names: rplN
Find proteins for P0ADY3 (Escherichia coli (strain K12))
Go to UniProtKB:  P0ADY3
Entity ID: 10
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L15
L
143Escherichia coli (strain K12)Mutation(s): 0
Gene Names: rplO
Find proteins for P02413 (Escherichia coli (strain K12))
Go to UniProtKB:  P02413
Entity ID: 11
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L17
N
120Escherichia coli (strain K12)Mutation(s): 0
Gene Names: rplQ
Find proteins for P0AG44 (Escherichia coli (strain K12))
Go to UniProtKB:  P0AG44
Entity ID: 12
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L18
O
116Escherichia coli (strain K12)Mutation(s): 0
Gene Names: rplR
Find proteins for P0C018 (Escherichia coli (strain K12))
Go to UniProtKB:  P0C018
Entity ID: 13
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L19
P
114Escherichia coli (strain K12)Mutation(s): 0
Gene Names: rplS
Find proteins for P0A7K6 (Escherichia coli (strain K12))
Go to UniProtKB:  P0A7K6
Entity ID: 14
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L20
Q
117Escherichia coli (strain K12)Mutation(s): 0
Gene Names: rplT (pdzA)
Find proteins for P0A7L3 (Escherichia coli (strain K12))
Go to UniProtKB:  P0A7L3
Entity ID: 15
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L21
R
103Escherichia coli (strain K12)Mutation(s): 0
Gene Names: rplU
Find proteins for P0AG48 (Escherichia coli (strain K12))
Go to UniProtKB:  P0AG48
Entity ID: 16
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L22
S
110Escherichia coli (strain K12)Mutation(s): 0
Gene Names: rplV (eryB)
Find proteins for P61175 (Escherichia coli (strain K12))
Go to UniProtKB:  P61175
Entity ID: 17
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L23
T
93Escherichia coli (strain K12)Mutation(s): 0
Gene Names: rplW
Find proteins for P0ADZ0 (Escherichia coli (strain K12))
Go to UniProtKB:  P0ADZ0
Entity ID: 18
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L24
U
102Escherichia coli (strain K12)Mutation(s): 0
Gene Names: rplX
Find proteins for P60624 (Escherichia coli (strain K12))
Go to UniProtKB:  P60624
Entity ID: 19
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L25
V
94Escherichia coli (strain K12)Mutation(s): 0
Gene Names: rplY
Find proteins for P68919 (Escherichia coli (strain K12))
Go to UniProtKB:  P68919
Entity ID: 20
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L27
W
76Escherichia coli (strain K12)Mutation(s): 0
Gene Names: rpmA
Find proteins for P0A7L8 (Escherichia coli (strain K12))
Go to UniProtKB:  P0A7L8
Entity ID: 21
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L28
X
77Escherichia coli (strain K12)Mutation(s): 0
Gene Names: rpmB
Find proteins for P0A7M2 (Escherichia coli (strain K12))
Go to UniProtKB:  P0A7M2
Entity ID: 22
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L29
Y
63Escherichia coli (strain K12)Mutation(s): 0
Gene Names: rpmC
Find proteins for P0A7M6 (Escherichia coli (strain K12))
Go to UniProtKB:  P0A7M6
Entity ID: 23
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L30
Z
58Escherichia coli (strain K12)Mutation(s): 0
Gene Names: rpmD
Find proteins for P0AG51 (Escherichia coli (strain K12))
Go to UniProtKB:  P0AG51
Entity ID: 24
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L32
0
56Escherichia coli (strain K12)Mutation(s): 0
Gene Names: rpmF
Find proteins for P0A7N4 (Escherichia coli (strain K12))
Go to UniProtKB:  P0A7N4
Entity ID: 25
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L33
1
50Escherichia coli (strain K12)Mutation(s): 0
Gene Names: rpmG
Find proteins for P0A7N9 (Escherichia coli (strain K12))
Go to UniProtKB:  P0A7N9
Entity ID: 26
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L34
2
46Escherichia coli (strain K12)Mutation(s): 0
Gene Names: rpmH (rimA, ssaF)
Find proteins for P0A7P5 (Escherichia coli (strain K12))
Go to UniProtKB:  P0A7P5
Entity ID: 27
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L35
3
64Escherichia coli (strain K12)Mutation(s): 0
Gene Names: rpmI
Find proteins for P0A7Q1 (Escherichia coli (strain K12))
Go to UniProtKB:  P0A7Q1
Entity ID: 29
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L16
M
136Escherichia coli (strain K12)Mutation(s): 0
Gene Names: rplP
Find proteins for P0ADY7 (Escherichia coli (strain K12))
Go to UniProtKB:  P0ADY7
Entity ID: 1
MoleculeChainsLengthOrganism
23S ribosomal RNAA2904Escherichia coli K-12
Entity ID: 28
MoleculeChainsLengthOrganism
5S ribosomal RNAB119Escherichia coli K-12
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.8 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
Software Package:
Software NamePurpose
PHENIXrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
German Research FoundationGermanyFOR1805
German Research FoundationGermanySFB740

Revision History

  • Version 1.0: 2018-06-20
    Type: Initial release
