6D85

Structure of the Bovine p85a BH domain E217K mutant


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.203 Å
  • R-Value Free: 0.221
  • R-Value Work: 0.202

wwPDB Validation 3D Report Full Report


This is version 1.0 of the entry. See complete history

Literature

Patient-derived mutations within the N-terminal domains of p85 alpha impact PTEN or Rab5 binding and regulation.

Mellor, P.Marshall, J.D.S.Ruan, X.Whitecross, D.E.Ross, R.L.Knowles, M.A.Moore, S.A.Anderson, D.H.

(2018) Sci Rep 8: 7108-7108

  • DOI: 10.1038/s41598-018-25487-5
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • The p85α protein regulates flux through the PI3K/PTEN signaling pathway, and also controls receptor trafficking via regulation of Rab-family GTPases. In this report, we determined the impact of several cancer patient-derived p85α mutations located wi ...

    The p85α protein regulates flux through the PI3K/PTEN signaling pathway, and also controls receptor trafficking via regulation of Rab-family GTPases. In this report, we determined the impact of several cancer patient-derived p85α mutations located within the N-terminal domains of p85α previously shown to bind PTEN and Rab5, and regulate their respective functions. One p85α mutation, L30F, significantly reduced the steady state binding to PTEN, yet enhanced the stimulation of PTEN lipid phosphatase activity. Three other p85α mutations (E137K, K288Q, E297K) also altered the regulation of PTEN catalytic activity. In contrast, many p85α mutations reduced the binding to Rab5 (L30F, I69L, I82F, I177N, E217K), and several impacted the GAP activity of p85α towards Rab5 (E137K, I177N, E217K, E297K). We determined the crystal structure of several of these p85α BH domain mutants (E137K, E217K, R262T E297K) for bovine p85α BH and found that the mutations did not alter the overall domain structure. Thus, several p85α mutations found in human cancers may deregulate PTEN and/or Rab5 regulated pathways to contribute to oncogenesis. We also engineered several experimental mutations within the p85α BH domain and identified L191 and V263 as important for both binding and regulation of Rab5 activity.


    Organizational Affiliation

    Cancer Research Group, University of Saskatchewan, 107 Wiggins Road, Saskatoon, Saskatchewan, S7N 5E5, Canada.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Phosphatidylinositol 3-kinase regulatory subunit alpha
B, A
193Bos taurusMutation(s): 1
Gene Names: PIK3R1
Find proteins for P23727 (Bos taurus)
Go to Gene View: PIK3R1
Go to UniProtKB:  P23727
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download SDF File
Download CCD File
A, B
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
CSO
Query on CSO
A, B
L-PEPTIDE LINKINGC3 H7 N O3 SCYS
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.203 Å
  • R-Value Free: 0.221
  • R-Value Work: 0.202
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 85.474α = 90.00
b = 91.647β = 90.00
c = 93.556γ = 90.00
Software Package:
Software NamePurpose
HKL-2000data reduction
HKL-2000data scaling
PHASERphasing
PHENIXrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Canadian Institutes of Health ResearchCanadaMOP84277
Canadian Institutes of Health ResearchCanadaMOP126155
Natural Sciences and Engineering Research Council (Canada)CanadaRGPIN262138

Revision History

  • Version 1.0: 2018-05-23
    Type: Initial release
