6DWU

Crystal structure of complex of BBKI and Bovine Trypsin


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.96 Å
  • R-Value Free: 0.281
  • R-Value Work: 0.226

wwPDB Validation 3D Report Full Report


This is version 1.0 of the entry. See complete history

Literature

Crystal structures of the complex of a kallikrein inhibitor from Bauhinia bauhinioides with trypsin and modeling of kallikrein complexes.

Li, M.Srp, J.Gustchina, A.Dauter, Z.Mares, M.Wlodawer, A.

(2019) Acta Crystallogr D Struct Biol 75: 56-69


Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Cationic trypsin
AA, AC, AE, AG, AI, AK, AM, AO, AQ, AS, AU, BA, BC, BE, BG, BI, BK, BM, BO, BQ, BS, BU, CA, CC, CE, CG, CI, CK, CM, CO, CQ, CS, CU, DA, DC, DE, DG, DI, DK, DM, DO, DQ, DS, DU
223Bos taurusMutation(s): 0
EC: 3.4.21.4
Find proteins for P00760 (Bos taurus)
Go to UniProtKB:  P00760
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Kunitz-type inihibitor
AB, AD, AF, AH, AJ, AL, AN, AP, AR, AT, AV, BB, BD, BF, BH, BJ, BL, BN, BP, BR, BT, BV, CB, CD, CF, CH, CJ, CL, CN, CP, CR, CT, CV, DB, DD, DF, DH, DJ, DL, DN, DP, DR, DT, DV
163Bauhinia bauhinioidesMutation(s): 0
Find proteins for Q6VEQ7 (Bauhinia bauhinioides)
Go to UniProtKB:  Q6VEQ7
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.96 Å
  • R-Value Free: 0.281
  • R-Value Work: 0.226
  • Space Group: P 1 21 1
Unit Cell:
Length (Å)Angle (°)
a = 137.167α = 90.00
b = 483.880β = 116.76
c = 137.010γ = 90.00
Software Package:
Software NamePurpose
HKL-2000data reduction
PHENIXrefinement
PDB_EXTRACTdata extraction
HKL-2000data scaling
PHASERphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2019-01-30
    Type: Initial release
