6ELZ

State E (TAP-Flag-Ytm1 E80A) - Visualizing the assembly pathway of nucleolar pre-60S ribosmes


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.3 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Visualizing the Assembly Pathway of Nucleolar Pre-60S Ribosomes.

Kater, L.Thoms, M.Barrio-Garcia, C.Cheng, J.Ismail, S.Ahmed, Y.L.Bange, G.Kressler, D.Berninghausen, O.Sinning, I.Hurt, E.Beckmann, R.

(2017) Cell 171: 1599-1610.e14

  • DOI: 10.1016/j.cell.2017.11.039
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Eukaryotic 60S ribosomal subunits are comprised of three rRNAs and ∼50 ribosomal proteins. The initial steps of their formation take place in the nucleolus, but, owing to a lack of structural information, this process is poorly understood. Using cryo ...

    Eukaryotic 60S ribosomal subunits are comprised of three rRNAs and ∼50 ribosomal proteins. The initial steps of their formation take place in the nucleolus, but, owing to a lack of structural information, this process is poorly understood. Using cryo-EM, we solved structures of early 60S biogenesis intermediates at 3.3 Å to 4.5 Å resolution, thereby providing insights into their sequential folding and assembly pathway. Besides revealing distinct immature rRNA conformations, we map 25 assembly factors in six different assembly states. Notably, the Nsa1-Rrp1-Rpf1-Mak16 module stabilizes the solvent side of the 60S subunit, and the Erb1-Ytm1-Nop7 complex organizes and connects through Erb1's meandering N-terminal extension, eight assembly factors, three ribosomal proteins, and three 25S rRNA domains. Our structural snapshots reveal the order of integration and compaction of the six major 60S domains within early nucleolar 60S particles developing stepwise from the solvent side around the exit tunnel to the central protuberance.


    Organizational Affiliation

    Gene Center Munich and Center of Integrated Protein Science-Munich (CiPS-M), Department of Biochemistry, Feodor-Lynen-Str. 25, University of Munich, 81377 Munich, Germany.




