6E1I | pdb_00006e1i

HLA-A*0201 single chain trimer with murine H2K alpha 3 domain and HPV.16 E7 peptide YMLDLQPET

• PDB DOI: https://doi.org/10.2210/pdb6E1I/pdb

• Classification: IMMUNE SYSTEM
• Organism(s): Homo sapiens, Mus musculus
• Expression System: Homo sapiens
• Mutation(s): No


• Deposited: 2018-07-09 Released: 2019-07-17
• Deposition Author(s): Finton, K.A.K., Rusnac, D.V.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.99 Å
• R-Value Free:
  0.233 (Depositor), 0.230 (DCC)
• R-Value Work:
  0.204 (Depositor), 0.210 (DCC)
• R-Value Observed:
  0.205 (Depositor)

Starting Model: experimental

Literature

Effects of HLA single chain trimer design on peptide presentation and stability

Finton, K.A.K., Rusnac, D.V.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: mass spectrometry

Macromolecule Content

• Total Structure Weight: 49.41 kDa
• Atom Count: 3,240
• Modeled Residue Count: 389
• Deposited Residue Count: 442
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
HLA-A*0201 single chain trimer with murine H2K alpha 3 domain and HPV.16 E7 peptide YMLDLQPET	A	442	Homo sapiens, Mus musculus	Mutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for P01887 (Mus musculus) Explore P01887  Go to UniProtKB:  P01887
IMPC:  MGI:88127
Find proteins for P01902 (Mus musculus) Explore P01902  Go to UniProtKB:  P01902
Find proteins for P04439 (Homo sapiens) Explore P04439  Go to UniProtKB:  P04439
PHAROS:  P04439 GTEx:  ENSG00000206503
UniProt Groups	P01887P01902P04439

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.99 Å
• R-Value Free:  0.233 (Depositor), 0.230 (DCC)
• R-Value Work:  0.204 (Depositor), 0.210 (DCC)
• R-Value Observed: 0.205 (Depositor)

Space Group: P 2 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 52.466	α = 90
b = 82.195	β = 90
c = 107.165	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-2000	data reduction
HKL-2000	data scaling
PHASER	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2019-07-17
Deposition Author(s): Finton, K.A.K., Rusnac, D.V.

Revision History

• Version 1.0: 2019-07-17
  Type: Initial release

• Version 1.1: 2023-10-11
  Changes: Data collection, Database references, Refinement description
• Version 1.2: 2024-11-06
  Changes: Structure summary
