6EIN | pdb_00006ein

Crystal structure of KDM5B in complex with S49365a.

• PDB DOI: https://doi.org/10.2210/pdb6EIN/pdb

• Classification: OXIDOREDUCTASE
• Organism(s): Homo sapiens
• Expression System: Spodoptera frugiperda
• Mutation(s): No


• Deposited: 2017-09-19 Released: 2018-05-02
• Deposition Author(s): Srikannathasan, V., Newman, J.A., Szykowska, A., Wright, M., Ruda, G.F., Vazquez-Rodriguez, S.A., Kupinska, K., Strain-Damerell, C., Burgess-Brown, N.A., Arrowsmith, C.H., Edwards, A., Bountra, C., Oppermann, U., Huber, K., von Delft, F.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.11 Å
• R-Value Free:
  0.225 (Depositor), 0.220 (DCC)
• R-Value Work:
  0.196 (Depositor), 0.200 (DCC)
• R-Value Observed:
  0.198 (Depositor)

Starting Model: experimental

Literature

Crystal structure of KDM5B in complex with S49365a.

srikannathasan, v.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 56.26 kDa
• Atom Count: 3,785
• Modeled Residue Count: 439
• Deposited Residue Count: 481
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Lysine-specific demethylase 5B,Lysine-specific demethylase 5B	A	481	Homo sapiens	Mutation(s): 0  Gene Names: KDM5B, JARID1B, PLU1, RBBP2H1 EC: 1.14.11 (PDB Primary Data), 1.14.11.67 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for Q9UGL1 (Homo sapiens) Explore Q9UGL1  Go to UniProtKB:  Q9UGL1
PHAROS:  Q9UGL1 GTEx:  ENSG00000117139

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
B7Z	B [auth A]	8-[4-[2-(4-propanoylpiperazin-1-yl)ethyl]pyrazol-1-yl]-3~{H}-pyrido[3,4-d]pyrimidin-4-one C19 H23 N7 O2 NWZZGCCTCMQFDY-UHFFFAOYSA-N
ZN	C [auth A]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N
EDO	F [auth A], G [auth A], H [auth A], I [auth A]	1,2-ETHANEDIOL C2 H6 O2 LYCAIKOWRPUZTN-UHFFFAOYSA-N
MN	D [auth A], E [auth A]	MANGANESE (II) ION Mn WAEMQWOKJMHJLA-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.11 Å
• R-Value Free:  0.225 (Depositor), 0.220 (DCC)
• R-Value Work:  0.196 (Depositor), 0.200 (DCC)
• R-Value Observed: 0.198 (Depositor)

Space Group: P 6₅ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 143.47	α = 90
b = 143.47	β = 90
c = 153.47	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
MOLREP	phasing
PDB_EXTRACT	data extraction
xia2	data reduction
xia2	data scaling
MOLREP	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2018-05-02
Deposition Author(s): Srikannathasan, V., Newman, J.A., Szykowska, A., Wright, M., Ruda, G.F., Vazquez-Rodriguez, S.A., Kupinska, K., Strain-Damerell, C., Burgess-Brown, N.A., Arrowsmith, C.H., Edwards, A., Bountra, C., Oppermann, U., Huber, K., von Delft, F.

Revision History

• Version 1.0: 2018-05-02
  Type: Initial release

• Version 2.0: 2018-09-12
  Changes: Advisory, Atomic model, Data collection, Derived calculations, Non-polymer description, Source and taxonomy, Structure summary
• Version 2.1: 2024-01-17
  Changes: Data collection, Database references, Refinement description
• Version 2.2: 2024-10-23
  Changes: Structure summary