Macromolecules

Find similar proteins by: Sequence  |  Structure


Entity ID: 4
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L13-A
L
199Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL13A
Find proteins for Q12690 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: RPL13A
Go to UniProtKB:  Q12690
Entity ID: 5
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L15-A
N
204Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL15A (RPL10A, RPL13A, YL10A)
Find proteins for P05748 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P05748
Entity ID: 6
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L18-A
Q
186Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL18A (RP28A)
Find proteins for P0CX49 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: RPL18A
Go to UniProtKB:  P0CX49
Entity ID: 7
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L19-A
R
189Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL19A (RPL23A, YL14A)
Find proteins for P0CX82 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P0CX82
Entity ID: 8
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L20-A
S
172Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL20A (RPL18A, RPL18A2)
Find proteins for P0CX23 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P0CX23
Entity ID: 9
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L21-A
T
160Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL21A (URP1)
Find proteins for Q02753 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  Q02753
Entity ID: 10
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L22-A
U
121Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL22A
Find proteins for P05749 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P05749
Entity ID: 11
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L27-A
Z
136Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL27A (RPL27)
Find proteins for P0C2H6 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: RPL27A
Go to UniProtKB:  P0C2H6
Entity ID: 12
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L30
c
105Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL30 (RPL32)
Find proteins for P14120 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: RPL30
Go to UniProtKB:  P14120
Entity ID: 13
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L31-A
d
113Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL31A (RPL34, RPL34A)
Find proteins for P0C2H8 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P0C2H8
Entity ID: 14
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L32
e
130Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL32
Find proteins for P38061 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: RPL32
Go to UniProtKB:  P38061
Entity ID: 15
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L33-A
f
107Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL33A (RPL37A)
Find proteins for P05744 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P05744
Entity ID: 16
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L34-A
g
121Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL34A
Find proteins for P87262 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P87262
Entity ID: 17
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L36-A
i
100Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL36A (RPL39A)
Find proteins for P05745 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: RPL36A
Go to UniProtKB:  P05745
Entity ID: 18
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L37-A
j
88Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL37A (RPL35A)
Find proteins for P49166 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: RPL37A
Go to UniProtKB:  P49166
Entity ID: 19
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L38
k
78Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL38
Find proteins for P49167 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: RPL38
Go to UniProtKB:  P49167
Entity ID: 20
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L16-A
O
199Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL16A (RPL13, RPL21A)
Find proteins for P26784 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P26784
Entity ID: 21
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L23-A
V
137Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL23A (RPL17A, RPL17AA)
Find proteins for P0CX41 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: RPL23A
Go to UniProtKB:  P0CX41
Entity ID: 22
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L28
a
149Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL28 (CYH2)
Find proteins for P02406 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: RPL28
Go to UniProtKB:  P02406
Entity ID: 23
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L17-A
P
184Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL17A (RPL17, RPL20A)
Find proteins for P05740 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P05740
Entity ID: 24
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L25
X
142Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL25
Find proteins for P04456 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P04456
Entity ID: 25
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L26-A
Y
127Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL26A (RPL26, RPL33A)
Find proteins for P05743 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P05743
Entity ID: 26
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L35-A
h
120Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL35A (SOS1)
Find proteins for P0CX84 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: RPL35A
Go to UniProtKB:  P0CX84
Entity ID: 27
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L7-A
F
244Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL7A (RPL6A, RPL8A, YL8A)
Find proteins for P05737 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: RPL7A
Go to UniProtKB:  P05737
Entity ID: 28
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L3
B
387Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL3 (MAK8, TCM1)
Find proteins for P14126 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: RPL3
Go to UniProtKB:  P14126
Entity ID: 29
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L4-A
C
362Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL4A (RPL2, RPL2A)
Find proteins for P10664 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P10664
Entity ID: 30
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L9-A
H
191Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL9A (RPL8A, RPL9)
Find proteins for P05738 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P05738
Entity ID: 31
MoleculeChainsSequence LengthOrganismDetails
