6F76

Antibody derived (Abd-8) small molecule binding to KRAS.


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.2 Å
  • R-Value Free: 0.249
  • R-Value Work: 0.226

wwPDB Validation 3D Report Full Report


This is version 1.0 of the entry. See complete history

Literature

BRET-based RAS biosensors that show a novel small molecule is an inhibitor of RAS-effector protein-protein interactions.

Bery, N.Cruz-Migoni, A.Bataille, C.J.Quevedo, C.E.Tulmin, H.Miller, A.Russell, A.Phillips, S.E.Carr, S.B.Rabbitts, T.H.

(2018) Elife 7: --

  • DOI: 10.7554/eLife.37122

  • PubMed Abstract:
  • The RAS family of proteins is amongst the most highly mutated in human cancers and has so far eluded drug therapy. Currently, much effort is being made to discover mutant RAS inhibitors and in vitro screening for RAS-binding drugs must be followed by ...

    The RAS family of proteins is amongst the most highly mutated in human cancers and has so far eluded drug therapy. Currently, much effort is being made to discover mutant RAS inhibitors and in vitro screening for RAS-binding drugs must be followed by cell-based assays. Here, we have developed a robust set of bioluminescence resonance energy transfer (BRET)-based RAS biosensors that enable monitoring of RAS-effector interaction inhibition in living cells. These include KRAS, HRAS and NRAS and a variety of different mutations that mirror those found in human cancers with the major RAS effectors such as CRAF, PI3K and RALGDS. We highlighted the utility of these RAS biosensors by showing a RAS-binding compound is a potent pan-RAS-effector interactions inhibitor in cells. The RAS biosensors represent a useful tool to investigate and characterize the potency of anti-RAS inhibitors in cells and more generally any RAS protein-protein interaction (PPI) in cells.


    Organizational Affiliation

    MRC Molecular Haematology Unit, Weatherall Institute of Molecular Medicine, University of Oxford, Oxford, United Kingdom.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
GTPase KRas
B, A, C, D, E, F
173Homo sapiensMutation(s): 1
Gene Names: KRAS (KRAS2, RASK2)
Find proteins for P01116 (Homo sapiens)
Go to Gene View: KRAS
Go to UniProtKB:  P01116
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
CVK
Query on CVK

Download SDF File
Download CCD File
A, B, C, F
4-(2,3-dihydro-1,4-benzodioxin-5-yl)-~{N}-[3-[(dimethylamino)methyl]phenyl]-2-methoxy-aniline
C24 H26 N2 O3
LEFMIEUBWDMNAT-UHFFFAOYSA-N
 Ligand Interaction
MG
Query on MG

Download SDF File
Download CCD File
A, B, C, D, E, F
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
 Ligand Interaction
GNP
Query on GNP

Download SDF File
Download CCD File
A, B, C, D, E, F
PHOSPHOAMINOPHOSPHONIC ACID-GUANYLATE ESTER
C10 H17 N6 O13 P3
UQABYHGXWYXDTK-UUOKFMHZSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.2 Å
  • R-Value Free: 0.249
  • R-Value Work: 0.226
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 63.190α = 90.00
b = 118.424β = 90.00
c = 156.751γ = 90.00
Software Package:
Software NamePurpose
xia2data reduction
REFMACrefinement
xia2data scaling
PHASERphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Wellcome TrustUnited Kingdom100842/z/12/z
Wellcome TrustUnited Kingdom099246/z/12/z
BloodwiseUnited Kingdom12051
Medical Research Council (United Kingdom)United KingdomMR/J000612/1

Revision History

  • Version 1.0: 2018-08-08
    Type: Initial release
