6ERJ

Self-complemented FimA subunit from Salmonella enterica


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.69 Å
  • R-Value Free: 0.242
  • R-Value Work: 0.177
  • R-Value Observed: 0.180

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Alternative folding to a monomer or homopolymer is a common feature of the type 1 pilus subunit FimA from enteroinvasive bacteria.

Zyla, D.S.Prota, A.E.Capitani, G.Glockshuber, R.

(2019) J Biol Chem 294: 10553-10563

  • DOI: 10.1074/jbc.RA119.008610
  • Primary Citation of Related Structures:
    5LP9, 5NKT, 6ERJ

  • PubMed Abstract:
  • Adhesive type 1 pili from enteroinvasive, Gram-negative bacteria mediate attachment to host cells. Up to 3000 copies of the main pilus subunit, FimA, assemble into the filamentous, helical quaternary structure of the pilus rod via a mechanism termed donor-strand complementation, in which the N-terminal extension of each subunit, the donor strand, is inserted into the incomplete immunoglobulin-like fold of the preceding FimA subunit ...

    Adhesive type 1 pili from enteroinvasive, Gram-negative bacteria mediate attachment to host cells. Up to 3000 copies of the main pilus subunit, FimA, assemble into the filamentous, helical quaternary structure of the pilus rod via a mechanism termed donor-strand complementation, in which the N-terminal extension of each subunit, the donor strand, is inserted into the incomplete immunoglobulin-like fold of the preceding FimA subunit. For FimA from Escherichia coli , it has been previously shown that the protein can also adopt a monomeric, self-complemented conformation in which the donor strand is inserted intramolecularly in the opposite orientation relative to that observed for FimA polymers. Notably, soluble FimA monomers can act as apoptosis inhibitors in epithelial cells after uptake of type 1-piliated pathogens. Here, we show that the FimA orthologues from Escherichia coli , Shigella flexneri , and Salmonella enterica can all fold to form self-complemented monomers. We solved X-ray structures of all three FimA monomers at 0.89-1.69 Å resolutions, revealing identical, intramolecular donor-strand complementation mechanisms. Our results also showed that the pseudo-palindromic sequences of the donor strands in all FimA proteins permit their alternative folding possibilities. All FimA monomers proved to be 50-60 kJ/mol less stable against unfolding than their pilus rod-like counterparts (which exhibited very high energy barriers of unfolding and refolding). We conclude that the ability of FimA to adopt an alternative, monomeric state with anti-apoptotic activity is a general feature of FimA proteins of type 1-piliated bacteria.


    Organizational Affiliation

    From the Institute of Molecular Biology and Biophysics, ETH Zurich, Otto-Stern-Weg 5, CH-8093 Zurich and rudi@mol.biol.ethz.ch.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Type-1 fimbrial protein, a chainA [auth B]164Salmonella enterica subsp. enterica serovar Paratyphi A str. ATCC 9150Mutation(s): 0
Gene Names: fimASPA2182GNB70_001452
UniProt
Find proteins for A0A0H2WR29 (Salmonella paratyphi A (strain ATCC 9150 / SARB42))
Explore A0A0H2WR29
Go to UniProtKB:  A0A0H2WR29
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
Type-1 fimbrial protein, a chainB [auth A]163Salmonella enterica subsp. enterica serovar Paratyphi A str. ATCC 9150Mutation(s): 0
Gene Names: fimASPA2182GNB70_001452
UniProt
Find proteins for A0A0H2WR29 (Salmonella paratyphi A (strain ATCC 9150 / SARB42))
Explore A0A0H2WR29
Go to UniProtKB:  A0A0H2WR29
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ACY
Query on ACY

Download Ideal Coordinates CCD File
C [auth B], D [auth B], E [auth A]ACETIC ACID
C2 H4 O2
QTBSBXVTEAMEQO-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.69 Å
  • R-Value Free: 0.242
  • R-Value Work: 0.177
  • R-Value Observed: 0.180
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 34.97α = 90
b = 104.43β = 90
c = 182.87γ = 90
Software Package:
Software NamePurpose
XSCALEdata scaling
PHASERphasing
PHENIXrefinement
PDB_EXTRACTdata extraction
XDSdata reduction
XSCALEdata scaling

Structure Validation

View Full Validation Report




Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Swiss National Science FoundationSwitzerland156304

Revision History  (Full details and data files)

  • Version 1.0: 2019-01-30
    Type: Initial release
  • Version 1.1: 2019-06-26
    Changes: Data collection, Database references
  • Version 1.2: 2019-07-17
    Changes: Data collection, Database references