Ribosome biogenesis protein BRX1
A
291Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: BRX1
Find proteins for Q08235 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  Q08235
Entity ID: 32
MoleculeChainsSequence LengthOrganismDetails
Proteasome-interacting protein CIC1
K
376Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: CIC1 (NSA3)
Find proteins for P38779 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P38779
Entity ID: 33
MoleculeChainsSequence LengthOrganismDetails
Ribosome biogenesis protein ERB1
m
807Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: ERB1
Find proteins for Q04660 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  Q04660
Entity ID: 34
MoleculeChainsSequence LengthOrganismDetails
ATP-dependent RNA helicase HAS1
D
505Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: HAS1
EC: 3.6.4.13
Find proteins for Q03532 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: HAS1
Go to UniProtKB:  Q03532
Entity ID: 35
MoleculeChainsSequence LengthOrganismDetails
Ribosome assembly factor MRT4
W
236Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: MRT4
Find proteins for P33201 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P33201
Entity ID: 36
MoleculeChainsSequence LengthOrganismDetails
60S ribosome subunit biogenesis protein NIP7
l
181Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: NIP7
Find proteins for Q08962 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: NIP7
Go to UniProtKB:  Q08962
Entity ID: 37
MoleculeChainsSequence LengthOrganismDetails
Nucleolar GTP-binding protein 1
b
647Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: NOG1
Find proteins for Q02892 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  Q02892
Entity ID: 38
MoleculeChainsSequence LengthOrganismDetails
Ribosome biogenesis protein 15
o
220Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: NOP15
Find proteins for P53927 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P53927
Entity ID: 39
MoleculeChainsSequence LengthOrganismDetails
Pescadillo homolog
n
605Saccharomyces cerevisiae (strain YJM789)Mutation(s): 0
Gene Names: NOP7 (RRP13, YPH1)
Find proteins for A6ZV85 (Saccharomyces cerevisiae (strain YJM789))
Go to UniProtKB:  A6ZV85
Entity ID: 40
MoleculeChainsSequence LengthOrganismDetails
Ribosome biogenesis protein NSA2
r
261Saccharomyces cerevisiae (strain YJM789)Mutation(s): 0
Gene Names: NSA2
Find proteins for A6ZR80 (Saccharomyces cerevisiae (strain YJM789))
Go to Gene View: NSA2
Go to UniProtKB:  A6ZR80
Entity ID: 41
MoleculeChainsSequence LengthOrganismDetails
Nuclear GTP-binding protein NUG1
s
520Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: NUG1
Find proteins for P40010 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P40010
Entity ID: 42
MoleculeChainsSequence LengthOrganismDetails
Ribosome biogenesis protein RLP7
t
322Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RLP7 (RPL7)
Find proteins for P40693 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P40693
Entity ID: 43
MoleculeChainsSequence LengthOrganismDetails
Eukaryotic translation initiation factor 6
y
245Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: TIF6 (CDC95)
Find proteins for Q12522 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  Q12522
Entity ID: 44
MoleculeChainsSequence LengthOrganismDetails
UPF0642 protein YBL028C
z
106Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Find proteins for P38202 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P38202
Entity ID: 45
MoleculeChainsSequence LengthOrganismDetails
Ribosome biogenesis protein YTM1
p
460Saccharomyces cerevisiae (strain YJM789)Mutation(s): 0
Gene Names: YTM1
Find proteins for A6ZPA9 (Saccharomyces cerevisiae (strain YJM789))
Go to UniProtKB:  A6ZPA9
Entity ID: 46
MoleculeChainsSequence LengthOrganismDetails
25S rRNA (cytosine(2870)-C(5))-methyltransferase
q
618Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: NOP2 (YNA1)
EC: 2.1.1.310
Find proteins for P40991 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: NOP2
Go to UniProtKB:  P40991
Entity ID: 47
MoleculeChainsSequence LengthOrganismDetails
Ribosome biogenesis protein RLP24
u
199Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RLP24
Find proteins for Q07915 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  Q07915
Entity ID: 48
MoleculeChainsSequence LengthOrganismDetails
Nucleolar protein 16
v
231Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: NOP16
Find proteins for P40007 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: NOP16
Go to UniProtKB:  P40007
Entity ID: 49
MoleculeChainsSequence LengthOrganismDetails
27S pre-rRNA (guanosine(2922)-2'-O)-methyltransferase
w
841Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: SPB1
EC: 2.1.1.167
Find proteins for P25582 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P25582
Entity ID: 50
MoleculeChainsSequence LengthOrganismDetails
Nucleolar complex-associated protein 3
I
663Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: NOC3
Find proteins for Q07896 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  Q07896
Entity ID: 51
MoleculeChainsSequence LengthOrganismDetails
rRNA-processing protein EBP2
J
427Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: EBP2
Find proteins for P36049 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P36049
Entity ID: 52
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L6-A
E
176Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL6A (RPL17A, YL16A)
Find proteins for Q02326 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  Q02326
Entity ID: 53
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L8-A
G
256Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL8A (MAK7, RPL4A)
Find proteins for P17076 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P17076
Entity ID: 54
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L14-A
M
138Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL14A
Find proteins for P36105 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P36105
Entity ID: 1
MoleculeChainsLengthOrganism
25S ribosomal RNA13396Saccharomyces cerevisiae S288C
Entity ID: 2
MoleculeChainsLengthOrganism
5.8S ribosomal RNA2158Saccharomyces cerevisiae S288C
Entity ID: 3
MoleculeChainsLengthOrganism
Internal transcribed spacer 26232Saccharomyces cerevisiae S288C
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download SDF File
Download CCD File
j
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.3 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2017-12-27
    Type: Initial release
  • Version 1.1: 2018-02-07
    Type: Source and taxonomy, Structure summary
  • Version 1.2: 2018-11-21
    Type: Advisory, Data collection, Derived calculations
