6EPK | pdb_00006epk

CRYSTAL STRUCTURE OF THE PRECURSOR MEMBRANE PROTEIN-ENVELOPE PROTEIN HETERODIMER FROM THE YELLOW FEVER VIRUS

PDB DOI: https://doi.org/10.2210/pdb6EPK/pdb

Classification: VIRAL PROTEIN
Organism(s): Yellow fever virus
Expression System: Drosophila melanogaster
Mutation(s): No

Deposited: 2017-10-11 Released: 2018-10-31
Deposition Author(s): Rey, F.A., Duquerroy, S., Crampon, E., Barba-Spaeth, G.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.70 Å
R-Value Free:
0.186 (Depositor), 0.175 (DCC)
R-Value Work:
0.162 (Depositor), 0.161 (DCC)
R-Value Observed:
0.163 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 2.3 of the entry. See complete history.

Literature

New insight into flavivirus maturation from structure/function studies of the yellow fever virus envelope protein complex

Crampon, E., Covernton, E., Vaney, M.C., Dellarole, M., Sommer, S., Sharma, A., Haouz, A., England, P., Lepault, J., Duquerroy, S., Rey, F.A., Barba-Spaeth, G.

(2023) mBio

DOI: https://doi.org/10.1128/mbio.00706-23

Macromolecule Content

Total Structure Weight: 119.57 kDa
Atom Count: 8,103
Modeled Residue Count: 974
Deposited Residue Count: 1,032
Unique protein chains: 2

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Envelope protein E	A, C [auth D]	427	Yellow fever virus	Mutation(s): 0 EC: 3.4.21.91 (PDB Primary Data), 3.6.1.15 (PDB Primary Data), 3.6.4.13 (PDB Primary Data), 2.1.1.56 (PDB Primary Data), 2.1.1.57 (PDB Primary Data), 2.7.7.48 (PDB Primary Data)
UniProt
Find proteins for Q6DV88 (Yellow fever virus (strain Ghana/Asibi/1927)) Explore Q6DV88 Go to UniProtKB: Q6DV88
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q6DV88
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Precursor Membrane Protein	B, D [auth E]	89	Yellow fever virus	Mutation(s): 0 Gene Names: prM EC: 3.4.21.91 (PDB Primary Data), 3.6.1.15 (PDB Primary Data), 3.6.4.13 (PDB Primary Data), 2.1.1.56 (PDB Primary Data), 2.1.1.57 (PDB Primary Data), 2.7.7.48 (PDB Primary Data)
UniProt
Find proteins for P03314 (Yellow fever virus (strain 17D vaccine)) Explore P03314 Go to UniProtKB: P03314
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P03314
Glycosylation
Glycosylation Sites: 2	Glycosylation Focus chain B Focus chain D [auth E]
Sequence Annotations Expand
Reference Sequence

Oligosaccharides

Help

Entity ID: 3
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	E [auth C]	2		N-Glycosylation	Interactions Focus chain E [auth C] Interactions & Density Focus chain E [auth C]
Glycosylation Resources
GlyTouCan: G42666HT GlyCosmos: G42666HT GlyGen: G42666HT

Entity ID: 4
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
alpha-D-mannopyranose-(1-3)-[alpha-D-mannopyranose-(1-6)]beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-[alpha-L-fucopyranose-(1-6)]2-acetamido-2-deoxy-beta-D-glucopyranose	F, H	6		N-Glycosylation	Interactions Focus chain F Focus chain H Interactions & Density Focus chain F Focus chain H
Glycosylation Resources
GlyTouCan: G82348BZ GlyCosmos: G82348BZ GlyGen: G82348BZ

Entity ID: 5
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	G	3		N-Glycosylation	Interactions Focus chain G Interactions & Density Focus chain G
Glycosylation Resources
GlyTouCan: G15407YE GlyCosmos: G15407YE GlyGen: G15407YE

