6DJ9

Structure of the USP15 DUSP domain in complex with a high-affinity Ubiquitin Variant (UbV)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.1 Å
  • R-Value Free: 0.267
  • R-Value Work: 0.253

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Structural and Functional Characterization of Ubiquitin Variant Inhibitors of USP15.

Teyra, J.Singer, A.U.Schmitges, F.W.Jaynes, P.Kit Leng Lui, S.Polyak, M.J.Fodil, N.Krieger, J.R.Tong, J.Schwerdtfeger, C.Brasher, B.B.Ceccarelli, D.F.J.Moffat, J.Sicheri, F.Moran, M.F.Gros, P.Eichhorn, P.J.A.Lenter, M.Boehmelt, G.Sidhu, S.S.

(2019) Structure 27: 590

  • DOI: 10.1016/j.str.2019.01.002
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • The multi-domain deubiquitinase USP15 regulates diverse eukaryotic processes and has been implicated in numerous diseases. We developed ubiquitin variants (UbVs) that targeted either the catalytic domain or each of three adaptor domains in USP15, inc ...

    The multi-domain deubiquitinase USP15 regulates diverse eukaryotic processes and has been implicated in numerous diseases. We developed ubiquitin variants (UbVs) that targeted either the catalytic domain or each of three adaptor domains in USP15, including the N-terminal DUSP domain. We also designed a linear dimer (diUbV), which targeted the DUSP and catalytic domains, and exhibited enhanced specificity and more potent inhibition of catalytic activity than either UbV alone. In cells, the UbVs inhibited the deubiquitination of two USP15 substrates, SMURF2 and TRIM25, and the diUbV inhibited the effects of USP15 on the transforming growth factor β pathway. Structural analyses revealed that three distinct UbVs bound to the catalytic domain and locked the active site in a closed, inactive conformation, and one UbV formed an unusual strand-swapped dimer and bound two DUSP domains simultaneously. These inhibitors will enable the study of USP15 function in oncology, neurology, immunology, and inflammation.