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain X [auth B] SDF format, chain W [auth B] SDF format, chain RA [auth E] SDF format, chain Q [auth A] SDF format, chain P [auth A] SDF format, chain O [auth A] SDF format, chain N [auth A] SDF format, chain M [auth A] SDF format, chain L [auth A] SDF format, chain KA [auth D] SDF format, chain K [auth A] SDF format, chain JA [auth D] SDF format, chain J [auth A] SDF format, chain IA [auth D] SDF format, chain I [auth A] SDF format, chain HA [auth D] SDF format, chain GA [auth D] SDF format, chain FA [auth D] SDF format, chain EA [auth D] SDF format, chain DA [auth D] SDF format, chain CA [auth D] SDF format, chain BA [auth D] SDF format, chain AA [auth D] MOL2 format, chain X [auth B] MOL2 format, chain W [auth B] MOL2 format, chain RA [auth E] MOL2 format, chain Q [auth A] MOL2 format, chain P [auth A] MOL2 format, chain O [auth A] MOL2 format, chain N [auth A] MOL2 format, chain M [auth A] MOL2 format, chain L [auth A] MOL2 format, chain KA [auth D] MOL2 format, chain K [auth A] MOL2 format, chain JA [auth D] MOL2 format, chain J [auth A] MOL2 format, chain IA [auth D] MOL2 format, chain I [auth A] MOL2 format, chain HA [auth D] MOL2 format, chain GA [auth D] MOL2 format, chain FA [auth D] MOL2 format, chain EA [auth D] MOL2 format, chain DA [auth D] MOL2 format, chain CA [auth D] MOL2 format, chain BA [auth D] MOL2 format, chain AA [auth D] mmCIF format, chain X [auth B] mmCIF format, chain W [auth B] mmCIF format, chain RA [auth E] mmCIF format, chain Q [auth A] mmCIF format, chain P [auth A] mmCIF format, chain O [auth A] mmCIF format, chain N [auth A] mmCIF format, chain M [auth A] mmCIF format, chain L [auth A] mmCIF format, chain KA [auth D] mmCIF format, chain K [auth A] mmCIF format, chain JA [auth D] mmCIF format, chain J [auth A] mmCIF format, chain IA [auth D] mmCIF format, chain I [auth A] mmCIF format, chain HA [auth D] mmCIF format, chain GA [auth D] mmCIF format, chain FA [auth D] mmCIF format, chain EA [auth D] mmCIF format, chain DA [auth D] mmCIF format, chain CA [auth D] mmCIF format, chain BA [auth D] mmCIF format, chain AA [auth D]	AA [auth D] BA [auth D] CA [auth D] DA [auth D] EA [auth D] AA [auth D], BA [auth D], CA [auth D], DA [auth D], EA [auth D], FA [auth D], GA [auth D], HA [auth D], I [auth A], IA [auth D], J [auth A], JA [auth D], K [auth A], KA [auth D], L [auth A], M [auth A], N [auth A], O [auth A], P [auth A], Q [auth A], RA [auth E], W [auth B], X [auth B]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain AA [auth D] Focus chain BA [auth D] Focus chain CA [auth D] Focus chain DA [auth D] Focus chain EA [auth D] Focus chain FA [auth D] Focus chain GA [auth D] Focus chain HA [auth D] Focus chain I [auth A] Focus chain IA [auth D] Focus chain J [auth A] Focus chain JA [auth D] Focus chain K [auth A] Focus chain KA [auth D] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Focus chain Q [auth A] Focus chain RA [auth E] Focus chain W [auth B] Focus chain X [auth B] Interactions & Density Focus chain AA [auth D] Focus chain BA [auth D] Focus chain CA [auth D] Focus chain DA [auth D] Focus chain EA [auth D] Focus chain FA [auth D] Focus chain GA [auth D] Focus chain HA [auth D] Focus chain I [auth A] Focus chain IA [auth D] Focus chain J [auth A] Focus chain JA [auth D] Focus chain K [auth A] Focus chain KA [auth D] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Focus chain Q [auth A] Focus chain RA [auth E] Focus chain W [auth B] Focus chain X [auth B]
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain Z [auth B] SDF format, chain Y [auth B] SDF format, chain V [auth A] SDF format, chain U [auth A] SDF format, chain T [auth A] SDF format, chain S [auth A] SDF format, chain R [auth A] SDF format, chain QA [auth D] SDF format, chain PA [auth D] SDF format, chain OA [auth D] SDF format, chain NA [auth D] SDF format, chain MA [auth D] SDF format, chain LA [auth D] MOL2 format, chain Z [auth B] MOL2 format, chain Y [auth B] MOL2 format, chain V [auth A] MOL2 format, chain U [auth A] MOL2 format, chain T [auth A] MOL2 format, chain S [auth A] MOL2 format, chain R [auth A] MOL2 format, chain QA [auth D] MOL2 format, chain PA [auth D] MOL2 format, chain OA [auth D] MOL2 format, chain NA [auth D] MOL2 format, chain MA [auth D] MOL2 format, chain LA [auth D] mmCIF format, chain Z [auth B] mmCIF format, chain Y [auth B] mmCIF format, chain V [auth A] mmCIF format, chain U [auth A] mmCIF format, chain T [auth A] mmCIF format, chain S [auth A] mmCIF format, chain R [auth A] mmCIF format, chain QA [auth D] mmCIF format, chain PA [auth D] mmCIF format, chain OA [auth D] mmCIF format, chain NA [auth D] mmCIF format, chain MA [auth D] mmCIF format, chain LA [auth D]	LA [auth D] MA [auth D] NA [auth D] OA [auth D] PA [auth D] LA [auth D], MA [auth D], NA [auth D], OA [auth D], PA [auth D], QA [auth D], R [auth A], S [auth A], T [auth A], U [auth A], V [auth A], Y [auth B], Z [auth B]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain LA [auth D] Focus chain MA [auth D] Focus chain NA [auth D] Focus chain OA [auth D] Focus chain PA [auth D] Focus chain QA [auth D] Focus chain R [auth A] Focus chain S [auth A] Focus chain T [auth A] Focus chain U [auth A] Focus chain V [auth A] Focus chain Y [auth B] Focus chain Z [auth B] Interactions & Density Focus chain LA [auth D] Focus chain MA [auth D] Focus chain NA [auth D] Focus chain OA [auth D] Focus chain PA [auth D] Focus chain QA [auth D] Focus chain R [auth A] Focus chain S [auth A] Focus chain T [auth A] Focus chain U [auth A] Focus chain V [auth A] Focus chain Y [auth B] Focus chain Z [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.70 Å
R-Value Free: 0.186 (Depositor), 0.175 (DCC)
R-Value Work: 0.162 (Depositor), 0.161 (DCC)
R-Value Observed: 0.163 (Depositor)

Space Group: P 4₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 99.88	α = 90
b = 99.88	β = 90
c = 238.824	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
Aimless	data scaling
AMoRE	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2018-10-31

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2018-10-31
Type: Initial release
Version 2.0: 2020-07-29
Type: Remediation
Reason: Carbohydrate remediation
Changes: Advisory, Atomic model, Data collection, Derived calculations, Structure summary
Version 2.1: 2023-09-06
Changes: Data collection, Database references, Derived calculations, Structure summary
Version 2.2: 2024-01-17
Changes: Refinement description
Version 2.3: 2024-11-13
Changes: Structure summary