    Organizational Affiliation

    Graduate School of Science and Molecular Chirality Research Center, Chiba University, Inage, Chiba, Japan.,State Key Laboratory of Agricultural Microbiology, College of Veterinary Medicine, Huazhong Agricultural University, Wuhan, China.,Institute of Advanced Energy and Graduate School of Energy Science, Kyoto University, Uji, Kyoto, Japan.,Department of Chemistry and Chemical Biology, Northeastern University, Boston, United States.,Department of Cell Biology and Medical Chemistry, Graduate School of Medicine, Kyoto University, Konoe-cho, Yoshida, Sakyo-ku, Kyoto, Japan.,Food Technology Division, Bhabha Atomic Research Centre, Trombay, Mumbai, Maharashtra 400085, India and snjam@barc.gov.in.,Japan Science and Technology Agency (JST) and Japan Agency for Medical Research and Development (AMED), Core Research for Evolutional Science and Technology (CREST), Konoe-cho, Yoshida, Sakyo-ku, Kyoto, Japan. kobayashi.takuya.4r@kyoto-u.ac.jp.,Cell Biology Program, The Hospital for Sick Children, 686 Bay Street, Toronto, ON M5G 0A4, Canada.,Department of Molecular and Cellular Physiology, Stanford University School of Medicine, Stanford, CA, USA.,Department of Biochemistry, McGill University, Montreal, QC, Canada.,Protein Metabolism Medical Research Center and Department of Biomedical Sciences, College of Medicine, Seoul National University, Seoul, 03080, Republic of Korea. yok5@snu.ac.kr.,Department of Biotechnology, Institute for Biochemistry, Biotechnology and Bioinformatics, Technische Universität Braunschweig, Spielmannstraße 17, 38106, Braunschweig, Germany.,Lunenfeld-Tanenbaum Research Institute, Mount Sinai Hospital, Toronto, ON M5G 1X5, Canada.,Institute of Human Virology, Department of Biochemistry and Molecular Biology, University of Maryland School of Medicine, Baltimore, USA. Electronic address: marzena.pazgier@usuhs.edu.,RIKEN, SPring-8 Center, Hyogo, Japan.,Department of Biological Chemistry and Molecular Pharmacology, Harvard Medical School, Boston, United States.,From the High Pressure and Synchrotron Radiation Physics Division and.,School of Biochemistry, Devi Ahilya University, Indore 452001, India.,Department of Cellular and Molecular Medicine, University of California, San Diego, La Jolla, California, 92093.,Department of Molecular Imaging and Therapy, Beckman Research Institute of the City of Hope, Duarte, CA, USA.,Protein Metabolism Medical Research Center and Department of Biomedical Sciences, College of Medicine, Seoul National University, Seoul, 03080, Republic of Korea.,Department of Cell Biology and Medical Chemistry, Graduate School of Medicine, Kyoto University, Konoe-cho, Yoshida, Sakyo-ku, Kyoto, Japan. kobayashi.takuya.4r@kyoto-u.ac.jp.,Japan Science and Technology Agency, Precursory Research for Embryonic Science and Technology (PRESTO), Kawaguchi, Saitama, Japan.,SPARC BioCentre, Hospital for Sick Children, Toronto, ON M5G 0A4, Canada.,Cancer Metabolism and Signaling Networks Program, Sanford Burnham Prebys Medical Discovery Institute, La Jolla, CA, 92037, USA.,Cancer Science Institute of Singapore, National University of Singapore, Singapore, Singapore.,The Donnelly Centre, University of Toronto, Toronto, ON M5S 3E1, Canada.,Department of Cell Biology and Molecular Genetics, University of Maryland, College Park, United States.,Center for Translational Medicine, the First Affiliated Hospital of Xi'an Jiaotong University, Xi'an, China. Electronic address: zhaole2@mail.xjtu.edu.cn.,Institute of Human Virology, Department of Biochemistry and Molecular Biology, University of Maryland School of Medicine, Baltimore, USA.,Lunenfeld-Tanenbaum Research Institute, Mount Sinai Hospital, Toronto, ON M5G 1X5, Canada; Department of Molecular Genetics, University of Toronto, Toronto, ON M5S 1A8, Canada.,Cancer Science Institute of Singapore, National University of Singapore, Singapore, Singapore; Department of Pharmacology, Yong Loo Lin School of Medicine, National University of Singapore, Singapore, Singapore.,Structure and Function of Proteins, Helmholtz Centre for Infection Research, Inhoffenstraße 7, 38124, Braunschweig, Germany.,Biolojic Design, Ltd., 12 Hamada Street, Rehovot 7670314, Israel.,Boehringer Ingelheim Pharma GmbH & Co KG, Biberach, Germany.,Program in Cellular and Molecular Medicine, Children's Hospital Boston, Boston, United States.,Boston Biochem, a Bio-Techne Brand, 840 Memorial Drive, Cambridge, MA 02139, USA.,SPARC BioCentre, Hospital for Sick Children, Toronto, ON M5G 0A4, Canada; Cell Biology Program, The Hospital for Sick Children, 686 Bay Street, Toronto, ON M5G 0A4, Canada; Department of Molecular Genetics, University of Toronto, Toronto, ON M5S 1A8, Canada.,Japan Science and Technology Agency, Research Acceleration Program, Membrane Protein Crystallography Project, Konoe-cho, Yoshida, Sakyo-ku, Kyoto, Japan.,From the High Pressure and Synchrotron Radiation Physics Division and ravimakde@rrcat.gov.in.,The Donnelly Centre, University of Toronto, Toronto, ON M5S 3E1, Canada; Department of Molecular Genetics, University of Toronto, Toronto, ON M5S 1A8, Canada.,Department of Chemistry, University of California, San Diego, La Jolla, California, 92093.,Antibody Discovery and Protein Engineering, MedImmune, Granta Park, Cambridge CB21 6GH, UK.,Department of Pharmacology, University of Colorado School of Medicine, Aurora, CO, 80045, USA.,Ludwig Institute for Cancer Research, San Diego Branch, La Jolla, California, 92093.,Department of Cell Biology and Medical Chemistry, Graduate School of Medicine, Kyoto University, Konoe-cho, Yoshida, Sakyo-ku, Kyoto, Japan. r.suno@mfour.med.kyoto-u.ac.jp.,Department of Biotechnology, Institute for Biochemistry, Biotechnology and Bioinformatics, Technische Universität Braunschweig, Spielmannstraße 17, 38106, Braunschweig, Germany. U.Rau@tu-bs.de.,Key Laboratory of Fermentation Engineering, Ministry of Education, College of Bioengineering, Hubei University of Technology, Wuhan, China; Institute of Human Virology, Department of Biochemistry and Molecular Biology, University of Maryland School of Medicine, Baltimore, USA.,Protech Inc., Yongeon 103 Daehangno, Jongno-gu, Seoul, 110-799, Republic of Korea. yok5@snu.ac.kr.,AstraZeneca R&D, Darwin Building Cambridge Science Park, Milton Road, Cambridge CB4 0WG, UK.,Boehringer Ingelheim RCV GmbH & Co KG, Vienna, Austria.,The Donnelly Centre, University of Toronto, Toronto, ON M5S 3E1, Canada; Department of Molecular Genetics, University of Toronto, Toronto, ON M5S 1A8, Canada. Electronic address: sachdev.sidhu@utoronto.ca.,Center for Epigenetics, Van Andel Research Institute, Grand Rapids, MI, 49503, USA.,Department of Biochemistry, McGill University, Montreal, QC, Canada; Corbin Therapeutics, Montreal, QC, Canada.,Department of Pharmacology, University of Colorado School of Medicine, Aurora, CO, 80045, USA. tatiana.kutateladze@ucdenver.edu.,Biolojic Design, Ltd., 12 Hamada Street, Rehovot 7670314, Israel; The Goodman Faculty of Life Sciences, Nanotechnology Building, Bar Ilan University, Ramat Gan 52900, Israel. Electronic address: yanay@ofranlab.org.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Ubiquitin carboxyl-terminal hydrolase 15
A, B, C, D, E, F
141Homo sapiensMutation(s): 0
Gene Names: USP15 (KIAA0529)
EC: 3.4.19.12
Find proteins for Q9Y4E8 (Homo sapiens)
Go to Gene View: USP15
Go to UniProtKB:  Q9Y4E8
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Ubiquitin Variant UbV 15.D
G, H, I, J, K, L
86N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.1 Å
  • R-Value Free: 0.267
  • R-Value Work: 0.253
  • Space Group: P 63
Unit Cell:
Length (Å)Angle (°)
a = 152.410α = 90.00
b = 152.410β = 90.00
c = 125.461γ = 120.00
Software Package:
Software NamePurpose
SCALAdata scaling
PHASERphasing
PHENIXrefinement
MOSFLMdata reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2019-01-23
    Type: Initial release
  • Version 1.1: 2019-02-13
    Type: Data collection, Database references
  • Version 1.2: 2019-04-17
    Type: Data collection, Database references
